Solution-8 Control Panel Issue 3c September 1994 Electronics Design & Manufacturing © Copyright 1994-1995 All rights reserv (MA 800 O) -
Page 2: Important Note
Important Note As there are many different types of consoles available for use with this control panel, please refer to the following table and substitute the correct button and indicator names to suit your particular console. CP3 & CP4 STAY button HOME button STAY Indicator = HOME Indicator... -
Page 3: Table Of Contents
Table of Contents TABLE OF CONTENTS..............................3 INTRODUCTION................................4 FEATURES ..................................4 BASIC SYSTEM OPERATION ............................5 CONTROLS & INDICATORS............................6 .................................6 ONSOLE ................................6 ISUAL NDICATORS ................................6 NDICATOR ................................6 NDICATOR ................................6 NDICATOR ................................7 AINS NDICATOR ................................7 AULT NDICATOR ..............................7 UDIBLE NDICATIONS .................................8 XTINGUISH CONSOLE OPERATIONS..............................8 ................................8 NTRODUCTION ............................9... -
Page 4: Introduction
Page Solution-8 Operators Manual Introduction Congratulations on choosing the security control system to protect you Solution-8 and your property. So that you can get the most from your alarm system we suggest that you take the time to read through this manual and familiarise yourself with the and its many outstanding operating features. -
Page 5: Basic System Operation
Solution-8 Operators Manual Page Basic System Operation The overall purpose of your alarm system is to deter any would be intruder from entering your premises. Before leaving your home or office make sure all the windows and doors are closed. -
Page 6: Controls & Indicators
Page Solution-8 Operators Manual Controls & Indicators The Console The console is the communications interface between you and your alarm system. It allows you to issue commands and offers both visual and audible indications that guide you through the general operation. -
Page 7: Mains Indicator
Solution-8 Operators Manual Page Mains Indicator The MAINS indicator is used to indicate that the system mains power is normal or has failed. Indication Definition Flashing Power Failure Power Normal Fault Indicator The FAULT indicator is used to indicate that the system has detected a battery fault and that you should contact your installer. -
Page 8: Extinguish Mode
Page Solution-8 Operators Manual Extinguish Mode This option when programmed by your installer will cause the indicators on your console to automatically extinguish if the console is not used for a period of sixty seconds. At any time the indicators can be brought back to an illuminated state by pressing a button, an alarm condition or when the system is in entry time. -
Page 9: Altering Or Adding Codes
Solution-8 Operators Manual Page It should also be noted that for any code that has trailing zeros, the zeros need not be entered when arming or disarming the system. Example: If your code is 2670 then you only need to enter 267 AWAY to turn the system on and off. -
Page 10: Erasing Codes
Page Solution-8 Operators Manual WARNING! Care should be taken when altering user code '1' as this is the systems MASTER CODE. If this code is forgotten or incorrectly programmed no other code changes can be carried out and your installer will need to be called to rectify the problem. -
Page 11: Arming In Away Mode
Solution-8 Operators Manual Page Arming in Away mode To arm the system in AWAY mode, key in your code followed by AWAY button. The AWAY indicator will illuminate, two beeps will be heard and your pre programmed exit time will now begin. -
Page 12: Disarming
Page Solution-8 Operators Manual Disarming To disarm the system key in your code followed by the AWAY or STAY button. The STAY or AWAY indicators will extinguish and two beeps will be heard. Isolating zones When a zone is isolated access is allowed into that zone at all times. This can be useful if you wish to leave a pet in the garage for one evening while you are out. -
Page 13: Day Alarm
Solution-8 Operators Manual Page Day Alarm 99997 Day alarm is a feature capable of indicating that one or a number of zones are currently opened (the specific zones will need to be assigned by your installer). Let us assume that your installer has programmed the front door for Day Alarm, an indication will be given every time the front door is opened. -
Page 14: Alarm Memory Recall
Page Solution-8 Operators Manual Alarm Memory Recall This feature allows you to playback the last ten events that have occurred to the system. The RECALL mode reports all alarms and arming or disarming of the system in the STAY or AWAY modes. This function helps with trouble shooting of the system. The alarm memory events are displayed via the console indicators. -
Page 15: Walk Test Mode
Solution-8 Operators Manual Page Walk Test Mode Using Walk Test Mode you can test detection devices to ensure that they are functioning correctly, eg: to check a reed switch on a door. To turn Walk Test on, isolate any zones that are not required for walk testing (see manually isolating one or more burglary zones). -
Page 16: Console Panic Alarm
Page Solution-8 Operators Manual Console Panic Alarm A PANIC ALARM can be triggered by pressing any two buttons in the outside columns simultaneously on the console. The buttons must be horizontally adjacent. This function can be programmed by the installer to either be a silent or an audible alarm. -
Page 17: Domestic Dialling
Solution-8 Operators Manual Page Domestic Dialling Programming There are 32 data locations set aside for domestic dialling, each of which is capable of storing 1 digit. This will allow up to four 7 digit phone numbers to be programmed. To program the desired phone numbers, first ensure the system is disarmed and that there are no alarm memories present. -
Page 18: Dialling Function
For example your home and office could be reporting to your holiday house. Once the call has been received, if it is not acknowledged using an EDM call acknowledger, (Part Number CC911) then the panel will continue sending its transmission for a period of 2 minutes, after which it will hang up and commence dialling the next phone number. -
Page 19: Pager Dialling Formats
Solution-8 Operators Manual Page When interrogating the panel, if 1 beep is heard between the bursts of siren tone then a 24 Hour zone alarm has occurred. If 2 beeps are heard then a burglary zone alarm has occurred. If more than 1 zone has alarmed, ie. a burglary and a 24 Hour zone, then only the 24 Hour zone alarm will be indicated. -
Page 20: Basic Pager Format
Page Solution-8 Operators Manual Basic Pager Format Example: A typical transmission would appear on your pager as follows describing the system condition. The example shows client 678 with an alarm on zone four while the system is armed and all other events are normal. -
Page 21: Advanced Pager Format
Solution-8 Operators Manual Page Advanced Pager Format The Advanced Pager Format allows for more detailed and tailored information to be transferred to your pocket pager. This format is not easily deciphered and therefore is only recommended for use in advanced situations. The format is client identification number followed by a two digit event code. -
Page 22: Remote Arming Via The
Hold the EDM phone controller to the mouth piece of the telephone and press the button on the controller. The tone generated by the phone controller will arm the system and one long beep will be heard to indicate that the system has become armed. -
Page 23: Optional Equipment
Solution-8 Operators Manual Page Optional Equipment ̌ To enhance the security of your system an EDMSAT (Satellite siren) is available. When tampered with or even totally disconnected from the control Solution-8 panel, it will still continue to emit its ear shattering warning sound. -
Page 24: Terminology
Page Solution-8 Operators Manual Terminology Alarm condition Is when the security system is ARMED and a detection device is violated. Armed When the system is in a state ready to accept alarms. (System “ON”) Away This is a console button used to execute any given command. - Page 25 Solution-8 Operators Manual Page Master code Is a numerical code used for ARMING and DISARMING the system as well as allowing access to all functions that are programmable through the main codepad. Monitoring Is a secure location where a DIGITAL RECEIVER monitors...
-
Page 26: Warranty Statement
Page Solution-8 Operators Manual Warranty Statement Electronics Design & Manufacturing warrants this product to be free from defects in material and workmanship for a period of three years from the date of manufacture as indicated by the date stamp and/or the serial number on the product. Defective units returned by the purchaser at their own expense during this period will be repaired or replaced at the option of the manufacturer. -
Page 27: Installation Notes
Solution-8 Operators Manual Page Installation Notes Installation Company _____________________________________________ Technician _____________________________________________________ Phone Number __________________________________________________ Installation Date _________________________________________________ Warranty Expires ________________________________________________ Description Stay Mode Alarm ̌ ̌ Zone 1 ̌ ̌ Zone 2 ̌ ̌ Zone 3 ̌ ̌ Zone 4 ̌...
