Ignis gamma v2.15 is a microprocessor temperature regulator to control the central heating boiler with a solid fuel
feeding screw. The Ignis gamma v2.15 controller with room sensor supports the preset room temperatures
according to established time programs.
APPLICATION
The purpose of Ignis gamma v2.15 is automatic control of feeding screw, blower, central heating pump (CH pump)
and feeding pump for tap water container (TW container).
FRONT PANEL
Controls:
feeding pump for TW container
blower
MAIN DISPLAYS
1
controller
operation status
current
boiler temperature
current
tap water temperature
The main displays operate changing in cyclic mode. The boiler temperature can be set on Display 1 using
buttons
and
. The arrow
returns to its cyclic operation of changing displays.
IGNIS gamma v 2.15
TMK Września
CH pump
feeding
parameter setting MENU ON/OFF
boiler
temperature setting
current
room temperature
we can use to change displays in manual mode. In 30 seconds the controller
MENU navigation and parameter setting
2
current day/hour
Mo 12:35
Daily & 21,5*
room temperature
controller
for daytime
daytime
