CHEST FREEZER
SERVICE MANUAL
GY-NE200CF

Advertisement

loading
Need help?

Need help?

Do you have a question about the GY-NE200CF and is the answer not in the manual?

Questions and answers

Related Manuals for Acqua GY-NE200CF

Summary of Contents for Acqua GY-NE200CF

  • Page 1 CHEST FREEZER SERVICE MANUAL GY-NE200CF...

  • Page 2: Table Of Contents

    Content 1.Safety precautions ………………….……………………………………2~2 2.Specification……………………………………………………………..3~3 3.Parts identification…………...………………………………………….4~4 4.Chest Freezer system diagram………….………………………….……5~5 5.Circuit diagram………………………………………………..………..5~5 6.Maintenance service and Troubleshooting …………..……………….6~24 7.Quality information report……………………………….……………24~24 8.Exploded view and part list……………………………………………25~26 - 2 -...

  • Page 3: Safety Precautions

    1. Safety precautions - 3 -...

  • Page 4: Specification

    2. Specification models FC-26DD4HNA net capacity (L) color white power supply(V/Hz) 220-240 rated input power (W) net weight (kg) gross weight(kg) unit dimension (D*W*H)(mm) 946*562*830 packing dimension (D*W*H)(mm) 982*982*880 container quantity (PCS) noise - 4 -...

  • Page 5: Parts Identification

    3.Parts identification Door Door knob Hinge Sup ply Ca ble T em pe ra ture Cla mp Control V olum e P ower Supply Cord with Plu g Drain cap P ower la mp Sid e C over Foo t - 5 -...

  • Page 6: Chest Freezer System Diagram

    4. Chest Freezer system diagram when the FREEZER is just powered on. The refrigerant flows in the sequence: Compressor Condenser Dry filter Capillary tube Evaporator . 5.Circuit diagram CHEST FREEZER FC 26DD4HNA 205L 1.2A 140W 0.92 R134a 105g 38kg - 6 -...

  • Page 7: Maintenance Service And Troubleshooting

    6.Maintenance service and Troubleshooting. - 7 -...
  • Page 8 - 8 -...
  • Page 9 - 9 -...
  • Page 10 - 10 -...
  • Page 11 - 11 -...
  • Page 12 - 12 -...
  • Page 13 - 13 -...
  • Page 14 - 14 -...
  • Page 15 - 15 -...
  • Page 16 - 16 -...
  • Page 17 - 17 -...
  • Page 18 - 18 -...
  • Page 19 - 19 -...
  • Page 20 - 20 -...
  • Page 21 - 21 -...
  • Page 22 - 22 -...
  • Page 23 - 23 -...
  • Page 24 - 24 -...

  • Page 25: Quality Information Report

    7. Quality information report 7. Quality information report Quality information Quality information Thank you very much for purchasing our products. In order to provide you with more satisfied products, Thank you very much for purchasing our products. In order to provide you with more satisfied products, please kindly fill in the questionnaire as the items indicated below.

  • Page 26: Exploded View And Part List

    8.Exploded view and part list 8.1 Exploded view - 26 -...
  • Page 27 ACQUA GY-NE200CF exploded view...
  • Page 28 GY-NE200CF Parts List Part No Part name 6270800771.00 Foamed door assy 6160100114.00 Door gasket 6120400083.00 Hinge assy 6111600048 Upper cover hinge 6111600044 Lower cover hinge 6120400083 Hinge assy 6210400126 Basket 6210600066 Side cover 6111600071 Pipe lid 6110600220 Cap drain 6210200002...
