Battery
Your Agent 00Funk Mark II operates from a single 9V
battery. We recommend you use a long-life alkaline type.
Since the Agent 00Funk Mark II draws power while the input
plug is connected, you should remove the input plug when not
in use to prolong battery life.
Replace your battery if the LED does not light brightly or if the
output distorts easily. You may also find you need to turn up
the pitch control a little as your battery runs out.
To install a battery:
1
Loosen the battery drawer thumbscrew.
2
Slide the battery drawer out.
3
Attach the battery clip to the battery.
Insert the battery into
4
the drawer with the
battery clip inside the
unit as shown.
5
Push the back end of the
battery down until it clips
snugly into the drawer as
shown.
6
Slide the battery drawer in.
7
Tighten the battery drawer thumbscrew.
External power supply
You can also run your Agent 00Funk Mark II from an external
plugpack or other voltage source plugged into the 2.1mm tip-
negative 9vdc socket. A 9V DC regulated supply is required
but almost any current rating will do since it draws less than
50 mA. While a plug is inserted into the 9vdc socket the
battery, if installed, is disconnected. To prevent damage to
your pedal, please ensure you have the voltage and polarity
correct before plugging in an external power supply.
Connections
To use your Agent 00Funk Mark II by itself, connect a lead
from your instrument to the input socket, and a lead from the
output socket to your amplifier. However, when you have
other effects before the Agent 00Funk Mark II in the signal
chain, especially fuzz or distortion, you should use the
envelope input for squelchier results.
The Chunk Systems Brown Dog gated bass fuzz pedal
operates with the Agent 00Funk Mark II to create some
crazy synth tones. It has an envelope output and is best
connected to the Agent 00Funk Mark II as shown:
You can also use a splitter cable as shown to use the
envelope input with other pedals. This is equivalent to the
effects loop found on some other envelope filters.
