Summary of Contents for BLUCHER CP 700E
- Page 1 Instruction manual Compact hydraulic pump with accumulator BLUCP 700E Drainage and pressure piping solutions PO Box 107; Corunna Avenue, Melrose Park SA 5039 T: 08 8374 3426 | M: 0425 567 241 spaterson@blucher.com.au | www.blucher.com.au...
- Page 2 Please read this instruction manual carefully before using our pro- duct. In case of any open issues or questions, please contact our service center immediately. (Find Information on the last cover page) BLUCP700E...
-
Page 3: Table Of Contents
19.2 Oil filling 19.3 Changing the filter Removal from service/disposal Guarantee/Repair The entire or partial contents of this document shall not be copied or made available to third parties in any other way without the prior written permission of BLUCHER . BLUCP700E... -
Page 4: Technical Data
Technical data Operating pressure: 700 bar (70 MPa) Max. Lift: depending on the tool used Battery voltage: 18 V DC Drive motor: DC permanent magnet motor Battery capacity: 3,0 Ah Time of pressing cycle approx. 4-7 sec. (depending on ND) Type of battery: Li-Ion (without memory effect) Charging time:... - Page 5 BLUCP700E...
-
Page 6: Accessories Supplied With The Basic Unit
Accessories supplied with the basic unit Item Definition Item Definition USB 2.0 cable with 5 pole mini type [ 1 ] [ 4 ] 1.5m pressure hose connectors: A plug and B socket [ 2 ] [ 5 ] Remote control unit CD-ROM C 18 C type battery charger [ 3 ]... -
Page 7: General Information
8 days of its detection and not later than one year after receipt of the product. BLUCHER shall not be held liable for any defects claimed after the abovementi- oned period. The guarantee does not cover any damage caused by improper handling, poor maintenance, by using other than original BLUCHER spare parts, by opening the de- vices by non-authorized staff. -
Page 8: Safety Instructions When Using The Equipment
Safety instructions when using the equipment Caution: In case of non-observance of the safety instructions there is danger to life and health or it can cause material damage to the machine and the surrounding environment! Caution: Never place fingers or other parts of the body into the working area of the tool head! Caution: Keep other people, particularly unauthorized people, away from the wor-... -
Page 9: Storage And Transportation
Complete shutdown of the equipment takes place exclusively upon remo- val of the battery. Caution: If oil leaks from the Compact pump, it must be sent to the BLUCHER custo- mer service department. Caution: The BLUCP700E Compact pump must not be operated in case of heavy rain or underwater. -
Page 10: Start-Up Of The Equipment
Start-up of the equipment Remove the protection caps from remote control and hydraulic connection from the BLUCP700E Compact pump. Next, connect the pressure tube and remote control unit as shown in the illustration. Insert the battery on the rear of the unit (see illustration) and push until the safety switch clicks. - Page 11 Caution: When the power pack is not being used keep it away from paper clips, coins, keys, nails, screws and other small metal objects which could act as contact bridges. A short circuit between the battery contacts could cause combustion or fires. Caution: Do not charge the power pack in the presence of easily inflammable gas or materials.
-
Page 12: Functions
Caution: In case of improper use liquid could leak from the battery. Avoid contact with the liquid. Leaking battery liquid can cause skin irritations or burns. In case of contact with the skin, rinse with abundant water. Consult a physician if liquid contacts eyes. -
Page 13: Remote Control Unit
12.1 Remote control unit Operating-LED ON or FORWARD button STOP or REVERSE button Magnetic support Fastening clip Description of operating LEDs on the remote control unit: ORANGE LED - lights up during start up GREEN LED - lights up when the work cycle is regular RED LED - flashes when the work cycle is not regular RED/GREEN LED - blinks when the service interval has expired and... -
Page 14: Tool Variations
Tool variations 14.1 Pressing tools Press head 54-75 Press collar head Press collar head Remove the protection caps for the hydraulic connection and connect the high-pressure hose of your Compact pump CUP 700 with the tool heads by pulling back the locking snap ring of the quick connector type CEJN series 115, then by sliding the connection on the plug nipple, releasing the locking snap ring and checking the connection for tight- ness. -
Page 15: Maintenance Instructions
Maintenance instructions The BLUCP700E Compact pump must be cleaned after use and stored in a dry place. Both the power pack and the battery charger must be protected from humidity and for- eign materials. Technically the equipment does not require maintenance. After completion of the previously set working cycles, it is necessary to take the BLUC- P700E Compact pump to the technical assistance service for inspection to guarantee perfect operation and to increase the long-life cycle of the machine. -
Page 16: Rating Plate
The first service assistance should be performed after 10,000 cycles, but can be freely programmed according to the conditions of use. • Integrated and intelligent electronic module with a large LCD display. Rating plate Manufacturer: BLUCHER Item Nr.: BLUCP700E Compact pump Serial Number: BLUCP700E ....Year of construction: 20.. -
Page 17: Software Installation Through Apparatus / Cd
18.2 Software installation through apparatus / CD Remove battery Hold down start stop button on the remote control at the same time while plugging in battery Wait till both LEDs are flahing alternately Push „+“ button on the remote control one time only. Automatically LED will light green Compact pump is detected run setup.exe... -
Page 18: What To Do In Case Of Dysfunction
What to do in case of dysfunction In case of dysfunction, the BLUCP700E Compact pump is disused. The „service informati- on LED“ signals the error code by the numbers of the flashing process. The error code may be cancelled by removing and plugging in battery; this also resets the system. - Page 19 SD card error flashing orange Overload lightning red Device too cold (continuous checking) lightning orange Device too hot (continuous checking) lightning orange Other indications Assistance Battery Error Description code Error during initialization of sensor temperature lightning red Drop in pressure during compression lightning red Fan not working lightning red...
-
Page 20: Oil Filling
19.2 Oil filling Disconnect coupling Position the device turning it Unscrew and remote control by 90° (battery on top) with a coin Fill to the brim with hydraulic oil Tighten screw „Shell-Naturelle HF-E15“ with a coin 19.3 Changing the filter Disconnect coupling Lift the device Press down lever... -
Page 21: Removal From Service/Disposal
Removal from service/disposal he individual components of the group must be disposed of separately. First of all it is necessary to drain the oil which must be taken to a special disposal centre. Next it is necessary to dispose of the battery through a special procedure, taking into ac- count the relative law. -
Page 22: Guarantee/Repair
Guarantee/Repair The company BLUCHER grants a warranty of 2 years or 20.000 cycles, if the tool is opera- ted to its appropriate use from the beginning of the warranty period. The warranty period starts with the date of the 25th pressing cycle. - Page 23 DECLARACIÓN CE DE CONFORMIDAD DÉCLARATION CE DE CONFORMITÉ Nous Australia BLUCHER (Name des Herstellers) (nome del fabbricante) (manufacturer’s name) (nombre del fabricante) (nom du fabricant) PO Box 107; Corunna Avenue, Melrose Park SA 5039 (Anschrift) (indirizzo) (address) (dirección) (adresse) erklären in alleiniger Verantwortung, dass das Produkt dichiariamo sotto nostra unica responsabilità...
- Page 24 Service...
