OMEZ LIGHTING titanbeam 7R User Manual

230w moving head beam
Hide thumbs

Advertisement

Table of Contents

Enlarged version
Introduction
Thank you for purchasing the OMEZ TitanBeam™ 7R. This moving head
fixture characterized by its exceptional bright light beam is a new product
in the Titan Line. This light weight fixture is CE compliant and has a
perfect combination of advanced electronic controlling technology with
TitanBeam™ 7R
standard DMX 512 control. Programing is a breeze on the fixture's touch
screen panel.
OMEZ TitanBeam™ 7R has a 230 watt discharge lamp with reflector that
User Manual
projects a high quality long range beam of light. With 5 high quality step
motors you can pan, tilt, and focus with fast Smooth precision.
OMEZ TitanBeam™ 7R features; one color wheel with 14 colors plus
open and one gobo wheel with 17 static patterns. Added to the 7R is the
pulse feature a steady, longer, and smoother shutter effect. This small
light weight fixture is designed for easy transport for mobile DJ's, VJ's,
KJ's, and Production companies.
OMEZ TitanBeam™ 7R is the industry standard in T.V. reality shows,
Arenas, Concert halls, Banquet halls, Performing arts theaters,
Nightclubs, and Entertainment venues.
Omez Guaranty
This TitanBeam™ 7R has met all quality control requirements when tested
230W Moving Head
in our factory and is known to be in perfect condition when shipped to our
Beam
warehouse in El Monte California. In order to ensure the safe operation of
this TitanBeam™ 7R it is absolutely necessary for the end user to follow
the safety instructions and warnings notes written in this user manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the titanbeam 7R and is the answer not in the manual?

Questions and answers

Summary of Contents for OMEZ LIGHTING titanbeam 7R

  • Page 1 Introduction Thank you for purchasing the OMEZ TitanBeam™ 7R. This moving head fixture characterized by its exceptional bright light beam is a new product in the Titan Line. This light weight fixture is CE compliant and has a perfect combination of advanced electronic controlling technology with TitanBeam™...

  • Page 2: Table Of Contents

    Contents 2 Safety Information Introduction/Omez Promise …... ……….………………..1 …………………….………..2 Safety information ………………………………3 Included in package Features ..…………………….……….4 ……………………………….5 Control panel DMX Channels .………………………………6 Installation ...…………………………….7 .……………………………….8 Cleaning & maintenance (Before plugging in fixture, Please read manual)

  • Page 3: Included In Package

    3. Included In Package This box includes items listed below Accessories UNIT User manual Warranty card Suspension fasteners DMX cable  4. Features   Modes: 16/20 Channels  Lamp Type: 230w YODN Bulb  Color Temperature: 8000K  Luminance: 63900 @ 20m ...

  • Page 4: Control Panel

    5. Control panel 5.3 Settings Tab 5.1 Panel Instructions Option Instruction Functions (slave mode) Receive a DMX signal from controller or master fixture Operation Left arrow and Right arrow: exit current screen, push twice it will take you back to home screen (master mode) Auto run1-2-3-4, send DMX signal Mode to slave...
  • Page 5 5.5 Manuel Tab Display On/Off On turns off display after 60 sec. On the home screen touch the manual tab scroll up and down to get to your desired field press ok to enter and make Light turns on with fixture Lamp On changes.

  • Page 6: Dmx Channels

    5.6 Advance Tab 6. DMX Channels On the home screen touch on the advance tab, press the up and down tab continues twice then ok. Channel Standard mode(16CH) 16Bit mode(20CH) Option Instruction Scroll “Up” or “Down” press ok to Color Wheel Color Wheel Sensor Monitor enter field...
  • Page 7 6.2 Strobe 6.1 Colors Standard 16Bit Channel Value Function Standard 16Bit Channel Value Function mode mode function mode mode function Close Open 10-19 4-103 Strobe Slow-Fast 20-29 Yellow 104-107 Open 30-39 Blue Strobe 108-207 Pulse Slow-Fast 40-49 Green Strobe 208-212 Open 50-59 Hot Pink...
  • Page 8 6.4 DMX Channels & Values Standard 16Bit Channel Value Function Standard 16Bit Channel Value Function mode mode function mode mode function Gobo 1 Shake Fast Open Gobo 2 Shake Slow Gobo 1 …… …………… 10-14 Gobo 2 15-19 Gobo 3 Gobo 2 Shake Fast ……..

  • Page 9: Installation

    Standard 16Bit Channel Value Function mode mode function 0-127 No Frost 7. Installation Frost 128-255 Frost Focus 0% Mounting the fixture in areas away from reach by unauthorized … …. Focus personal is always recommended. Before mounting the fixture make sure that the area you are using can hold a minimum Focus 100% load of 5x the Fixtures weight.
  • Page 10 Omez Lighting reserves the right to make changes and/or improvements in design upon its products without any obligation to include these changes to any products theretofore manufactured. OMEZ...
