Con-To-Go

User Guide

Media Content Box

ADSM002a-0/ADSM002b-0

Table of Contents

Need help?

Do you have a question about the Con-To-Go ADSM002a-0 and is the answer not in the manual?

Questions and answers

Summary of Contents for aptos Con-To-Go ADSM002a-0

Page 1 Con-To-Go User Guide Media Content Box ADSM002a-0/ADSM002b-0...
Page 2: Table Of Contents
Index Description & Feature ........... 02 Specification ..............03 Product Overview ............04 Remote Control .............. 06 Getting Started ............... 07 User Interface ..............15 Question/Troubleshooting .......... 23 Support File Format List ..........25 Package List ..............28 Safety Precautions ............
Page 3: Description & Feature
Description & Feature - Easily plug in SD memory card or USB drive,You can enjoy High resolution movies and pictures on TV by playing Con-To-go.Or, you can listen to music by using Con-To-Go. - Instead of using PC to link with TV as an electronic bulletin board, we offer services to help you create your own HD bulletin board using this low cost solution.
Page 4: Specification
Specification Video Format *.rm/*.rmvb/*.mpg/*.avi/*.dat/*.vob/ *.mp4/*mov Image Format JPEG,BMP,PNG,GIF,TIFF Music Format mp3 + LRC, WMA, WAV, Ogg Vorbis, AAC, RealAudio, APE, FLAC Adaptor power AC110~240v, 50~60Hz requirement Power Requirement 5V DC Maximum current Maximum resolution Input 720×576 Maximum resolution Output 1280x720 (HD) Operating Temperature 0°C ~ 40°C Storage Temperature...
Page 5: Product Overview
Product Overview - Top View - Power Indicator Infrared Sensor (Remote Control) - Back View - A/V Output Component Output Input - 5V Power Adapter...
Page 6: Right View
Product Overview - Right View - USB TYPE SD TYPE ADSM002a-0 ADSM002b-0 Remote Control Holder Input - SD Memory Card Input - USB Device...
Page 7: Remote Control
Remote Control power switch, player in work / dormancy return to main menu Play / Pause Upwards Downwards Left Right Stop Setting video image size, mode: “full screen”, “16:9mode1”, “16:9mode2”, “4:3mode”, “keep ratio” Return to forward menu Enter Select previous file. When playing video, speed backwards Select next file.
Page 8: Getting Started
Getting Started 1. Remote control installation and use 1) Take battery cover out. 2) Take isolated film out. 3) Install battery and battery cover again.
Page 9 Getting Started 1. Remote control installation and use 2) Take isolated film out.
Page 10 Getting Started 1. Remote control installation and use 3) Install battery and battery cover again. Pay Attention: - When operate the remote please aim it at the remote receiver, in 60 degrees and 5 meters, and forbid any obstacle between them. - The battery’s life is one year at common instance.
Page 11 Getting Started 2. Terminal connect - Output Format: NTSC / PAL Interlace If use CVBS mode, connect composite cable between Con-To-Go and TV’s CVBS/L/R port. Audio In Video In...
Page 12 Getting Started 3. Terminal connect - Output Format: 480i/480p/576i/576p/720p If use YPbPr mode, Connect component cable between Con-To-Go and TV. Then, connect composite cable between Con-To-Go and TV’s R/L audio port. Audio In Video In...
Page 13 Getting Started Connect power wire correctly.
Page 14 Getting Started USB TYPE SD TYPE ADSM002a-0 ADSM002b-0 Insert Pendrive or SD memory card.
Page 15 Getting Started Plug in power plug, then the power LED on the Con-To-Go turn blue, the player will work after a moment.
Page 16: User Interface
User Interface The first page of user interface displays SETUP icon. When user insert Pen drive or external hard drive, the icon of USB would appear on the screen. When user insert SD card, the icon of SD would appear on the screen.
Page 17 User Interface User can setup his/her preferable mold when user enter the SETTINGS function. - Language: choose “English”, “Traditional Chinese”, or “Simple Chinese” - Slideshow duration: set the time of picture display. - Slideshow mode: set the mode of picture display. - Music repeat mode: set the repeat mode of music play.
Page 18 User Interface Note: If you choose component cable to connect with TV, please make sure you select HD mold in TV System function. If you choose composite cable to connect with TV, please make sure you select the correct format in TV System function. NTSC - Taiwan, USA, Canada, Janpan, and etc.
Page 19 User Interface When user select SD, or HOME page, the icons of PICTURE, MUSIC, MOVIE, TXT, and FILE - Photo: Display photos in the storage. - Music: Display music in the storage. When move the cursor to the music for 4 seconds, it will play automatically.
Page 20 User Interface Background Music PHOTO on Select Media, you can display the picture from When user select your storage device. Note: After you click the selecting picture, the system would go into the slide show mold. Meanwhile, the system will search the music of the shortest route as the background music when you click button on the remote control.
Page 21 User Interface So I called up my head shrinker, And I told him what I'd done Note: Support *.lrc format When user select MUSIC on Select Media, you can play the music from your storage device.
Page 22 User Interface When user select MOVIE on Select Media, you can play the movie from your storage device. Note: Support *.srt format...
Page 23 User Interface When user select FILE on Select Media, you can select the file you want to delete from your storage device. If you insert both SD card and USB device, you also can copy file from one device to another device. Select File Delete Delete File:...
Page 24: Question/Troubleshooting
Question/Troubleshooting This chapter presents some troubleshooting problems you may encounter while using the device. Even if the following guide fails to solve your problem, please do not disassemble the device, but leave the problems to professional staff. Trouble Troubleshooting Power light not turn on Examine the connect of the power supply The TV have no image - Examine the connect of the TV connector...
Page 25 Question/Troubleshooting This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 26: Support File Format List
Support File Format List Below table list the support file with AML8613 chipset, only for reference, the support format will base on your real measure. Category Codec Max Resolution MPEG1 MPEG1 MPEG2 MPEG2 RMP4 Divx5 720x576 Divx4 MPEG4(ASP) Xvid DIVX Video MP4V DIV3...
Page 27 Support File Format List Category Codec Max Resolution JPEG Photo TIFF 8000x8000 Category Codec SampleRate Layer1 Layer2 8-48KHz Layer3 MPEG2.5 Audio 8-48KHz LPCM IMA-ADPCM 8-96KHz MS-ADPCM RealAudio COOK...
Page 28 Support File Format List Category .avi .mpg .vob Video .rmvb .dat .mp4 File .mov .mp3 Music .wav .wma .jpg .bmp .gif Photo .png .tiff...
Page 29: Package List
Package List Con-To-Go Composite Cable Component Cable User Manual Remote Control AC Adapter...
Page 30: Safety Precautions
Safety Precautions 1. Please turn off the power when inserting or removing SD memory card or USB device. Otherwise, it may cause damage to SD memory card, the USB device, or the unit. 2. Your product is a sophisticated electronic device. Do not drop or subject the unit to jarring or strong vibrations.

This manual is also suitable for:

Con-to-go adsm002b-0
