For SS-P 150, SS-P 150H, SS-P 500, SS-P 500H, and SS-P 1200EX models
SS-P Portable Extractors provide deep, rapid cleaning of carpets, upholstery and hard surfaces.
Heated models provide additional cleaning power. Lightweight, easy to use, and adjustable for a
wide range of carpet types and soiling conditions, the SS-P Extractors produce cleaner, drier
carpets and surfaces.
R E A D A N D S A V E T H E S E I N S T R U C T I O N S
Contents
Introduction
Warnings and cautions ......................................... p. 1
Key features .............................................................. 1
Product introduction .................................................. 2
Operating instructions
SS-P 150, SS-P 150H, SS-P500, SS-P 500H .......... 3
SS-P 1200EX ............................................................ 3
Maintenance (all units) .............................................. 5
Other information
Specifications ............................................................ 5
Warranty and registration ......................................... 5
Warnings: Risk of personal injury
Read these instructions before operating machine.
WARNING: Unplug machine before
servicing. Possbility of electrical shock.
WARNING: In heated units, solution line can
become extremely hot during use.
WARNING: Interior components may be hot
after operation. Let unit cool completely
before servicing.
WARNING: Do not operate machine unit in the
presence of flammable materials.
Cautions: Risk of property damage
CAUTION: Protect from freezing. Freezing may
damage internal components and will void warranty.
24-00265 C 2012-01 Warranty 49-055
SS-P Portable Extractors
User Instructions
Patent Pending
CAUTION: Do not use with water with over 3 grains
per gallon (51 miligrams per liter) of hardness. Use
with hard water could result in the formation of
mineral deposits inside pumps and fittings. Damage
caused by mineral deposits will void warranty.
CAUTION: Use only to extract liquids. Do not use as
a dry vacuum. Dust particles will damage the
vacuum motors. Damage caused by dry vacuuming
will void the warranty.
CAUTION: To prevent the growth of mold and
mildew inside the tanks, always drain waste tank
completely and empty solution tank after use.
Key features
Compact: Smaller footprint than leading competitors –
only 39.5H × 32L × 19.75W in. (100.3 × 81.2 × 50.2 cm).
Versatile: Sapphire portable extractors may be used
successfully with most professional wands and hand
tools. Use with 1½ in. vacuum wands, hoses and tools,
or adapt for use with 2 in. equipment (adaptor purchased
separately).
Lightweight: only 87–130 lbs. dry weight depending on
model.
Easy to transport: Rugged molded handles are well-
placed for easy maneuverability. Molded grip point
assures safe handling when lifting.
Integrated cord wrap provides secure cord storage.
Slim profile. Semi-pneumatic 10 in. diameter non-
marking wheels mounted in recessed wheel wells.
Durable: Rotomolded housing helps reduce
maintenance and provides quiet operation.
Quiet operation: Noise suppressor for quiet operation.
May be operated with single motor for reduced noise.
1
