Weighting of boilers
Psup / (Prated + Psup) (1)(2)
0
0.1
0.2
0.3
0.4
0.5
0.6
≥ 0.7
(1) The intermediate values are calculated by linear interpolation between the two adjacent values.
(2) Prated is related to the preferential space heater or combination heater.
Package efficiency
Main Eco Elite Combi ErP
Temperature control X
Temperature control Y
© Baxi Heating UK Ltd 2015
III I The value of the mathematical expression: 294/(11 Prated),
whereby 'Prated' is related to the preferential space heater.
IV V The value of the mathematical expression 115/(11 Prated),
whereby 'Prated' is related to the preferential space heater.
II, package without hot water storage tank
0
0.3
0.55
0.75
0.85
0.95
0.98
1.00
%
%
9.0 ErP Information
9.2 Package Fiche - Boilers (cont)
II, package with hot water storage tank
0
0.37
0.70
0.85
0.94
0.98
1.00
1.00
25 30
