Formosa Napoli BF Installation, Maintenance & User Instructions

Coal effect balanced flue gas fire
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Napoli BF
COAL EFFECT BALANCED FLUE GAS FIRE
Installation, Maintenance & User Instructions
Hand these instructions to the user
Model No. ABFC**MN2 & ABFC**EN3 are for use on Natural Gas (G20) at a
supply pressure of 20 mbar in G.B. / I.E.
Model No. ABFC**MP2 is for use on Propane Gas (G31) at a supply pressure
of 37 mbar in G.B. / I.E.
** denotes trim / fret or fascia variant

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Napoli BF and is the answer not in the manual?

Questions and answers

Related Manuals for Formosa Napoli BF

Summary of Contents for Formosa Napoli BF

  • Page 1 Napoli BF COAL EFFECT BALANCED FLUE GAS FIRE Installation, Maintenance & User Instructions Hand these instructions to the user Model No. ABFC**MN2 & ABFC**EN3 are for use on Natural Gas (G20) at a supply pressure of 20 mbar in G.B. / I.E.

  • Page 2: Table Of Contents

    CONTENTS PAGE Section 1 Information and Requirements Appliance Information Conditions of Installation Fireplace surround & suitability Flue Terminal Position Shelf position Hearths Section 2 Installation of Fire Unpacking the fire Fireplace opening Preparation of the wall Preparation of the flue hole Installation of the gas supply Preparation of the flue duct Securing the firebox to the opening...

  • Page 3: Information And Requirements

    SECTION 1 INFORMATION AND REQUIREMENTS APPLIANCE INFORMATION Natural Gas Main injector : (1 off) 1.65mm (MC) 1.20mm (MC) 1.8mm (EFC) Pilot Type - S.I.T.140 Series Size 27 Size 19 Max. Gross Heat Input : 4.6kW 4.8kW Min. Gross Heat Input : 3.2kW 3.4kW 0.427 m 3 /hr...

  • Page 4: Conditions Of Installation

    INSTALLATION REQUIREMENTS Efficiency Declaration The efficiency of this appliance has been measured as specified in BS EN 613 : 2001 and the result is 85%. The gross calorific value of the fuel has been used for this efficiency calculation. The test data from which it has been calculated has been certified by BSI. The efficiency value may be used in the UK Government’s Standard Assessment Procedure (SAP) for energy rating of dwellings.

  • Page 5: Flue Terminal Position

    FLUE TERMINAL POSITION The minimum acceptable dimensions from the flue terminal to obstructions and ventilation openings are shown below and listed in the table It is important that the position of the flue allows the free passage of air across it at all times. The minimum acceptable space from the flue terminal to obstructions and ventilation openings are specified below in figure 2.

  • Page 6: Shelf Position

    SHELF POSITION The fire may be fitted below a combustible shelf providing there is a minimum distance of 200mm above the top of the fire and the shelf does not project more than 150mm. If the shelf overhangs more than 150mm the distance between the fire and the shelf must be increased by 15mm for every 25mm of additional overhang over 150mm.

  • Page 7: Fireplace Opening

    FIRE PLACE OPENING 2.2.1 The front opening of the fire place must be between 410 and 420mm wide, and between 563 and 570mm high. If the opening exceeds these dimensions then a surround must be constructed from suitable non- combustible material to produce a suitable sized opening. Any surround must be suitably sealed to the fire place to prevent leakage.

  • Page 8: Preparation Of The Wall

    2.2.3 NOTE : WHEN MEASURING LENGTH BETWEEN FIREBOX AND THE OUTER WALL TAKE INTO ACCOUNT THE DISTANCE BETWEEN THE BACK OF THE FIREBOX AND THE INNER WALL AS THIS WILL VARY BETWEEN INSTALLATIONS, DEPENDENT UPON THE FIRE SURROUND REBATE OR CAVITY DEPTH. (DIMENSION “X” BELOW - FIGURE 5).

  • Page 9: Preparation Of The Flue Hole

    Fig. 6 150mm diameter 423mm PREPARATION OF THE FLUE HOLE 2.4.1 Mark the position of the centre of the flue on the inner wall. 2.4.2 Cut hole for outer flue pipe. There are two possible methods to achieve this, either core drill or via hammer and chisel. 2.4.3 To core drill, proceed as follows :- Drill a pilot hole through the wall, in position as specified in figure 6.

  • Page 10: Installation Of The Gas Supply

    INSTALLATION OF THE GAS SUPPLY 2.5.1 Before installing the firebox, decide from which side or if a rear connection to the gas supply is required. Plan the pipe run to enter the firebox from the left, right or rear and connect to the inlet elbow. See below :- 2.5.2 If concealed pipe work is required plan the pipe run to enter the fire box...

  • Page 11: Preparation Of The Flue Duct

    PREPARATION OF THE FLUE DUCT 2.6.1 Place the firebox into the fire opening with fire surround correctly secured in the final position. From the outside of the house measure from the face of the outside wall to the rear panel of the firebox through the flue hole.

  • Page 12: Securing The Firebox To The Opening

    SECURING OF FIREBOX TO THE OPENING 2.7.1 There is a choice of methods of fixing the firebox that are provided to enable the installer to deal with any type of installation. The preferred method of fixing the appliance is the cable fixing method, which is described in detail in the following section.

  • Page 13: Making The Gas Connection

    2.7.8 To improve access to tension the screws it may be advantageous to remove the control panel from the fire. To do this, remove the 4 off retaining screws and on MC models, remove the control valve retaining nut. 2.7.9 Thread a tensioning screw over both of the cables and ensure that the tensioning nut is screwed fully up against the hexagon shoulder of the tensioning screw (this provides maximum travel for the tensioning nut).

  • Page 14: Fitting The Terminal Guard

    In England & Wales, building regulations require that a terminal guard should be fitted if the terminal could come into contact with people near the building or be subject to damage. Formosa Fires also recommend the fitting of a flue terminal guard where regulations do not demand that it be fitted.

  • Page 15: Removal & Refitting Of The Glass Frame

    2.10 REMOVING & REFITTING OF THE GLASS FRAME. 2.10.1 Remove the 2 screws which hold the convection slot cover to the firebox, as shown below in figure 11. 2.10.2 Remove the burner heat shield by unscrewing the 2 off retaining screws as shown below in figure 11.

  • Page 16: Assembling Fuel Bed And Commissioning

    SECTION 3 ASSEMBLING FUEL BED AND COMMISSIONING FITTING THE FUELBED 3.1.1 Place the ceramic fibre support behind the burner as shown below in figure 12. Fig. 12 3.1.2 Place the front right coal moulding onto the front coal support as shown below in figure 13.
  • Page 17 3.1.3 Place the front left coal moulding onto the front coal support as shown below in figure 14. Fig. 14 Left Front Coal Moulding 3.1.4 Place the upper right coal moulding as shown below in figure 15. This moulding tucks under the front right coal moulding and is supported by the ceramic fibre support.

  • Page 18: Fitting The Trim

    3.1.5 Place the upper left coal moulding as shown below in figure 16. This moulding tucks under the front left coal moulding and is supported by the ceramic fibre support. Fig. 16 Upper Left Coal Moulding 3.1.5 Refit the glass frame as detailed in section 2.10, then light the appliance as detailed in section 3.4 to 3.7 To ensure that the release of fibres from these R.C.F (Refractory Ceramic Fibre) articles is kept to a minimum, during installation and servicing we...

  • Page 19: Lighting The Appliance (Mc Variants)

    LIGHTING THE APPLIANCE - MANUAL CONTROL VARIANTS IMPORTANT NOTE : IF THE BURNER IS EXTINGUISHED FOR ANY REASON YOU MUST ENSURE THAT YOU WAIT A FULL FIVE MINUTES BEFORE ATTEMPTING TO RE-LIGHT THE FIRE. WHEN TURNING THE FIRE “OFF” PLEASE ENSURE THAT THE CONTROL VALVE IS TURNED TO THE “OFF”...

  • Page 20: Fitting The Batteries (Remote Control & Efc Models)

    IMPORTANT NOTE : THE BATTERIES SHOULD BE REPLACED WITH GOOD QUALITY ALKALINE BATTERIES WHEN REQUIRED, THE BATTERY LIFE IS EXPECTED TO BE A MINIMUM OF 12 MONTHS WITH NORMAL USAGE. FOR BEST PERFORMANCE Formosa Fires RECOMMEND THE USE OF ENERGIZER BATTERIES WITH ITʼS PRODUCTS.

  • Page 21: Lighting The Fire Manually Via The Control Valve (Remote Control & Efc Models)

    3.5.4 For easy flame control operation please see section 3.7 LIGHTING THE FIRE MANUALLY VIA THE CONTROL VALVE 3.6.1 These products can be operated manually by using the buttons directly on the fire control in addition to the EFC switch (should the need arise). To operate the fire press and hold the “power”...
  • Page 22 LIGHTING THE APPLIANCE - EASY FLAME CONTROL MODELS. 3.7.1 To light the fire using the EFC switch press and hold the power button continuously until the red light illuminates next to the operation symbol (this typically takes two seconds). As the red light illuminates release immediately the power button.
  • Page 23 3.7.5 If you are not intending to use the fire for a long period (i.e. over the summer months) the battery life can be extended by sliding the power isolator switch to the left (to the “0” position away from the “1” position) on the valve itself, which is located behind the ashpan cover on the fire.

  • Page 24: Maintenance

    Servicing Notes Servicing should be carried out annually by a competent person such as a GAS SAFE registered engineer. It is a condition of the Formosa Fires guarantee schemes that this is carried out by a competent person i.e a GAS SAFE registered Engineer in accordance with these servicing notes.

  • Page 25: Removal Of The Control Valve (Mc Variants)

    Removing the control valve from the fire (manual control models only) 4.3.1 Remove ash-pan, fret assembly / trim or fascia from the front of the fire. 4.3.2 Isolate the gas supply, remove the glass frame as shown on in section 2.10 then remove the ceramics.

  • Page 26: Removal Of The Control Valve (Efc Variants)

    Removing the control valve (EFC models) 4.5.1 Remove ash-pan, fret assembly / trim or fascia from the front of the fire. 4.5.2 Isolate the gas supply, disconnect the gas control valve to bulkhead pipe and pilot connection to the valve at the pilot burner. Disconnect the ignition wire and thermocouple from the pilot.

  • Page 27: Parts Shortlist

    Parts Shortlist Replacement of parts must be carried out by a competent person such as a GAS SAFE registered gas installer. The part numbers of the replaceable parts are as follows, these are available from BFM Europe, contact details as shown on the back page of this book.

  • Page 28: Installation Information / About Your Fire

    This should be considered when installing or decorating. The Model number of this appliance is as stated on the rating plate affixed to the control panel of the fire and the appliance is manufactured by:- Formosa Fires.
  • Page 29 ABOUT YOUR NEW FORMOSA FIRES NAPOLI GAS FIRE The Formosa Fires Napoli balanced flue coal effect gas fire incorporates a unique and highly developed fuel bed which gives the realism of a loose coal layout combined with realistic flames and glow. The use of durable ceramic material in the construction of the fuelbed components ensures long and trouble free operation.

  • Page 30: Operating Your Fire (Mc Variants)

    OPERATING THE FIRE (MANUAL CONTROL MODELS) 5.2.1 The controls are located behind the ashpan cover which is situated behind the ashpan / fender. The controls, comprise a control valve to adjust the gas flow and a push button piezo igniter. To light the fire proceed as follows:- 5.2.2 Depress the control knob and turn anti-clockwise to the position...

  • Page 31: Operating Your Fire (Efc Variants)

    OPERATING THE FIRE - EASY FLAME CONTROL MODELS. 5.3.1 To light the fire using the EFC switch press and hold the power button continuously until the red light illuminates next to the operation symbol (this typically takes two seconds). As the red light illuminates release immediately the power button.

  • Page 32: Manual Operation Of Efc Models

    MANUAL OPERATION OF EASY FLAME CONTROL MODELS 5.4.1 These products can therefore be operated manually should the need arise. The control valve is located at the base of the fire as shown below in figure 2. Fig. 2 Position of battery cover on control valve Ensure that the power isolation switch is in position “1”...

  • Page 33: Replacing The Batteries On Efc Models

    5.5.2 Remove the battery cover and replace the 3 off AA batteries with good quality Alkaline items, Formosa Fires recommend the use of “Energizer” batteries. It is important that only an alkaline battery is used, otherwise premature battery failure and leakage may result.

  • Page 34: Removal / Replacing The Glass Frame

    REMOVAL / REPLACING THE GLASS FRAME 5.6.1 Remove the 2 screws which hold the convection slot cover to the firebox, as shown below in figure 4. 5.6.2 Remove the burner heat shield by unscrewing the 2 off retaining screws as shown below in figure 4. 5.6.3 Remove the 4 off retaining nuts as shown below in figure 4.

  • Page 35: Removal / Replacing The Fuel-Bed

    REMOVING / REPLACING THE FUELBED 5.7.1 Remove the trim, fret & ashpan or fascia. Remove the glass frame assembly as shown in section 5.6. Place the ceramic fibre support behind the burner as shown below in figure 5. Fig. 5 5.7.2 Place the front right coal moulding onto the front coal support as shown below in figure 6.
  • Page 36 5.7.3 Place the front left coal moulding onto the front coal support as shown below in figure 7. Fig. 7 Left Front Coal Moulding 5.7.4 Place the upper right coal moulding as shown below in figure 8. This moulding tucks under the front right coal moulding and is supported by the ceramic fibre support.
  • Page 37 5.7.5 Place the upper left coal moulding as shown below in figure 9. This moulding tucks under the front left coal moulding and is supported by the ceramic fibre support. Fig. 9 Upper Left Coal Moulding 5.7.6 Refit the glass frame as detailed in section 5.6, then light the appliance as detailed in section 5.2 / 5.3 / 5.4 To ensure that the release of fibres from these R.C.F (Refractory Ceramic Fibre) articles is kept to a minimum, during installation and servicing we...

  • Page 38: Cleaning The Fire / Cleaning The Glass Panel & Fuel-Bed

    Any damaged parts must be replaced by contacting your dealer or telephoning Formosa Fires on the number stated on the rear cover of this book. The coals must only be replaced with a complete and genuine replacement set and the fire must never be run with the wrong number or damaged coals.
  • Page 39 Due to our policy of continual improvement and development the exact accuracy of illustrations and descriptions contained in this book cannot be guaranteed. TROUBLE SHOOTING ADVICE FOR ELECTRONIC FIRE CONTROL MODELS PRIOR TO REQUESTING A SERVICE CALL Please locate the Indicator light on the control valve behind the ashpan cover (see figure 3 on page 32), if it shows any of the following flashing sequences then the problem requires the batteries in the control valve changing, be advised that service calls as a result of batteries requiring being changed in the product are chargeable.
