Sound Projects SP20-Linex Operation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

S O U N D
P R O J E C T S
O
M
O
M
P
E
R
A
T
I
O
N
A
N
U
A
L
P
E
R
A
T
I
O
N
A
N
U
A
L
S
P
2
0
-
L
™
S
P
2
0
-
L
™
I
N
E
X
I
N
E
X
SOUND PROJECTS
Karperweg 16
1317 SN Almere
The Netherlands
Phone +31 (0)36 53 94 570
Fax +31 (0)36 53 00 578

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP20-Linex and is the answer not in the manual?

Questions and answers

Related Manuals for Sound Projects SP20-Linex

Summary of Contents for Sound Projects SP20-Linex

  • Page 1 S O U N D P R O J E C T S ™ ™ SOUND PROJECTS Karperweg 16 1317 SN Almere The Netherlands Phone +31 (0)36 53 94 570 Fax +31 (0)36 53 00 578...
  • Page 2 Like any high performance tool your Sound Projects system needs regular maintenance. Check all bolts and nuts of touring systems at least once a year! Clean foam-grille and cabinet openings with vacuum cleaner and compressed air to remove excessive dust.

  • Page 3: Table Of Contents

    Contents QUICK REFERENCE SET-UP GUIDE ..............4 LINE-ARRAY BASICS ..................8 BASIC CONFIGURATION PRINCIPLES ............... 9 USING SOUND PROJECTS ARRAY CALCULATOR (SPARC™) ......11 ..................... 11 ENERAL OVERVIEW ELECTRONIC SYSTEM SET-UP ................. 14 ..................... 14 ENERAL OVERVIEW ..................16 IRING AND CONNECTION ....................

  • Page 4: Quick Reference Set-Up Guide

    Step 0: Connect the single hoist adapter to the fly-frame (optional) Connect the single hoist adapter to the fly-frame. Step 1: Connect motor hoist to fly-frame Connect the motor hoist(s) to the lifting point (and tilting point if applicable). V1.22 - 4 - Owners Manual SP20-Linex™...
  • Page 5 Step 3: Set the angles of the cabinets IMPORTANT: ALWAYS make sure the quick release pins are well in place and locked! Set the angles at the back of the cabinets and connect the audio-line V1.22 - 5 - Owners Manual SP20-Linex™...
  • Page 6 IMPORTANT: Do not stand in front of the array when hoisting! When cabinets are freed from the ground they may cause the array to swing forward. Lift the array out of the flightcase V1.22 - 6 - Owners Manual SP20-Linex™...
  • Page 7 Step 5: Connecting enclosure fronts Connect the fronts of the cabinet. Step 6: Set the angles at the back of the cabinets Set the angles at the back of the cabinets, connect the audio-lines and lift the array Continue from step 4 until the complete array is finished...

  • Page 8: Line-Array Basics

    Therefore, vertical directivity control and maximum SPL of the low and low-mid frequencies Fig.1 Typical characteristic of a 2 meter greatly benefit from a larger (longer) array array at 170 Hz. size. V1.22 - 8 - Owners Manual SP20-Linex™...

  • Page 9: Basic Configuration Principles

    – 6dB coverage area. This means they will hear less low-mid frequencies! This effect is most pronounced at large distances. In general one to three cabinets extra coverage for the furthest audience will be sufficient. V1.22 - 9 - Owners Manual SP20-Linex™...
  • Page 10 6 metres). Additionally, focussing the arrays at different panning angles will reduce comb filtering interaction since the overlap region is reduced. Last but not least, the ear cannot resolve tightly spaced comb filtering notches at higher frequencies throughout the overlap region. V1.22 - 10 - Owners Manual SP20-Linex™...

  • Page 11: Using Sound Projects Array Calculator (Sparc™)

    Using Sound Projects Array Calculator (SPArC™) To determine the optimum angle settings of the array elements, array position, expected SPL levels and other array configuration parameters SOUND PROJECTS has developed SPArC™; a pragmatic array calculation tool. Based on the venue parameters SPArC™ instantly calculates the most favourable line-array configuration and processor pre-set.

  • Page 12: Figure 4.1 Project Info Page Screenshot

    “on” the graph at the “Main interface” page corresponds with the manual angle settings (beside the pink areas). The auto settings can be copied to the manual settings, after which the auto settings can be “fine tuned” if preferred by the user. V1.22 - 12 - Owners Manual SP20-Linex™...
  • Page 13 Printing a page Any page of SPArC™ can be printed via the excel menu: file>print. V1.22 - 13 - Owners Manual SP20-Linex™...

  • Page 14: Electronic System Set-Up

    5.1 and figure5.2, consisting of one 2in-4out controller, one SP2600 for the HF and MF sections and one SP4600 amplifier for the sections powering three Linex™ cabinets. figure 5.1 Typical Linex™ block diagram V1.22 - 14 - Owners Manual SP20-Linex™...
  • Page 15 5.2 Linex™ connection example V1.22 - 15 - Owners Manual SP20-Linex™...

  • Page 16: Wiring And Connection

    General guidelines SOUND PROJECTS has configured several controller presets to cover any venue situation. These settings will deliver the most accurate frequency response at the audience areas. It is advised to use no or only minor EQ adjustments afterwards. One must be very precautious because, due to venue acoustics, the frequency response may differ remarkably between places.

  • Page 17: Table 5.3 Recommended Controller Settings For Linex

    SOUND PROJECTS has prepared a tenfold controller settings, which are available as presets for several recommended controllers available in the market today. The correct controller preset number can be selected with table 3.3. In addition SPArC™ can be consulted for the proper preset number.

  • Page 18: Power Amplifier Requirements

    2.1. However in some applications they can be over or underpowered. Proper amplifier selection requires a considered analysis for the particular application. Recommended amplifier power table for SP20-Linex 1 Cabinet 2 Cabinets...

  • Page 19: Table 5.5 Max. Rms Power Handling

    IEC 268-5 Power), only the latter two are real standards and therefore comparable. The other ways of specifying are more fanciful and therefore not serious. Sound Projects transducer power ratings are calculated based on minimum impedance (Z-min) and the RMS voltage of the relevant band-passed noise input signal.

  • Page 20: Table 5.7 Limiter Settings Example Table

    Threshold value and amplifier gain factor When you use the amplifiers supplied by Sound Projects they have a gain of 32 dBu. The gain factor of an amplifier is extremely important for the threshold value of the limiter! In table 2.6, the limiter parameters are listed in case of amplifiers with a gain of 32 dBu.

  • Page 21: Stacking And Flying With Easy-Rig

    The Sasy-rig™ flying system has been designed to set up acoustic vertical line-arrays in an easy, fast and flexible way. All the necessary cabinet rigging hardware is stored within the SP20-Linex housing. In general, the only additional requirements include an Sasy-rig™ fly-frame and tilt- bar, motor hoists, transport flight cases and qualified rigging personnel.

  • Page 22: Rigging Components

    6.2 SP20-LINEX enclosure with integrated flying hardware Flying Frame The Sasy-rig™ flying frame is designed to fly up to 24 SP20-LINEX enclosures in a ‘dead-hang‘ set-up. SPArC™, specially designed line-array software, automatically calculates the corresponding maximum number of cabinets for each situation submitted in the program and signals when weight load limits are exceeded.

  • Page 23: Figure 6.4 Quick Release Pins

    Quick release pins Each SP20-LINEX enclosure holds 6 quick release pins fixed to the enclosure rigging. The provided pins have a workload limit of 0,5T (S.F.10) per pin.
  • Page 24 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 Sasy-rig™ single hoist adapter WLL conversion table. V1.22 - 24 - Owners Manual SP20-Linex™...

  • Page 25: Preparing A Set-Up

    Store the enclosures in clusters of three in a flight-case and mark each flight-case with L for the left array and R for the right array plus the number of the cabinets in line. The SP20-LINEX transport flight case has truck-pack dimensions. Two flight cases (1.20m width) will tightly fit inside most trailers.

  • Page 26: General Set-Up Of A Flown Array

    A simple strap can be used to aim the array horizontally and keep the array from rotating. V1.22 - 26 - Owners Manual SP20-Linex™...
  • Page 27 Step 2: Lifting the first cluster of cabinets Rigging a complete array of SP20-LINEX can be significantly faster by lifting clusters of 3 cabinets at once for they are already connected in the flight-case during transport. Lift the fly-frame at the lifting-point together with the first 3 cabinets out of the flight-case.
  • Page 28 When cabinets are freed from the ground they may cause the array to swing forward. Lift the array while guiding the cluster of cabinets until it‘s completely freed from the flight-case. V1.22 - 28 - Owners Manual SP20-Linex™...
  • Page 29 Step 5: Connecting enclosure fronts Although a single person can set-up an entire rig of SP20-LINEX, the fastest setup is achieved by two persons on either side of the array. At the front of the enclosure two fixed connecting bars extend at the top.

  • Page 30: Setting Up A System With Limited Floor-Space

    When ground-stacking it does not matter if the enclosures are positioned up-side down. Also arcing the array backwards is still possible. Never ground stack more than 8 SP20-LINEX enclosures on a fly frame! V1.22 - 30 -...

  • Page 31: How To Determine The Maximum Number Of Cabinets In An Array

    All Sasy-rig™ rigging hardware is designed with a safety factor 10. This is well above the European safety standards as stated in the Guidelines for Machines. Local laws, however, may enforce higher safety factors and/or restrictions or demand other safety precautions. V1.22 - 31 - Owners Manual SP20-Linex™...
  • Page 32 V1.22 - 32 - Owners Manual SP20-Linex™...

  • Page 33: Additional Safety Guidelines

    Additional Safety Guidelines Before mounting the SP20-LINEX system make sure you apply the following general safety guidelines. Standards for flying and rigging are local not universal, therefore it is important for the user  to contact appropriate regulatory agencies concerning relevant standards for specific applications.

  • Page 34: Components And System Specifications

    Not recommended, only with 2 Ohm enabled amplifiers. These SPL values are for a single cabinet. A line-array of more cabinets will show higher SPL values at one meter. Especially low frequencies will be severally louder. V1.22 - 34 - Owners Manual SP20-Linex™...
  • Page 35 Horizontal isobars (one cabinet) Vertical isobars (one cabinet) Cabinet dimensions V1.22 - 35 - Owners Manual SP20-Linex™...

  • Page 36: Declaration Of Conformity

    Declaration of Conformity Hilversum, 1 October 2004 SOUND PROJECTS, hereafter referred to as the manufacturer, declares that the Easy-rig™ flying frame and its rigging hardware as supplied by the manufacturer are produced and, when provided with certificate, tested conform CE norms as described in the Guidelines for Machinery appendix 2A.
