Summary of Contents for Tokio active
-
Page 2: What's Included
What’s Included The following components are included with your purchased product: Tokio Action Waterproof Case Camera Shield Suction Mount Car Charger Handle Bar Mount Helmet Mount Helmet Belt USB Cable ... -
Page 3: Mounting Accessories
Mounting Accessories... - Page 4 Quick User Guide for Mounting Accessories...
-
Page 5: Appearance And Buttons
Appearance and buttons... - Page 6 ⑴Memory card slot ⑻Lens ⑵Reset ⑼LCD TFT ⑶USB slot ⑽Working Indicator Light ⑷Power button ⑾Indicator Light for charging ⑿ Wrist strap eyelet ⑸MIC ⑹Shutter button ⑺Mode Switch:...
-
Page 7: Getting Started
USB Cable Turn off your Tokio Active and connect it with PC via USB cable for charging. The indicator light for charging is on at this time and will be off after charging. Normally, the device can be fully charged after 3-4... - Page 8 Use of Memory Card There is no built-in memory available in your Tokio Active, make sure to install the Micro SD card before operations. 2.1 Push the memory card into the card slot according to the concave lettering beside the slot of memory card till it is completely inserted.
- Page 9 3.2 Shutdown: press on the POWER button, and the camera will be shut down. 3.3 Automatic shutdown: when the idle time of your Tokio Active reaches the time for automatic shutdown, it will be shut down automatically to save power. The defaulted automatic shutdown time of your Tokio Ative is 5 minutes.
- Page 10 Switching Between Function Modes There are three modes available for your Toiko Active, photo taking mode; video recording mode and vehicle-mounted mode, you can switch to different modes after startup. Picture taking mode: for taking photos Video recording mode: video can be recorded;...
- Page 11 5. Indicator light Busy light: when the camera is busy (such as, recording a film, taking photos, automatic off-screen), the busy light will be on. Charging light: when the light is on for a long time, it prompts the user that the camera is charging. 6.
- Page 12 : means that the memory card has been installed at present. : digital zoom icon, click it to enlarge : digital zoom icon, click it to minify. : visual shutter, touch this visible frame for taking photos or recording. : battery icon, represents the power status of the battery. : represents the status of digital zoom.
- Page 13 : means that the memory card has been installed at present. : digital zoom icon, click it to enlarge. : digital zoom icon, click it to minify. : visual shutter, touch this visible frame for taking photos or recording. : battery icon, indicates the power status of the battery. : represents the status of digital zoom.
- Page 14 1 00:12:18 : timer, indicating that the camera can still record for 12 minutes and 18 seconds. : mode icon, representing that the camera is in vehicle-mounted mode. : video size, click this icon to select 720P, VGA. : represents that the memory card has been intalled .
- Page 15 Playback mode: 9.1 After starting up and entering the previewing state, click on the playback icon ( ) at the lower right corner of the LCD to switch to the playback mode: : Means that the current file is an AVI video file. : Means that there is one file in the current folder/ one file in total.
- Page 16 9.2 Movie Clips Playing: Click to pause playing, click to play forward, and click to play backward. 9.3 File Deletion: Click Yes to delete the current file immediately, or click No to cancel the request of deletion.
-
Page 17: Connection With Pc
Connection With PC Use the USB cable provided to connect your Tokio Active with PC. After connecting with PC, an icon of movable disk will appear in the window of “my computer”. Photos/videos which have taken are saved in folder I:\DCIM\100MEDIA (I is the movable disk of this device) in the movable... -
Page 18: Technical Parameters
Technical Parameters Image sensor 1.3 million pixel (CMOS) Function mode videoing, taking photos, vehicle-mounted mode, removable disk, PC cam Camera lens F3.1 f=9.3mm Digital zooming 4 times Shutter Electronic shutter LCD display screen 2.0-inch touch screen Image resolution 5M (2592× 1944), 3M (2048× 1536), 1M(1280× 1024) Video resolution VGA: 640x480 (60 frames/second), 720P:1280x720 (30 frames/second) White balance... - Page 19 System Requirements Operating System Microsoft Windows2000, XP, Vista, 7 Intel Pentium III of more than 800MHz or other CPU with equivalent performance Internal Memory Larger than 512MB Sound Card and The sound card and display card shall support DirectX8 or higher version. Display Card CD Driver Speed of 4 times or faster...
- Page 20 Important Maintenances Precautions In order to offer your Tokio Active good maintenances, please always follow the below basic precautions: Do not expose the device to sunshine directly, nor point its lens to sunlight. Otherwise, the image sensor of the video camera may get damaged.
- Page 21 agent of camera for wiping if necessary. Do not use organic solvent to clean the video camera. Do not touch the lens surface with fingers. Please use branded Micro SD card only. The data inside the Micro SD card may be lost or damaged under the following circumstances: Improper use of the memory card.
-
Page 22: Battery Management
Battery Management The built-in battery is not fully charged from factory, so it is recommended that you charge the battery for at least 4 hours before you start to use the device. The rechargeable battery is designed and manufactured to be used and recharged frequently. As same with all of lithium batteries, the capacity of the battery reduces each time it is charged.
