1 1
Unpacking
Remove all packaging from the TV. Retain the packaging. If you
dispose of it please do so according to any local regulations.
TV Screw A
Base Stand SCART Adapter Cable
Remote Control / Instruction Manual
AAA Batteries x 2
Quick Start Guide
Mains Adapter
2 2
Operating Your Remote Control
1. Press and lift the back
cover up to open the
battery compartment of
the remote control.
2. Insert two AAA size
batteries. Close the
battery compartment
cover.
Make sure the (+) and ( - ) ends of the batteries match the
(+) and ( - ) ends indicated in the battery compartment.
3 3
Installing the Base Stand
screw
OR
TV Front
screw
Base Stand
Front
Screw A
(P.N.: 20912223101)
1. Lay the TV down on a at surface with the back side facing up.
Please make sure a soft cushioned material (such as a pillow or thick
piece of foam) is placed beneath the screen.
2. To install the base stand, align the screw hole and then secure the
base stand by hand or using a screwdriver with the provided 1
screw.
The screw holes will only align if the front of the base stand
is at the front of the TV.
4 4
Connecting the Aerial
OR
RF Coaxial Cable
(not included)
USB
HDMI1 PC AUDIO
SCART PC IN
Connect one end of the RF coaxial cable to the aerial socket on the wall
and the other end of the cable to the RF (75 ) socket at the rear right
side of your TV.
Do not connect the TV to the mains supply until you have
completed all the connections.
5 5
Connecting to the Mains Socket
Mains
Adapter
(included)
To mains
socket
VIDEO L R Y Pb Pr
HDMI2
1. Connect the mains adapter to the mains socket after you have
completed all the connections.
2. At this stage, the TV switches to standby mode. The red LED
indicator will illuminate on the front panel of the TV.
3. In standby mode, press the button on the right side panel of the
TV or on the remote control to turn the TV on. The red LED indicator
will turn green.
6 6
Turning the TV On for the First Time
The rst time you turn the TV on, it will go straight into First Time
Installation.
1. Press the OK button to start First Time Installation.
First Time Installation
Please ensure aerial is plugged in!
Then press OK button.
RF
2. Press the buttons to select English as your desired
language to be displayed on the menu. Press the OK button to
con rm.
OSD Language
Cesky English
Fran ais
~
Dansk Espanol Hrvatski
Deutsch E k Italiano
OK
3. Press the buttons to select UK as the country where
you will operate the TV. Press the OK button to con rm.
Country
UK Belgium Czech
Australia Bulgaria Denmark
Austria Croatia Finland
OK
4. Channel tuning will commence. This operation may take up to 6
minutes. The display will show the progress of the tuning and the
number of channels found.
Channel Tuning
TV : 3 Channel(s)
DTV : 0 Channel(s)
Radio : 0 Channel(s)
Data : 0 Channel(s)
36%... 668.75MHz
Please press MENU to skip.
7 7
Target Region Descriptor
During tuning your TV may have received signals from more than
one transmitter. If this has occurred the Target Region Descriptor
screen will be displayed. This will enable you to select the correct
regional transmission for the local news service that you require.
Press the buttons to adjust each option's setting and then press
the OK button to con rm.
This will show the regional country
(e.g. England, Wales, Scotland, NI).
This will be shown as GBR for the UK.
Country Code
Magyar Polski
Primary Region
Nederlands Portugues
Secondary Region
Norsk Pycck
Tertiary Region
You may receive signals from more than one
transmitter within the Secondary Region,
(e.g Beds and Cambs may have Luton or
Sandy Heath).
France Hungary
This will allow you to set the region for
Germany Italy
your local news service.
Greece Luxembourg
Well done,
nd that there are many exciting features available. To get to
know all these features, please take some time to read the
instruction manual provided with your TV.
(TV)
If after reading the instruction manual you have additional
questions related to the use of your TV please call our UK Call
Centre on 0844 561 1234. Our UK Customer Contact Centre is
open Monday-Saturday 8am-8pm or Sunday 8am-6pm.
Target Region Setting
GBR
England
London
your new TV is now ready to use. You will
(P.N.: 4033C163614)
