Pursonic S620 DELUXE Instruction Manual

PURE, FRESH AND SONIC CLEAN
S620 DELUXE

IMPORTANT SAFEGUARDS

Please read the safety instructions before using this product. The safety instructions
provided here are to help you use this product safely and correctly, and also to prevent
you from injuring yourself or others.
When using electrical products, especially when children are present, basic safety
precautions should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING
DANGER-WATER
To reduce the risk of burns, electrocution, fire, or injury to persons:
● Do not place or store the product where it can fall or be pulled into a bathtub, sink or
toilet.
● Do not place or drop the charger into water or other liquid.
● Do not reach for the charger that has fallen into water or other liquid. Unplug
immediately.
● Do not use while bathing.
● Unplug charger before cleaning and assure that it is dry before plugging it into an
electrical outlet.
DANGER-VOLTAGE
To reduce the risk of burns, electrocution, fire, or injury to persons:
● Do not plug the charger base into an outlet with a voltage other than specified on the
bottom of the charger.
● Voltage converters do not guarantee compatibility.
● Do not force the plug into an outlet.
● If the plug does not fit easily into the outlet, discontinue use.
●
This appliance has a polarized plug (one blade is wider than the other). As a safety
feature, this plug will fit in a polarized outlet only one way. If the plug does not fit fully in
the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not
attempt to defeat this safety feature.
MEDICAL-WARNINGS
● If you have had oral surgery or gum surgery within the past two months, consult your
dentist before using the product.
● Consult your dentist if excessive bleeding occurs while using this product or minor
bleeding continues to occur after one week of use.
● Consult your physician or implant device manufacturer prior to using this product if you
have questions concerning the combined use of this product with a pacemaker or other
implanted medical device(s).
WARNINGS
To reduce the risk of burns, electrocution, fire, or injury to persons:
● This product is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities or lack of experience and knowledge, unless
they have been given adequate supervision or instruction concerning use of the product
by an adult responsible for their safety.
● Children should be supervised to ensure they do not play with the product.
● Use this product only for its intended use as described in this manual. This product is
designed to clean your teeth, gums and tongue only. Do not use any attachments or
brush heads other than those recommended by the manufacturer.
● If your toothpaste includes peroxide, baking soda or other bicarbonate (common in
whitening toothpastes), thoroughly clean your brush head and handle to avoid cracking
the plastic.
● Certain liquid mouthwash may damage the product by causing the housing or tank to
crack, when using mouthwash, rinse the tank and main unit with water immediately after
use. Be especially careful when washing the hose connections at the main unit and the
tank.
● Never fill the tank with hot water! The gumlines can be very sensitive and can be easily
damaged by hot water.
● Use the unit within an ambient temperature range of 32F-104F.
● Never operate this product if it has a damaged cord, plug or charger. Do not use this
product if it is not working properly, if it has been dropped or damaged or dropped into
water. Immediately discontinue use if the product appears damaged in any way.
● Keep the product away from heated surfaces.
● If you experience discomfort or pain in your mouth, discontinue use of this product and
contact you dentist.
● Do not clean the product in the dishwasher.
● Consult your physician prior to using the toothbrush if you have any medical concerns.
● The toothbrush has been tested and is certified as per ETL and CE regulations.
● Never drop or insert any object into any opening.
● For household use.
SAVE THESE INSTRUCTIONS
ORAL IRRIGATOR
MAIN UNIT
Nozzle
Identification ring
Water tank cap
ON/OFF button
Mode button
Mode indicator
ACCESSORY
Orthodontic Tip Tongue Cleaner Tip
GETTING STARTED
Make sure your oral irrigator and the appliance are dry when inserting
the batteries.
Oral Irrigator operates on 3 AA-size 1.5V alkaline batteries(not
included)
1. Remove the battery door by rotating the battery door knob in
counter- clockwise direction. (Fig.1)
2. Be sure the +and -poles of the batteries match the-appropriate
location inside the battery box.
3. Insert the batteries into the battery box in the correct polarity.
4. Firmly push the battery door back onto the battery box, and rotate
the battery door knob to the "Close" position.
HOW TO USE
1. Attach the nozzle and the tank firmly onto the unit (Fig.2)
2. Open the cap of the water tank, hold the unit so it is vertical, and fill
the tank with cold or warm water, not hotter than 104F, Be sure the
water tank is always removed from the main unit before refilling.(Fig.3)
● Do not put salt, toothpaste, powder or other chemicals into the water
tank.
● Do not operate the unit when empty other than when pouring out
any remaining water after use. Operating the unit without water may
result in a malfunction and will void the warranty.
3. Close the cap, making sure it locks in place.
4. Press the mode switch and select the desired water jet mode.
● The mode indicator will display the previously selected mode.
● If you want to use a different mode, press the mode switch until it
changes to the desired setting. Pressing the mode switch will change
the mode from normal to soft to pulse.
MODE AND ITS INDICATOR (Fig.4)
① Mode switch: Pressing the mode switch will change the water jet
setting and the respective mode indicator will light up.
② Normal mode: This mode is for removing food particles trapped
between the teeth.
③ Soft mode: This mode is for gently massaging the gums.
④Pulse mode: This mode is for removing food particles and for
massaging the gums and rinsing between the teeth and gums.
NOTES: When you use the unit for the first time, press the operation
switch to turn the unit on and test each of the water jet modes with the
tank filled with water.
5. Insert the nozzle into your mouth.
● Bend over the sink and hold the unit in an upright position with the
nozzle pointing toward your teeth.
6. Press the operation switch.
● Close your mouth slightly to contain the water spray.
● The unit starts operating in the mode selected in step 4 above.
● A fully filled water tank provides approximately 45 seconds of use.
● Do Not turn the switch on before putting the nozzle in your mouth.
● Do Not hold the tip of the nozzle firmly against the teeth or gums.
7. Turn the nozzle wheel with your thumb to reach all areas in your
Water tank
mouth. (Fig.5)
● Keep your mouth slightly opened so that the water can flow out.
● Systematically rinse all teeth and the spaces between them.
● Make sure that you always hold the device in an upright position with
the nozzle pointing upwards. If you turn the device upside down, no
water from the tank will be taken in.
● Remember that rinsing the mouth is not a substitute for tooth
Suction hose
brushing. Brush your teeth or dental prosthesis after a meal for at least
five minutes and then use this device.
Filter
● Do not place the nozzle firmly against the teeth or gums. Doing so
may damage your teeth or gums.
8. Use of the Orthodontic Tip (Fig.6)
● Start on the last molar (back tooth). Aim water stream at 90° to the
tooth at the gum line. Gently glide tip along gumline, pausing briefly to
lightly brush area between teeth and all around orthodontic brackets,
before proceeding to the next tooth. Continue process until you have
cleaned the inside and outside of both the upper and lower teeth.
● Do not scrub or press hard, simply let the brush do all the work.
9. Use of the Tongue Cleaner Tip (Fig.7)
● To use the Tongue Cleaner Tip, set the unit to the lowest pressure
setting. Gently place the tongue cleaner in the center/midline of your
tongue, about halfway back and start the water flosser. With light
pressure pull forward. You can increase pressure as you prefer.
10. After use, press the operation switch to turn off the unit.
Fig.1
Fig.2
Fig.3
Pulse
Fig. 4
Fig. 5
Fig. 6
Fig.7
