Northern Industrial Tools 15258 Owner's Manual

10 " bench grinder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
10 "
BENCH GRINDER
OWNER'S MANUAL
WARNING:
Read carefully and understand all INSTRUCTIONS before
operating. Failure to follow the safety rules and other basic
safety precautions may result in serious personal injury.
Item # 15258

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 15258 and is the answer not in the manual?

Questions and answers

Related Manuals for Northern Industrial Tools 15258

Summary of Contents for Northern Industrial Tools 15258

  • Page 1 10 " BENCH GRINDER OWNER'S MANUAL WARNING: Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item # 15258...

  • Page 2: Intended Use

    Thank you very much for choosing a NORTHERN TOOL + EQUIPMENT CO., INC. Product! For future reference, please complete the owner's record below: Model: _______________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it.

  • Page 3: Electrical Safety

    • Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control, so visitors should remain at a safe distance from the work area. • Be aware of all power lines, electrical circuits, water pipes and other mechanical haz- ards in your work area, particularly those hazards below the work surface hidden from the operator's view that may be unintentionally contacted and may cause personal harm or property damage.

  • Page 4: Personal Safety

    • Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock. • Do not let your fingers touch the terminals of plug when installing to or removing from the outlet.
  • Page 5 • Use only accessories that are recommended by the manufacturer for your model. Accessories that may be suitable for one tool may create a risk of injury when used on another tool. • Keep guards in place and in working order. •...
  • Page 6 Eye Shield Assembly Step 1: Attach the eye shield assembly to the shield supports(#38) using bolts(#39), eye shields(#37), spring washer(#22), washer(#23), nut(#24), as shown in Figure 2. Step 2: Remove the bolt(#33), spring washer(#22), washer(#23), nut(#24) from the wheel cover. Step 3: Align the EYE SHIELD Assembly with holes and replace the WHEEL COVER BOLT and NUT.

  • Page 7: Operation

    Figure 3 Step 3: Place the outside WHEEL MOUNTING WASHER (#30) on the SPINDLE with its concave side facing in. Step 4: Place the WHEEL MOUNTING NUT (#31) on the SPINDLE and tighten. Caution: Do not over tighten the WHEEL MOUNTING NUT as it may crack the GRINDING WHEEL.

  • Page 8: Maintenance

    General operation Step 1: Obtain a tray that is large enough for the workpiece to fit into, fill it with water and place it near the Bench Grinder. Step 2: Turn the Bench Grinder on. Step 3: Once the GRINDING WHEEL has reached full speed, bring the workpiece up to the wheel gently and without jarring.

  • Page 9: Diagram & Parts List

    DIAGRAM & PARTS LIST PARTS LIST End Closure Bearing Spring Washer Rotor Assembly Stator Assembly Right inner Guard Cable Right Tool Rest Strain Relief Grinding Wheel Washer Capacitor Gringding Wheel Sheath Capacitor Clip 10 Base Plate Grinding Wheel Washer Outer Guard 14 Spring Washer Left Tool Rest 16 Switch...
