BedJet 1222NA User's Operating Manual

Vet forced air animal warmer with remote control

Hide thumbs

Table Of Contents

IMPORTANT INSTRUCTIONS

USER OPERATING MANUAL – MODEL 1222NA/2222EU

VET Forced Air Animal Warmer

with Remote Control

This device is designed for animal and pet warming use only. It is not

for use in any human household or human medical application.

READ AND SAVE THESE INSTRUCTIONS

READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE,

INSTALL, OPERATE OR MAINTAIN THE PRODUCT DESCRIBED.

PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY

INFORMATION. FAILURE TO COMPLY WITH

INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR

PROPERTY DAMAGE!

RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.

Revision 1.0

P a g e | 1

Table of Contents

Need help?

Do you have a question about the 1222NA and is the answer not in the manual?

Questions and answers

Summary of Contents for BedJet 1222NA

Page 1 IMPORTANT INSTRUCTIONS USER OPERATING MANUAL – MODEL 1222NA/2222EU ® VET Forced Air Animal Warmer with Remote Control This device is designed for animal and pet warming use only. It is not for use in any human household or human medical application.
Page 2: Important Instructions
3. Make certain that the power source conforms to the electrical requirements of this device. 4. DO NOT OPERATE MORE THAN ONE BEDJET ON SAME AC-POWER OUTLET WITHOUT ADJUSTING DUAL MODE SWITCH LOCATED ON REAR OF DEVICE TO “DUAL ZONE ON, LOW POWER”...
Page 3 Arrange cord away from traffic area and where it will not be tripped over. 14. This device has hot and arcing or sparking parts inside. Do not use the BedJet in areas where gasoline, paint, or flammable liquids or flammable gases are used or stored. It must NOT be used in potentially dangerous locations such as flammable, explosive, chemical-laden or wet atmospheres.
Page 4: Manufacturer Information
IMPORTANT INSTRUCTIONS USER OPERATING MANUAL – MODEL 1222NA/2222EU 21. CAUTION — Some parts of this product can become very hot and cause burns. Particular attention has to be given where children and vulnerable people are present. 22. Heater must not be located immediately below a socket outlet.
Page 5: Pre-Installation Checklist
A23 alkaline battery Proper Assembly Required: All parts included are required to be fully assembled and installed onto the BedJet as part any operation. Do not operate the BedJet without the included Air Hose. Do not attempt to use the BedJet with air delivery accessories or air delivery components not approved or supplied by BEDJET LLC.
Page 6: System Operation
 Main power switch is located on rear of unit, directly below power cord. Switch unit on and wait 3 seconds. The unit will beep once and orange power light on BedJet display will light indicating ready for operation status.
Page 7 BEDJET REMOTE CONTROL SYNC TO BEDJET: The wireless remote control needs to be paired to your BedJet in order to correctly operate. This is normally done at the factor prior to delivery. If BedJet is powered on (verified by Power LED on BedJet display) and wireless...
Page 8 Bluetooth linked BedJet Veterinary App from your smartphone or tablet computer to unlock advanced features.  The BedJet main power switch (under the power cord) must be turned ON for the remote control to operate the BedJet. Once the power switch is ON, the BedJet will beep once and orange Power ON LED will light to indicate successful boot-up of the internal microcontroller.
Page 9 IMPORTANT INSTRUCTIONS USER OPERATING MANUAL – MODEL 1222NA/2222EU Operating Mode Summary Air Output Shutoff Max. BedJet Regulated Auto-Shutoff Timer Increase Auto-Shutoff Mode Display LED Temperature Time Default Remote Button Time Setting 109 °F +15 minutes High Heat 30 Minutes 4 Hours 43 °C...
Page 10 “Pair”. On following screen press Search, the local BedJet device should show up on the list. Press the device ID and the pairing should begin. The Bluetooth symbol on the BedJet Status Display will light once the Bluetooth link is active with your smart device.
Page 11: Maintenance
HEPA PREFILTER CLEANING: Clean the HEPA lifetime washable pre-filter every 2 months or when visually dirty. Press the round BedJet logo on top of the BedJet unit and pull air intake grill open to access filter, remove the black mesh filter from HEPA filter (it is attached to front of) HEPA filter with Velcro) and clean under running water.
Page 12: Thermal Safety
IMPORTANT INSTRUCTIONS USER OPERATING MANUAL – MODEL 1222NA/2222EU Thermal Safety The BedJet VET includes the most robust set of redundant safety features of any forced air animal warmer unit currently on the market to prevent unintentional overheating. These features include: ...
Page 13 USER OPERATING MANUAL – MODEL 1222NA/2222EU Certifications The BedJet VET has been designed to operate as a safe forced air heating extension for animal beds. This product has been rigorously tested by an accredited 3 party testing lab to be qualified as a safe electric appliance.
Page 14: Troubleshooting
USER OPERATING MANUAL – MODEL 1222NA/2222EU Troubleshooting Use this guide to address problems with your BedJet Product. If problems cannot be resolved, please contact Customer Service at info@bedjet.com or +1.401.404.5250. Do not return any product requiring service without first obtaining Return Authorization Number (RMA) and shipping instructions.
Page 15 IMPORTANT INSTRUCTIONS USER OPERATING MANUAL – MODEL 1222NA/2222EU Diagnose & Fix Issue Possible Causes Action Remote control will not   Dead battery in remote Make sure remote control LED lights operate BedJet when button pressed, if not then ...
Page 16: Warranty
God (such as a flood) is not covered. BEDJET LLC does not have any obligations if our inspection reveals that the product has been altered, modified, damaged, subjected to or involved in an accident, disassembled, repaired or attempted to be repaired by someone other than us, or used in a manner inconsistent with its intended purpose.

This manual is also suitable for:

2222eu
