Summary of Contents for Emco Tech Delphi IO400U
-
Page 2: Table Of Contents
CONGRATULATIONS ON YOUR NEW PURCHASE! TABLE OF CONTENTS Description You have just purchased the finest, most advanced water system in the world! Your new Delphi undersink ionizer is designed to provide you with many years of the cleanest, 01-02 Congratulations / Introduction healthiest and most "functional"... -
Page 3: What Is Alkaline Electrolyzed-Reduced Water
Some uses for the different levels of Acidic water The Acid water has both antiseptic and antibacterial properties. It also has an astringent effect and can be used for cosmetic purposes. What is alkaline electrolyzed-reduced water? Use it while brushing your teeth, It is an excellent astringent;... - Page 4 Why the Delphi undersink is the world's Water selection and mode indicators most advanced ionizer Your ionizer has an attractive colored FND display that easily identifies your Your new Delphi undersink is the only fully remote fucet that selections. allows you to get both alkaline and acidic water at the sink. Easy to understand symbols and colors identify the type and level of water you have selected on the machine.
-
Page 5: Safety Precautions
Safety Precautions Installation Precautions Do not attempt to repair the machine if you encounter a technical problem, first contact the IonWays Associate you purchased the machine from, then IonWays Technical Support if needed. Protect your ionizer from freezing temperatures. Electrical power precautions If your ionizer becomes submerged in water, unplug the power cord from the wall BEFORE removing the ionizer from the water. -
Page 6: During Usage
Safety Precautions During Use Acidic water is effective for washing and rinsing. In order to clean the product's internal parts and in order to drink clean water, acidic water should be run through the alkaline water tube 2 or 3 times per week and the faucet pipe should be cleaned Do not run hot water through your ionizer. -
Page 7: Names And Functions Of Parts I
Names and functions of Parts I Front Back Calcium cap Rear cover Body Filter cover Speaker Volume controller Huse holder Main switch Connector Port Alkaline water outlet port Acidic water outlet port Tap water inlet AC Power cord... -
Page 8: Names And Functions Of Parts Ii
Names and functions of Parts II Display Panel Faucet Function display panel pH level indicator This numeric display will indicate which level (1-4) is selected. LEVEL If alkaline water is selected the number will be displayed in BLUE BLUE, if acidic water is selected, the number will be displayed in ORANGE ORANGE. -
Page 9: How To Install
How to Install How to connect water faucet How To Install Connecting the Delphi faucet All the fittings are push in style fittings. To attach the hoses to any fitting, firmly insert the end of the hose into the fitting. Pull firmly to check to connection - you should not be able to pull the hose out. -
Page 10: How To Use
How to Install How to Use How to install the external valve Connecting the faucet and cold water hoses to the Ionizer Faucet Connect the external valve between the hoses. 1/4" hose If the water pressure is excessively high, adjust the water flow by turning the external valve. - Page 11 How to Use How to Use To change levels of Alkaline water To select Acidic water Note: Acidic water is for external use only. DO NOT DRINK To select a different level, depress the "ALKALINE" button to move to next level until the desired setting level is achieved.
-
Page 12: How To Measure Ph
How to Use To select "Filtered" water With the water running through your Delphi faucet, press the "FILTERED" button. How to Measure pH The display panel will show a green symbol. The purified water will come out of the top spout. Nothing comes out of the lower spout. -
Page 13: How To Set Your Individual Ph Levels
How to set your individual pH levels User can regulate the electrical current of the water ionizer based on the water source. Depress the "ALKALINE" button to raise to the desired setting, and depress the "ACIDIC" button to lower to the desired setting. Depress the "FILTERED"... -
Page 14: How To Add Calcium
How to Add Calcium Adding calcium to your machine is NOT needed unless you have unusually soft water, low in minerals. If your machine is making adequate pH, there is no need to add the calcium insert. Calcium cap(Chrome) Plastic cap Add the new calcium beads and close Stop the water flow prior to calcium replacement. -
Page 15: How To Replace The Filter
How to Replace the Filter LEVEL How to Replace the Filter Flush out the GAC carbon dust. Reset ALKALINE IMPORTANT! Stop water flow prior to filter replacement. - The water will initially come out discolored (light to charcoal ACIDIC gray) due to carbon particulates in the new filter. When the digital filter life indicator reaches This is not harmful and is typical of all GAC filters. -
Page 16: About Your Revolutionary Biostone Filter
About your revolutionary Biostone Filter Composition of filter Calcium: It slightly increases the alkaline mineral content in your water. It improves water taste and odors, and it is particularly effective in removing the chloride. You get calcium on tap! Tourmaline: Tourmaline emits Far Infra Red (FIR) energy naturally. -
Page 17: Trouble Shooting Guide
Trouble Shooting Guide Abnormal condition Cause(s) Resolution Abnormal condition Cause(s) Resolution A power plug is not property Properly insert power plug into Expired filter from ordinary use inserted, or it is inserted into a a correctly functioning power or premature clogging due to Replace your filter. - Page 18 How to assemble the spouts When you first open the faucet box you will find an allen wrench and the spouts for your faucet. You need to install the spouts to the faucet. There are allen screws in the faucet where the spouts attach.
