FTC CLIKR-5 UR5L-8700L-IP Operating Instructions

Operating Instructions for
CLIKR -5
™
Cable Remote Control
UR5L-8700L-IP
(888) 218-5050 • www.ftcvision.com
3/11

BUTTON FUNCTIONS

SySTEm ON/OFF
Available for future use
mENU
Displays the Applications Menu.
GUIDE
Displays the program guide listings
OK/SELECT
Selects highlighted screen options
SETTINGS
Available for future use
mUTE
Silences the audio. Press to activate.
Press again to restore sound to the previous level.
VOLUmE 5/6
Raises or lowers the sound level.
FAV
Available for future use
ON DEmAND
Provides direct access to On Demand channel.
BACK
Return to previous menu screen or TV channel
m BUTTONS
Available for future use
REPLAy
Replays the previous few seconds of a program.
my DVR
Digital Video Recording
DELETE
Edit text on the screen.
ON-OFF
Opens or closes the PIP (Picture-In-Picture)
window through the IPTV STB.
VIDEO SOURCE
Selects the video source from available video
components through the IPTV STB.
SWAP
Available for future use
Operating Instructions for
CLIKR -5
™
Cable Remote Control
UR5L-8700L-IP
Universal Remote Control, Inc.
www.universalremote.com
OCE-0060G REV 04 (02/26/10)
Allows you to turn your TV, VCR,
POWER
DVD, AUX and Set-top Box On and Off.
AUX, DVD, VCR, TV, STB
Used to select the component you want
to operate and signals remote control actively.
INFO
Displays information about the program currently
playing or highlighted in the program guide.
EXIT
Exit from the current screen.
PAGE +/-
Navigate to and highlight an item from
the on-screen choices.
CURSOR NAVIGATION PAD 5,6,3,4
Navigate to and highlight an item from
the on-screen choices.
A
Allows you to select available aspect ratios through the STB.
B, C, D
Available for future use.
ChANNEL 5,6
Select the next higher or lower channel.
LAST
Returns to the previously tuned channel.
INTERACTIVE
Available for future use.
SKIP
Forward ahead in stored or recorded programs.
VCR/DVD/VOD KEyS
Perform standard VCR and DVD functions when
in VCR and DVD mode, and Video-On-Demand
functions when in STB mode.
NUmBER PAD
Enter numbers to tune to channels. Also, make
numeric entries on on-screen menus.
Note: You can also use 5/6or the program guide as alternate
ways to tune channels.
ASPECT/ENTER
Allows access to viewing options, including aspect
ratios, audio languages and subtitles.
PIP Ch +/-
Available for future use
mOVE
Available for future use
LIGhT BUTTON
Press to backlight all keypad buttons. Press again to turn
off (or simply wait 10 seconds for automatic shut-off).
Note:
1. Introduction
If the 3-digit code number you just entered
is correct, the component will turn off. If it did
The CLIKR ™ -5 UR5U-8700L & UR5U-8720L are
not turn off, continue entering code numbers
designed to operate the Scientific-Atlanta, Pioneer, listed for that brand until the component turns off.
Pace Micro, Samsung and Motorola digital Set-
tops, plus the majority of TV, VCR, DVD and
Step 4:
After you've entered the correct code
AUDIO equipment on the market as shown below.
number and the component has turned off, press
CABLE: Cable Converters the [POWER] button to turn the component
TV: Televisions back on. Now it is time to test the VOLUME and
VCR: VCRs and TV/VCRs MUTE buttons for the TV (or PLAY and STOP
DVD: DVD Players buttons for VCR and DVD) to make sure they
AUX: Audio Receivers and DVRs, etc. all work. If any of the functions do not work
as they should, repeat from STEP 3 using the
next 3-digit code number listed for that brand

2. Replacing Batteries

until you find the best component code.
Before you program or operate the remote
STEP 5:
Once you have found the correct
control, you must install two new AA alkaline
3-digit code, save it by pressing the same
batteries.
[COMPONENT] button one more time. The
component LED light will blink twice to confirm
Step 1: Remove the battery compartment cover
that the code was successfully stored.
on the back of your remote control.
Now, program the rest of your components
Step 2: Check battery polarity carefully, and
by repeating STEPS 1-5.
install the batteries as shown in the illustration
below.
Note:
If the Pre-Programmed Method did not
work, or if the Code Tables do not list your
Step 3: Replace the battery compartment cover.
component brand, use the Auto-Search Method
as explained in Section B.

B. Auto-Search Method

STEP 1:
Install two Turn on the component you want to
AA alkaline program (TV, VCR, DVD or AUX).
batteries,
STEP 2:
as shown. Press the [COMPONENT] button (TV,
VCR, DVD or AUX) to be programmed and
[OK/SEL] button simultaneously for 3 seconds.
The component LED light will turn on for 30
seconds, indicating the unit is ready to be
programmed.

3. Operations

STEP 3:
Point the remote toward the component
and press the [CH5] or [CH6] button one step
DEFAULT STATE:
at a time or keep it pressed. The remote will
emit a series of ON/OFF commands. Release
Component Default:
CABLE Set-top Box
the [CH5] or [CH6] button as soon as the
(STB) Channel Default: CABLE channel and
component turns off.
numbers through the CABLE STB. You have
the option of controlling your CABLE channel
STEP 4:
Test functions. (Same as for 3-Digit
and numbers through the TV or VCR. Refer to
Code Programming Method - Section A). If any
section I for programming steps.
of the functions do not work as they should,
repeat from STEP 3 using [CH5]or [CH6]
Volume Default:
Volume and Mute control are
buttons to find the correct code.
automatically transferred to the respective
Component mode you select, as follows:
STEP 5:
Save the code. (Same as for 3-Digit
CBL:Cable Set Top Box / TV: TV / AUX:
Code Programming Method - Section A).
AUX. Volume and Mute control for VCR and
DVD are automatically transferred to the TV.
However, you have the option of controlling
Now, repeat the Auto-Search Method for those
CABLE Volume and Mute through the
components you could not program earlier with
TV, VCR or AUX. Refer to section J for
the Pre-Programmed Method. If you can't find
programming steps.
the right code using the Auto-Search Method,
try the Learning Method in Section C.
4. Programming
the Remote Control

C. Learning Method

There are two ways you can program your STEP 1:
Press the [COMPONENT] button (TV,
CLIKR™-5 remote:
VCR, DVD or AUX) to be programmed and
the [ASPECT] buttons simultaneously for 3
• The Pre-Programmed
seconds until the component LED light turns on.
3-Digit Code Method
• The Auto-Search Method
STEP 2: Line up the CLIKR™-5 to the other
• The Learning Method
remote, head-to-head, 1 or 2 inches apart.
The Pre-Programmed Code Method allows
STEP 3: Press any button on the CLIKR™-5
you to set up all the buttons at once by
that you want to teach a command to. For
entering 3-digit code numbers that correspond
example, if you want to teach the [MUTE]
to a particular Component's manufacturer/
button, press the [MUTE] button.
brand, so it's the fastest and easiest of the two
methods. (Code Tables are on the backside
STEP 4:
Press and hold the [MUTE] button
of this Instruction Sheet.) The Auto-Search
on the other remote until the CLIKR™-5
Method scans through all the codes in the
component LED light blinks twice.
remote control, one at a time. The Learning
Method allows you to transfer functions from
Note: The LED will blink 5 times if there was an
other remotes, one button at a time.
error in the learning process. If so, repeat STEPS
3 and 4. Continue learning other buttons by
Important Setup Note:
repeating STEPS 3 and 4.
This pertains to all programming steps. When you
are in setup mode, a component LED will light for
STEP 5:
30 seconds. If you do not press a button within 30 Once you have completed teaching
CLIKR™-5 all desired commands for that
seconds, the LED light will turn off and exit setup
mode and you will need to start over. component, save the learned commands by
pressing the [COMPONENT] and [ASPECT]
buttons simultaneously until the component
LED blinks 3 times. Now test all the buttons to
A. Pre-Programmed
make sure they learned correctly.
3-Digit Code Method
Step 1: D. Erasing a Single
Turn on the component you want to
program (TV, VCR, DVD or AUX).
Learning Command
Step 2:
Press the [COMPONENT] button (TV,
STEP 1: Press the [COMPONENT]
VCR, DVD or AUX) to be programmed and
[ASPECT] buttons simultaneously for 3 seconds
[OK/SEL] button simultaneously for 3 seconds.
until the component LED light turns on.
The component LED light will turn on for
30 seconds, indicating the unit is ready to be
STEP 2: Press and hold the button you want to
programmed.
erase for 3 seconds. The component LED will
blink twice to confirm the erasure.
Step 3:
Point the remote control toward the
component and enter the 3-digit code number
STEP 3: To exit, press and hold both the
assigned to your brand.
[COMPONENT] and [ASPECT]
simultaneously until the Component LED blinks
3 times.
mode. Default channel control settings on the
E. Erasing all Learned
remote control are as follows:
Commands from One Component
STB: STB TV: STB VCR: STB
DVD: DVD AUX: AUX
STEP 1:
Press the [COMPONENT] and
[ASPECT] buttons simultaneously for 3 seconds
If you wish to store the TV channel control in
until the component LED light turns on.
TV mode, use the following steps.
STEP 2: Press and hold both the [COMPONENT]
STEP 1:
Press the [TV] button and the [OK/SEL]
button you want to erase and the [PAUSE]
button simultaneously for 3 seconds. The [TV]
button for 5 seconds. The component LED will
Component LED will turn on for 30 seconds.
blink twice to confirm the erasure.
STEP 2:
Press the [VOL6] button.
STEP 3: To exit, press and hold both the
[COMPONENT] and [ASPECT] buttons
STEP 3:
Press the [TV] button again. The
simultaneously until the component LED blinks
Component LED will blink twice to confirm the
3 times.
programming.
To return to original state:
F. Finding a Component Button's
If you wish to restore the STB channel control
Setup Code Number
in TV mode, repeat the above steps but press
[STB] in STEP 3.
If you used either the Auto-Search or Learning
Methods to program a component, you may not

J. Programming Volume Control

know what the correct code number is. Here is a
way for you to identify the code number, so you Volume and
can record it for future reference. programmed to automatically transfer to the
respective Component mode you select, as
STEP 1: follows:
Press the [COMPONENT] button (TV,
VCR, DVD or AUX) you want to verify and the CBL: CBL TV: TV VCR: TV
[OK/SEL] button simultaneously for 3 seconds.
DVD: TV AUX: AUX
The Component LED light will turn on for 30
seconds. However, you can program the volume controls
(Volume Up, Volume Down and Mute) from one
STEP 2:
Press the [INFO] button and count Component to operate in another Component.
the number of times the Component LED light
If you wish to store the TV volume control in
blinks. This number indicates the first digit of
STB mode, use the following steps.
the code, followed by the second and third, each
separated by a 1- second pause when the LED
STEP 1:
Press the [STB] button and the [OK/SEL]
will turn off.
button simultaneously for 3 seconds. The [STB]
Note: Component LED will turn on for 30 seconds.
10 blinks represents the number zero.
Example: One blink (pause), eight blinks (pause)
STEP 2:
Press the [VOL5] button.
and three blinks indicates code number 183.
STEP 3:
Press the [TV] button. The Component
LED will blink
G. AUX Function:
programming.
Programming a Fifth Component
To return to original state:
You can take advantage of the AUX function to
If you wish to restore the STB volume control
program a 5th component, such as a second TV,
in STB mode, repeat the above steps but press
VCR, DVD or Audio component.
[STB] in STEP 3.
STEP 1:
Turn on the fifth component you want K. Programming a 'Macro' Button
to program (TV, VCR, DVD or Audio).
If your remote model has custom-programmable
STEP 2: Macro buttons
Press the [AUX] button and the [OK/
SEL] button simultaneously for 3 seconds. The programmed to act as a 'Macro' or Favorite
[AUX] Component LED will turn on for 30 Channel button in STB mode. This allows you
seconds. to program up to five 2-digit channels, four
3-digit channels or three 4-digit channels that
can be accessed with one button press.
STEP 3:
Press the [COMPONENT] button you
want to set up. Point the remote control toward
STEP 1:
the Component and enter the 3-digit code Press the [STB] button to select the STB
mode.
number assigned to your brand.
Note:
If the 3-digit code number you just entered STEP 2:
Press the [MACRO] button and [OK/
is the correct number, the component will turn
SEL] button simultaneously for 3 seconds. The
off. If it did not turn off, continue entering code
[STB] button will turn on for 30 seconds.
numbers listed for that brand until the component
turns off.
STEP 3:
Enter the 2-, 3- or 4-digit code for
the channel you want programmed first (for
STEP 4: example, 007) using the Number Pad, then press
Test functions. (Same as for Pre-
Programmed 3-Digit Code Method - Section the [STOP] button. Then enter the code for the
next channel (for example, 050), then press the
A). If any of the functions do not work as they
should, you need to find a new code. [STOP] button. Repeat this process for the third
channel. The [CBL] button will blink once for
each channel entered.
STEP 5:
Once you have found the correct 3-digit
code, save it by pressing the [AUX] button one
STEP 4:
more time. The Component LED light will blink Press the [CH5] button to store the
twice to confirm the code was stored. Now when channels that were selected. The [STB] button
you press the AUX button, all the buttons will will blink twice to confirm the storage of
commands.
work with that fifth component.
Note:
To access the programmed channels,
H. Programming the
press the [MACRO] button once. This will bring
System On/Off Button
up the first channel. Press once again and it will
bring up the second channel. Press again and it
This allows you to program the System On/Off
will bring up the third channel.
button so it can send up to five power On/Off
commands with one button press.
L. Low Battery Warning
STEP 1:
Press the [STB] button.
When the batteries are low and need to be
replaced with fresh batteries, the Component
STEP 2:
Press the [SYSTEM ON/OFF] button LED lights will blink 2 times in sequence
and the [OK/SEL] button simultaneously for 3 whenever a [POWER] button is pressed to turn
seconds. The [STB] button will turn on for 30
on equipment.
seconds.
M. Memory Lock System
STEP 3:
Press the first [COMPONENT] button
This remote control is designed to retain
you want to store in the [SYSTEM ON/OFF]
button and then the [POWER] button. Repeat programmed memory for 10 years even after
batteries are removed from the remote control.
this for other Components until you have
stored all the desired power commands into the
and
N. Record Your Component
[SYSTEM ON/OFF] button.

Setup Codes

STEP 4:
Press the [CH5] button to save the
power commands you stored. The [CBL] button
TV Setup Code Number:
will blink twice to confirm the commands have
VCR Setup Code Number:
been saved.
DVD Setup Code Number:
AUX Setup Code Number:

I. Programming Channel Control

For additional information about your remote
buttons
You can program the channel controls (Channel
control, go to www.universalremote.com.
Up, Channel Down, Last and Numbers) from one
Component to operate in another Component
Mute control are factory-
twice to confirm the
available, they can be
