Battery Pack - PowerSmith MAGLITHION MLMS12C Operator's Manual

• Do not attempt to use a step-up transformer,
receptacle.
• Do not short the battery pack.
Avoid storing battery pack in a container with other metal objects such as nails, coins, etc. Always
protect the battery terminals when battery pack is not used.
• Do not charge battery pack inside a box or container of any kind.
battery must be placed in a well ventilated area during charging.
• Do not allow anything to cover or clog the charger vents.
• Do not incinerate the battery pack even
out. The battery pack can explode in a fire.
• Disconnect Charger from the power source when not in use.
the risk to electric shock or damage to the charger if metal pieces should fall into the opening. It also
will help prevent damage to the charger during a power surge.
WARNiNG:
possible burns and even a breakdown
WARNiNG:
conductive objects. Electric shock or electrocution may result. Do not allow any
liquid to get inside charger. Electric shock may result.
OPERATiON
NOTE:
Always Check that the power supply corresponds to the voltage on the
ratings plate on your charger.
CHARGER
CHARGING WITH THE DIAGNOSTIC CHARGER
NOTE:
Newly purchased batteries are not fully charged and must be charged
before using in your cordless tool(s).
1. Plug the battery charger into the proper AC voltage source. A steady GREEN light will illuminate
indicating charger is connected to a proper power source.
2. Insert the battery pack so that the ribs on the battery pack slide into the grooves on the battery charger.
Insert the battery pack fully into the charger.
3. When the battery pack is inserted, the GREEN charging light will flash indicating the charger has started
the charging cycle. A steady GREEN light indicates the battery is completely charged and should be
removed from the charger.
A battery short can cause a large current flow, overheating,
120 volts are present at charging terminals, do not probe with
English
an engine generator or DC power
Do not touch the terminal with any conductive material.
if it is severely damaged or is completely worn
.
11
This will reduce

BATTERY PACK

GREEN LiGHT
RED LiGHT
The
