Summary of Contents for JDM A 4324
-
Page 1: Operating Instructions
4 Zone Public Address Amplifier ® Professional Four Zone Desktop Mixing Amplifiers A 4324 240W Operating Instructions Distributed by Altronic Distributors Pty. Ltd. Perth. Western Australia. Phone: 1300 780 999 Fax: 1300 790 999 Internet: www.altronics.com.au Revision 02/10/12... -
Page 2: Installation
4 Zone Public Address Amplifier ® Congratulations on purchasing this 4-Zone amplifier. It is housed IN THE BOX in a heavy duty 3RU rack mount cabinet and includes a host of • JD-Media PA Mixer Console features. It provides an economical solution for smaller •... -
Page 3: Front Panel Controls
4 Zone Public Address Amplifier ® www.jd-media.co.kr Fig 1: Front Panel Controls FRONT PANEL CONTROLS 7. MIC / LINE These knobs (CH1 to CH5) adjust the volume levels of the 1. POWER microphone or line inputs as selected by the rear panel switch Push switch to turn on. -
Page 4: Rear Panel Controls
4 Zone Public Address Amplifier ® Fig 2: Rear Panel Layout HIGH IMPEDANCE FM 75 BALANCED OUTPUT AM GND (20 ) 70V 100V(42 ) RMS 240W MIC(XLR) / LINE(PHONE) INPUTS DIRECT MESSAGE SPK ZONES E/M CON OUTPUT HIGH 100V (2.6 ) COLD REMOTE LINE... - Page 5 (20 ) 70V 100V(42 ) RMS 240W DIRECT SPK ZONES OUTPUT HIGH 100V (2.6 ) A 4324 20Ω 41Ω COLD Common Terminal Be sure that total impedance is not less than rated impedance. This includes switched speaker zones These terminals can be used for speakers &...
- Page 6 4 Zone Public Address Amplifier ® TELEPHONE PABX UNIT FM 75 HIGH IMPEDANCE BALANCED OUTPUT AM GND (20 ) 70V 100V(42 ) RMS 240W MIC(XLR) / LINE(PHONE) INPUTS DIRECT MESSAGE SPK ZONES OUTPUT E/M CON HIGH 100V (2.6 ) COLD REMOTE LINE S R T...
-
Page 7: Specifications
4 Zone Public Address Amplifier ® Fig 5: Block circuit diagram. SPECIFICATIONS A 4324 power: ............240 watts RMS Distortion: .............. < 1% @ 1kHz Signal to noise ratio ........Line: >70dB Mic: >60dB Frequency response .......... 80Hz - 15kHz, ±3dB Mic input sensitivity: .......... - Page 8 4 Zone Public Address Amplifier ® Altronic Distributors warrants this product for two years from the date of purchase from Altronics or its resellers to the consumer. If this item is part of an installation or another product, please contact the installer or supplier for your warranty. During the warranty period, we undertake to repair or replace your product at no charge if found to be defective due to a manufacturing fault.
