  • Page 1 X-TORM 300...

  • Page 2: Operating Determinations

    CAUTION! Keep this device away from rain and moisture! Unplug mains lead before opening the housing! FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOU INITIAL START - UP! Introduction Thank you for having chosen a new moving head 250. You acquired a versatile, powerful and intelligent lighting-effect.
  • Page 3 Fitting/Exchanging the lamp Install the lamp with the device switched off only. Unplug from mains before!
  • Page 4 Adjust lamp position by turning lamp adjusting screws Lamp is hot! Risk of fire! Wait at least 15min. before opening the covers and removing lamp from the fixture. Disconnect the fixture from AC power before re-lamping. Protect hands and eyes. Maximum room temperature t=40°C Minimum distance from flammable material d=0,5m.
  • Page 5 DANGER OF FIRE! When installing the device, make sure there is no highly-inflammable materials within a distance of min. 0.5 m. CAUTION! Use 2 appropriate clamps to rig the fixture on the truss. Follow the instructions mentioned at the bottom of the base. Use 2 appropriate clamps to rig the fixture on the truss.
  • Page 6 Push slider up in order to move head vertically (TILT). Gradual head adjustment from one end of the slider to the other. The head can be turned by 280° and stopped at any position you wish. Channel 3 - rotating gobo-wheel 0 - 15 Open/hole 16-31...

  • Page 7: Control Board

    Control Board The Control Board offers several features: you can simply set the starting address, reset. The rowse through the menu by pressing the main menu is accessed by pressing the MENU and b Up-button. Press the Enter-button in order to select the desired menu. You can change the selection by pressing the Up-button.

  • Page 8: Technical Specifications

    Before replacing the fuse, unplug mains lead. Procedure: Step 1: Unscrew the fuse holder on the rear panel with a fitting screwdriver from the housing (anti-clockwise). Step 2: Remove the old fuse from the fuse holder. Step 3: Install the new fuse in the fuse holder. Step 4: Replace the fuse holder in the housing and fix it.
