QTek 9000 Quick Manual page 5

15 Power/Backlight
16 Microphone
17 MMC/SD Cards or
SDIO Accessories Slot
18 Touch Screen
19 Navigation Pad
20 Video Camera Lens
21 Notification LED
22 Light Sensor
23 Camera Lens
24 Fixing Lock
25 Flash Light
Press to turn on your device or backlight.
Speak into the microphone when receiving or making a phone call or voice
recording.
Lets you insert a storage card (MMC/SD) for storing data.
Use to write, draw, or make a selection with the stylus.
Press this multi-directional control up, down, left, or right to move through
menus, program instructions; carry out the selection by pressing the center
button.
Bi-color LED on the right side: Green and Orange for GSM or WCDMA standby,
SMS message, GSM or WCDMA network status, notification, battery charging
status.
Bi-color LED on the left side: Blue and green for Bluetooth system notification
of powered-up and ready to transmit radio frequency signal, and Wi-Fi status.
When you use the device in a dark environment, the system will turn on
keyboard backlight as you press any key.
Press to release the back cover.
|
5
