Gulfstream GS A-Class 12/OV Design, Installation & Servicing Instructions

Advertisement

GulfStream
A Condensing Primary Storage Appliance
for Hot Water Supply and Central Heating
DESIGN, INSTALLATION AND
SERVICING INSTRUCTIONS
PLEASE LEAVE THESE INSTRUCTIONS IN THE POCKET PROVIDED ON
Supplied By www.heating spares.co Tel. 0161 620 6677
A - C L A S S
THE BACK OF THE FRONT PANEL
APPLIANCE TYPE
• This is a Floor Mounted Fan Assisted Balanced Flue Gas Condensing Combination
appliance for hot water supply and central heating.
• This appliance is for use with Natural Gas (G20) only at 20mbar.
• This appliance for use in GB & IE only
• Appliance category:
Appliance types:
MODELS
These instructions cover the following models and only apply to the
appliances sold and installed in Great Britain (GB) and Ireland (IE). These
appliances have been certified for safety and therefore it is important
these instructions must be followed. The appliance and the installation
specifications of the appliances must not be modified unless recommended
and approved by Gledhill Water Storage Limited.
Model Ref
Sedbuk
Maximum Space
Band
Heating Load (kW)
A-CLASS
GS
12/OV
A
GS
A-CLASS
12/SS
A
GS
A-CLASS
20/OV
A
A-CLASS
GS
20/SS
A
A-CLASS
GS
30/OV
B
A-CLASS
GS
30/SS
B
All models are WRAS approved and listed.
SAFETY
1. The Gas Safety (Installation and use) Regulations 1998
"In your own interest, and that of safety, it is law that all gas appliances are
installed by competent persons,in accordance with the above regulations.Failure
to install appliances correctly could lead to prosecution."
2. Control of Substances Harmful to Health
When working with insulation materials,avoid inhalation as it may be harmful to
health,avoid contact with skin,eyes,nose and throat.Use disposable protection.
Dampen the material and ensure that the area is well ventilated.
3. INSTRUCTIONS
Read these Instructions before installing or lighting the appliance
Leave these instructions and the'Benchmark'Log Book in the pocket
provided on the back of the appliance front panel.
I
2H
C
, C
, C
13
53
33
Gas Council
No.
10.0
Open vented heating system
10.0
Sealed heating system
18.0
Open vented heating system
18.0
Sealed heating system
26.0
Open vented heating system
26.0
Sealed heating system
Heating System Type
