Summary of Contents for Eurolec 720ELSS
- Page 1 720ELSS Electric Double Oven & Grill User & Installation Instructions...
-
Page 2: Table Of Contents
Contents User’s Section ........2 - 23 Introduction . -
Page 3: User's Section
Introduction We hope that the following information Your 70cm electric oven is designed to will help you to familiarise yourself be installed underneath a worktop, with the features of the appliance, and either into a housing unit, or between to use it successfully and safely. base units. - Page 4 Introduction Cooling fan To replace an oven light bulb The cooling fan helps to keep the Caution: Switch off the electricity exterior cool during normal use. supply to the appliance, to avoid the When an element is operated, you risk of electric shock. should hear the cooling fan switch on Wait until the oven is cool, then automatically and be able to feel air...
-
Page 5: Be Safe - Not Sorry
Be Safe - Not Sorry When you are cooking, keep l Using aluminium foil to cover the children away from the vicinity grill pan, or putting items wrapped of the appliance. in foil under the grill creates a fire hazard. The high reflectivity can l This product is designed as a also damage the element. -
Page 6: Using The Grill
Using the Grill Caution: Accessible parts may Detachable grill pan handle be hot when the grill is used, grid young children should be kept away. To switch on the grill Open the top oven / grill door. Turn the grill control fully clockwise to select either the full grill setting or economy grill setting. - Page 7 Using the Grill Using the grill Using aluminium foil to cover the grill pan, or putting items wrapped in foil The temperature of each grill setting is under the grill creates a fire hazard, fixed. Grilling can be adjusted by and the high reflectivity can damage selecting a higher or lower shelf the grill element.
-
Page 8: Using The Top Oven
Using the Top Oven Caution: Accessible parts may Notes: be hot when the oven is used, C a u t i o n : The top element gets young children should be kept extremely hot when in use, so take away. -
Page 9: Top Oven Baking Guide
Using the Top Oven Top oven baking guide Cooking temperatures Because the top oven is more compact Cooking times it may be necessary to reduce the The cooking times given in the following cooking temperatures specified in guide are based on a preheated oven, if recipes by up to 20˚C. -
Page 10: Using The Main Oven
Using the Main Oven Caution: Accessible parts may To help the air to circulate freely be hot when the oven is used, l Position the shelves evenly within young children should be kept the oven and maintain a clearance away. from the oven roof and base. -
Page 11: Cooking With A Fan Oven
Using the Main Oven Cooking with a fan oven Defrosting and cooling If you are used to cooking with a To defrost frozen foods, turn the conventional oven, you will find a oven control to the defrost position, number of difference to cooking with a place the food in the centre of the oven fan oven, which will require a different and close the door. -
Page 12: Main Oven Baking Guide
Using the Main Oven Main oven baking guide Because a fan oven has an even temperature throughout the oven, no The cooking times given below are only shelf positions have been given, approximate, because the size and type and there is no need to interchange of cooking dish will influence cooking dishes onto different shelves part times, as will personal preference. -
Page 13: Oven Furniture
Using the Ovens Oven furniture Aluminium foil Use foil only to cover food or cooking dishes. Do not use foil to cover the Baking tray and roasting tins shelves or oven base, as this creates a For best cooked results and even fire hazard. -
Page 14: Traditional Fruit Cakes
Using the Ovens Traditional fruit cakes Roast turkey It should be remembered that ovens Roasting turkey perfectly involves can vary over time, therefore cooking cooking two different types of meat - times can vary, making it difficult to be the delicate light breast meat, which precise when baking fruit cakes. -
Page 15: Roasting Guide
Using the Ovens Roasting guide Notes; The times given in the roasting guide l When cooking stuffed meat or are only approximate, because the poultry, calculate the cooking time size and age of the bird will influence from the total weight of the meat cooking times as will the shape of a plus the stuffing. -
Page 16: Automatic Cooking In The Main Oven
Using the Ovens Automatic cooking in the main oven Do not The automatic cooking facility is l Warm food should never be controlled by the programmer (see placed in the oven if there is a ‘Programmer/ Clock’ section) and allows delay period. -
Page 17: Using The Ovens
Using the Ovens Important: Food is more susceptible Hints for automatic cooking to the growth of food poisoning l Food is placed in a cold oven so organisms in warm conditions. If the you will need to add about 10 - weather is hot, either take care to 15 minutes onto the cooking time ensure that food is not left standing in... -
Page 18: Programmer / Clock
Programmer / Clock The Programmer Buttons Manual operation minute minder cook time ready time minus plus To set the programmer to manual operation at any time (cancelling any automatic setting), press the cook time a n d To set the “Time of Day” ready time buttons simultaneously. - Page 19 Programmer / Clock Semi-automatic cooking ( e x a m p l e ) 1. A (Auto) symbol appears. You have started cooking a meal or dish in the oven, and want to set the time for the oven to switch off. Press the cook time button, then use the p l u s and m i n u s buttons to set the display to show the length of cooking...
- Page 20 Programmer / Clock Fully automatic cooking ( e x a m p l e ) For use when a delayed start time is required. You want to set the length of cooking 5. A (Auto) symbol appears. t i m e, and the time for the oven to switch o f f.
- Page 21 Programmer / Clock The oven will automatically switch off 9. A (Auto) symbol will flash. at 18.00 hours (6.00 pm) and the alarm will sound (9). To switch off the alarm press the minute minder button (10). When the oven has switched off, 11.
-
Page 22: Cleaning
Cleaning C a u t i o n : Any cleaning agent Vitreous enamel parts used incorrectly may damage GRILL PAN MAIN OVEN BASE TOP OVEN the appliance. GRILL COMPARTMENT Always let the appliance cool Use a mild cream cleaner - eg; “Cif”. before cleaning. - Page 23 Cleaning Stainless steel surfaces (stainless steel finish models only) FACIA PANEL HANDLES Only use a clean cloth wrung out in hot soapy water, and dry with a soft cloth. Stubborn marks can be removed using “Luneta”. We recommend that you clean the whole of the stainless steel area to maintain a uniform finish.
- Page 24 Cleaning Glass parts Important: if the inner door glass panel is removed for cleaning, it must & FACIA PANEL DOOR PANELS be replaced the right way up as Use a mild cream cleaner - eg; “Cif”. shown, and pushed fully in to the Rinse thoroughly and dry with a soft stop position.
-
Page 25: Installation
Installation Instructions Before you start - please read the If this appliance is to be installed near to a instructions carefully - planning your corner where the adjacent cabinets run at installation will save you time and effort. right angles forward of the appliance, there must be a gap of at least 90mm Look at the different ways the appliance between the appliance and the cabinets,... -
Page 26: Installation Instructions
Installation Instructions Method 1: Without housing unit 1. Take the 6 No 8 x 12mm (silver) (between 2 base units) self tapping screws from the polythene bag, and use them to fit Before installing the appliance, check one runner to each side of the the internal dimensions as shown. - Page 27 Installation Instructions Method 1: Without housing unit (between 2 base units) Shown with fixing kit min 550mm 598 - 602mm 710mm sidetrim runners 50mm...
- Page 28 Installation Instructions Method 1: Without housing unit (between 2 base units) Shown without fixing kit min 550mm 598 - 602mm sidetrim...
- Page 29 Installation Instructions Method 2: Housing unit with To fix the runners (if required) internal height less than 710mm. 1. Take the side trims, hold it against Note: You will not need the 2 side the side of the base unit, and use trims (687mm long) or the appliance it to mark off the 687mm from the runners for this installation.
- Page 30 Installation Instructions Method 2: Housing unit with internal height less than 710mm Shown with fixing kit min 550mm 560 - 570mm 710mm runners 50mm...
- Page 31 Installation Instructions Method 2: Housing unit with internal height less than 710mm Shown without fixing kit min 550mm 560 - 570mm...
- Page 32 Installation Instructions Method 3: Housing unit with Remove any fixings that may prevent internal height of 710mm or more. entry of the oven into the housing. The cabinetry should be kept structurally Note: You will not need the 4 runners sound by fixing to adjacent cabinets, and 2 trims that are packed with the floor or worktop.
-
Page 33: Step 2: Connect To Electricity Supply
Installation Instructions Step 2: Connect to the electricity Step 3: Check edging strip supply The edging strip is factory fitted to Warning: This appliance must be the front side edges of the appliance earthed. front frame. This strip provides the c a b i n e t r y with extra protection from 1. -
Page 34: Step 4: Secure Appliance Into Housing Unit
Installation Instructions Step 4: Secure appliance into Step 5: Installing a hob above housing unit the appliance Where the appliance is installed under Note: The unit housing the appliance a worktop, with a hob installed above must be appropriately fixed. it, the installation instructions for the Method 1: Care must be taken to hob must be read in conjunction with... -
Page 35: Technical Data
Technical Data Electrical supply 220 - 240V ~ 50Hz Element ratings at 230V Dual Grill 1655 / 2575W Top Oven 1300W Main Oven 2300W Main oven stir fan Lights (1 each oven) 2 x 25W Cooling fan Maximum load 4990W... -
Page 36: Customer Service
Customer Service In case of difficulty please call the Customer Service Helpline on 01245 321111 Enter appliance numbers here for future reference: Model No Serial No Please ensure you have the above details (Model No and Serial No) to hand when calling Customer Service. from Premium Appliance Brands Limited Cranage House, 730 Mandarin Court, Centre Park, Warrington, WA1 1GG...
