Summary of Contents for Mohawk MAS 10
- Page 1 MAS 10 10-Inch Active Subwoofer User's Manual...
- Page 2 Panel controls and features A.POWER STATUS LED F.INPUT GAIN CONTROL This bi-color LED glows green when power is After you have installed your system, turn this on and no problems are present. If one of the control to minimum. protection circuits comes on, it will change to Turn the head unit on (and the subwoofer will red.
-
Page 3: Low Level Input Wiring
Low Level Input Wiring Low-level (RCA) input wiring is preferred for best audio performance. Most trunk or hatchback installations will require a 15-20 feet RCA cable, while pickup trucks and under-seat installations will require a 6-12 feet RCA cable. Always use a high quality cable. -
Page 4: Power Connections
Power Connections Connect the ground terminal to the closest point on the chassis of the vehicle. Keep this ground wire to less than 39" (100 cm) in length. Use 8 gauge (or heavier) wire. Connect the remote terminal to the remote output of head unit using 16 gauge ( or heavier ) wire. -
Page 5: Remote Level Control Connection
Remote Install the remote control securely under the Level Control dash or in a similar location where using it will not distract the driver. Specifications MODEL: MAS 10 RMS power 150W <0.4% Signal-to-noise ratio >90dB 20Hz - 150Hz Frequency response Input sensitivity, high level 0.9V... -
Page 6: Troubleshooting
Troubleshooting If you experience operation or performance problems with this product, compare your installation with the electrical wiring diagram on the previous pages. If problems persist, read the following troubleshooting tips which may help eliminate the problems. SYMPTOM POSSIBLE REMEDY Check to make sure you have a good ground connection.
