i-gatU Q-Band X Q 62 User Manual

Q-62

Device Overview

Wristband

How to wear your Q-Band X?

1
Wear Q-Band X on your wrist
Put on the wristband with the screen facing up and the band
wrapped around your wrist. Align the clasp along the band to
find the holes where best fit the clasps.
3
Charge your Q-Band X
1
To charge your Q-Band X, place it in the charging box at the
other end of the USB cable. Close the box afterwards, and
make sure the Q-Band X is securely covered. Plug the USB
connector to either a PC or power adapter to start charging.
Q-Band X
Button
2
3
Core
Metallic contact for charging
2
Fasten Q-Band X with clasp
Squeeze both clasps into the holes on the wristband until you
hear a click, indicating the band is securely fastened.
4
Change the wristband
1
2
1. Spread open both bands with the screen facing up, and press down
the screen with your thumb until the core comes off the wristband.
Insert the core with screen facing up into the notch from below the
2.
wristband. Button up the clasp on the side of the band with 2 holes.
Please note that the charging contact should be near the clasp.
EN
User Manual
Clasp
