ABBlighting V-Line Instruction Manual

For Universal Slip Fitter
1. Unsrew to install slip fitter first.
2. Rotate fixture to appropriate position, and srew tightly. Fixture can adjust 180˚.
3. Insert slip fitter to the pole.
3. Insert slip fitter to the pole

WARRANTY

LIMITED FIVE-YEAR WARRANTY. Should this product fail to perform satisfactorily due to a defect or poor workmanship
within five years from the date of purchase, return it to the place of purchase and it will be replaced, free of charge.
Incidental or consequential damages are excluded from the warranty.
4
Add: 1501 Industrial Way North, Toms River, NJ 08755 Phone: 866-ABB-8866 E-mail: info@abblighting.com
Web: www.abblighting.com ©2015 ABBlighting, Inc. All rights reserved
LED V-LINE FLOOD LIGHT
Instructions Manual
1. Unsrew to install slip fitter first
2. Rotate fixture to appropriate
position, and srew tightly. Fixture
can adjust 180˚

Slip Fitter

Pole

SUITABLE FOR MODEL
IMAGE MAY VARY FROM ACTUAL PRODUCT

SAFETY INSTRUCTION

READ CAREFULLY BEFORE INSTALLING FIXTURE. PLEASE KEEP THIS MANUAL FOR FUTURE USING.
Fixtures must be wired in accordance with the National Electrical Code and all applicable local codes. Proper grounding
is required for safety.
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICATION CODE BY A PERSON
FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED.
MAKE CERTAIN POWER OFF BEFORE INSTALLING OR MAINTAINING FIXTURE.
CHECK THAT VOLTAGE IS COMPATIBLE WITH FIXTURE DRIVER, USE APPROVED CONNECTORS FOR
ALL ELECTRICAL CONNECTIONS.

MAINTENANCE CAUTION

1. Review the wire connection before beginning, and make sure fixture is grounded properly.
2. For lighting controls, using functioning correctly.
3. Turn power off and wait for fixture cooling to operate.
4. Maintenance must be done by professionals.

WIRE CONNECTION

FOR 26W V-LINE FLOOD LIGHT
Universal voltage driver permits operation at 120V-277V,
50/60Hz
