- Page 1 USER MANUAL Portable Digital Radio CONNECTED CONNECTED CONNECTED Rechargeable DAB+ / FM Spotify Connect Li ium-Ion Battery Radio Enabled Bluetoo WiFi Network Multi-Room Smartphone Powered by NFC Connect Enabled Audio Streaming App Control UNDOK™...
-
Page 2: Important Safety Instructions
Important Safety Instructions 1. Read these instructions. 2. Keep these Instructions. 3. Heed all Warnings. 4. Follow all instructions. 5. Do not use the speaker near water. 6. Clean only with dry cloth. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS SPEAKER TO RAIN OR MOISTURE. - Page 3 carried out by qualified technicians. 16. The normal function of the product may be disturbed by strong Electro-Magnetic Interference. If so, simply reset the product to resume normal operation by following the instruction manual. In case the function could not resume, please use the product in other location. 17.
-
Page 4: Table Of Contents
Contents Important Safety Instructions ......................2 Contents ............................4 Your radio ............................6 Getting Started ..........................7 Setup Wizard ........................... 9 Internet Radio Mode ........................11 Local ‘Country’........................11 Selecting a station through ‘Stations’ ..................12 Selecting a program through ‘Podcasts’ ................13 Getting Access Code and FAQ from ‘Help’... - Page 5 Audio Settings ........................26 Storing Preset Stations ......................27 Recalling a Preset Station ...................... 27 Bluetooth Mode ..........................28 NFC (Near Field Communication) ....................28 Aux in Mode ........................... 29 General Operation ......................... 30 Setting Sleep .......................... 30 Setting Alarm .......................... 30 Setting Equaliser ........................
-
Page 6: Your Radio
Your radio /VOLUME knob Press to switch unit on or standby. Turn to adjust volume level. INFO/BACK/MENU button Press to view station information when a program is playing. Press and hold to display or exit menu screen. ... -
Page 7: Getting Started
Protected Access (WPA) data encryption then you need to know the WEP or WPA code so you can get the Heritage Portable Radio to communicate with the network. If your wireless network is configured for trusted stations you will need to enter the Radio’s ... - Page 8 Turning the Unit On/Off Connect the plug at the end of power adaptor cable to the DC IN socket at the rear of the unit. Then insert the power adaptor into the mains socket. Slide POWER switch to POWER ON side, unit will in standby mode and then start battery charging.
-
Page 9: Setup Wizard
Setup Wizard For initial use, the display will show ‘Setup wizard’ screen. Press SCROLL/SELECT knob to confirm ‘YES' to start setup. Options in the setup wizard include the following: Date/Time Set 12 or 24 hour format Auto update Synchronously update clock from the playing program you selected or set by yourself. Update from DAB ... - Page 10 Note: If a password (WEP/WPA) isn’t required by your network, radio will connect to the network automatically. Turn SCROLL/SELECT knob to cycle through the alphanumeric character list, press SCROLL/SELECT knob to select an appointed character. Note: WEP/WPA pass codes are case-sensitive. If a wrong operation is being conducted, select to delete designated character.
-
Page 11: Internet Radio Mode
Internet Radio Mode The display will show 'Main menu' after 'Setup wizard' completed. Press SCROLL/SELECT knob to select Internet radio mode. While 'Station list' is highlighted, press SCROLL/SELECT knob to confirm. → Then refer following section to choice stations. Or if failed to connect to network, please follow: a. -
Page 12: Selecting A Station Through 'Stations
Selecting a station through ‘Stations’ Stations enables you to select a station from categories: Location, Genre, Popular stations or New stations, or search stations. Press and hold INFO/BACK/MENU button > Station list > Stations, press SCROLL/SELECT knob to confirm. → In 'Stations' menu: ‘Location’... -
Page 13: Selecting A Program Through 'Podcasts
Selecting a program through ‘Podcasts’ Podcasts enables you to select a podcast from categories: Location or Genre, or search podcasts. Press and hold INFO/BACK/MENU button > Station list > Podcasts, press SCROLL/SELECT knob to confirm. → In 'Podcasts' menu: ‘Location’ enables you to choose from the podcasts provided by any country which you ... -
Page 14: Getting Access Code And Faq From 'Help
Getting Access Code and FAQ from ‘Help’ Press and hold INFO/BACK/MENU button > Station list > Help, press SCROLL/SELECT knob to confirm. Turn SCROLL/SELECT knob to select Get access code or FAQ, and then press SCROLL/SELECT knob to confirm Get access code It uses for creating an account when registering your radio on portal www.wifiradio-frontier. -
Page 15: Adding Station To 'My Added Stations
To add a Favourite Station, first find a station and then click the “Add” icon. After you added the stations, in order to have your radio access your new settings, get your radio power off for several minutes is necessary. The added stations are accessible by pressing MENU button >... -
Page 16: Viewing Station Information
Viewing Station Information Internet programs broadcast additional information. Press INFO/BACK/MENU button repeatedly while a program is playing, the display will show the information through Station Description, Genre, Country, Reliability, Bit rate, Codec, Sampling Rate, Playback Buffer and Date. Storing Preset Stations Your radio can store up to 10 of your favourite Internet stations. -
Page 17: Spotify
Tap the square image of the song’s cover art in the bottom left of the screen. Then tap the Connect icon Tap ‘Heritage P1’ from the list. If you can’t see it, just check it’s connected to the same WiFi network as your phone of tablet. -
Page 18: Controlling Spotify Connect
The Connect icon will turn green to signify that your radio is now selected and being used for audio playback. Your Spotify app will only recognize your radio when the radio is connected to the internet (i.e. in Internet Radio, Spotify Connect or Music player mode). To use Spotify when your radio is in non-internet modes (i.e. -
Page 19: Music Player Mode
Music player Mode In order for your radio to play music files from a computer, the computer must be set up to share files or media. The built-in Music player allows devices like this radio to play unprotected audio files (AAC, MP3, WMA) from a shared media library, navigating through tag menus such as Artist, Album or Genre. -
Page 20: Playing Shared Media
Make sure that the radio has access to the shared media by selecting it and clicking ‘Allow’. You can also set a name for the shared media in the box of ‘Name your media library’. Click ‘OK’ to close the dialogue boxes. The PC is now ready to stream the music to the radio. -
Page 21: My Playlist
My Playlist The My Playlist feature enables you to create a playlist of your favourite tracks from your music libraries. Once you have your playlist ready you can choose to play through the playlist on your radio and can also set shuffle and repeat play functions while your playlist is playing. To save a track to ‘My Playlist’, browse the track you want to add to the playlist, press and hold SCROLL/SELECT knob, and then the track is added to the playlist. -
Page 22: Dab Mode
DAB Mode Selecting DAB Mode Press MODE button repeatedly to select DAB mode. For initial use, radio will carry out a full scan and store stations list in memory Once the scanning is completed, the DAB/DAB+ stations will be displayed in alphanumeric order. -
Page 23: Scanning Stations
Scanning Stations Press and hold INFO/BACK/MENU button, turn SCROLL/SELECT knob to select ‘Scan’, and then press SCROLL/SELECT knob to full scan. Manual Tune This can help you when adjusting your antenna or when adding stations that were missed while auto tuning. Press and hold INFO/BACK/MENU button, turn SCROLL/SELECT knob to select ‘Manual tune’, and then press SCROLL/SELECT knob to confirm, the display will show the channel number and frequency. -
Page 24: Changing Station Order
Changing Station Order You may want to display the stations in different order. Press and hold INFO/BACK/MENU button, turn SCROLL/SELECT knob to select ‘Station order’, and then press SCROLL/SELECT knob to confirm. Turn SCROLL/SELECT knob to select 'Alphanumeric', 'Ensemble' or 'Valid', and then press SCROLL/SELECT knob to confirm your selecting option. -
Page 25: Recalling A Preset Station
Recalling a Preset Station Press PRESET button to show the saved preset stations. Turn SCROLL/SELECT knob to select the preset station you want to play and then press the SCROLL/SELECT knob to confirm. -
Page 26: Fm Mode
FM Mode Selecting FM Mode 1. Press MODE button repeatedly to select FM mode. 2. For initial use, it will start at the beginning of the FM frequency range (87.50MHz). Otherwise, the last listened FM station will be selected. 3. To manually change the FM frequency, while FM frequency shows up, turn SCROLL/SELECT knob clockwise or anticlockwise to change the frequency by 0.05MHz per step. -
Page 27: Storing Preset Stations
Storing Preset Stations Your radio can store up to 10 of your favourite FM stations. This will enable you to access your favourite stations quickly and easily. 1. While playing your favourite station, press and hold PRESET button until display shows as below: 2. -
Page 28: Bluetooth Mode
Activate your Bluetooth device and select the search mode. ‘Heritage P1’ will appear on your Bluetooth device. Select ‘Heritage P1’ and enter “0000” for the password if necessary. icon will remains steadily on the display when connection is successful. While a track is playing, you can:... -
Page 29: Aux In Mode
Aux in Mode AUX IN allows for quick and easy connection to an MP3 player or other external audio sources. Before connecting to the mains socket, use a 3.5mm audio cable (not supplied) to connect to your external audio device through the AUX IN socket at the rear of unit. /VOLUME knob to switch unit on. -
Page 30: General Operation
General Operation Setting Sleep This feature enables your radio to switch to standby mode by itself after a set sleep time. Press and hold INFO/BACK/MENU button > Main menu > Sleep, and then press SCROLL/SELECT knob to confirm. Turn SCROLL/SELECT knob to select a sleep time, and then press SCROLL/SELECT knob to confirm. -
Page 31: Setting Equaliser
Setting Equaliser This feature enables you to choose a sound equalization profile. Each of the equalization setting will change the tone of the sound from your radio when selected. Press and hold INFO/BACK/MENU button > Main menu > System settings > Equaliser, and then press SCROLL/SELECT knob to confirm. -
Page 32: Setting Time/Date
Setting Time/Date Press and hold INFO/BACK/MENU button > Main menu > System settings > Time/Date, press SCROLL/SELECT knob to confirm. Turn SCROLL/SELECT knob to select options, and then press SCROLL/SELECT knob to confirm the setting. Set Time/date: Manually set-up both Time and Date ‘Update from DAB, ‘Update from FM’, ‘Update from Auto update: Network’... -
Page 33: Software Update - Over The Network
Software Update – Over the network From time to time, your radio may make software upgrades available with bug fixes and/or additional features. If your radio detects that newer software is available, it will ask if you want to go ahead with an update. -
Page 34: Setting Backlight
Start UNDOK app, making sure your radio and smartphone are connected to same WiFi network. All available devices will be listed. Tap your radio ‘Heritage P1 xxxxxxxxxxxx’ (the 12 digit alphanumeric code is the MAC address of your radio) to connect to. - Page 35 If you have more than one radio (multi-room capable device), you can group them to play synchronously. Tap the ▼ ‘Return to device list’ icon. Create group, taping the edit icon which is following device name on device list, and then ‘Group Setup’...
- Page 36 Figure 3 Figure 4 Figure 5 Figure 6 Figure 7...
- Page 37 Alternatively, you can edit group through your radio. Press and hold INFO/BACK/MENU button > Main menu > System settings > Multi-room, and then press SCROLL/SELECT knob to confirm. Turn SCROLL/SELECT knob to select options, and then press SCROLL/SELECT knob to confirm. View your radio state (Ungrouped, Server or Client) and the View details group which it belong to.
-
Page 38: Menu Map
Menu Map... -
Page 40: Troubleshooting
Move the unit away from them (especially those with motors and transformers). Desired station not found. Weak signal. Search manually. I cannot find “Heritage P1” Ensure the Bluetooth function is activated on your on my Bluetooth device. Bluetooth device. -
Page 41: Specifications
Specifications Items Specifications Internet, DAB/DAB+ and FM radio with Bluetooth and Spotify Description: Connect FM: 87.5-108 MHz Frequency Range: DAB/DAB+: 174.928-239.200 MHz AC Input: 110-240V~, 50-60 Hz Power Requirements: DC Output: 12V, 2000mA (please use our provided adaptor) Battery: 7.4V 5000mAh Audio Output Power: 5W rms x 2 Operation: 24W (Max) - Page 42 You are also entitled to have e goods repaired or replaced if e goods fail to be of acceptable quality and e failure does not amount to a major failure. SEP15-HERITAGE P1 CONNECT...
