- Page 1 Turbhogar Mod. ALFA, BETA, DELTA, NEO, SIGMA Manual de uso y montaje Manual of assembly and use Manuel d’utilisation et de montage Benutzer und Montagehandbuch...
- Page 2 • the efficient system of hot air heating, driven by its two turbines. This enables us to heat up more quickly the space in which the TURBHOGAR fireplace is installed, by means of its front air outlets. Moreover, and thanks to its two upper outlets, the hot air can be conveyed to other rooms in the house.
- Page 3 Under no circumstances should the TURBHOGAR be coated with fibre glass sheets or other types of insulating material. To convey hot air to other rooms, the TURBHOGAR fireplace is fitted with two upper outlets. The connection is made with a flexible aluminium pipe by first removing the cover and then inserting an adjustable grille in the outlet.
- Page 4 TURBHOGAR · MANUAL OF ASSEMBLY AND USE Assembly Hood ventilation grille (optional) Outlet of hot air Hot air outlet on same floor (optional in upper floor) Flexible aluminium pipe Smoke outlet in stainless for heating or vitrified steel Front hot air outlets...
-
Page 5: Smoke Ducts
When joining together the pipes the nozzle end should be pointing • upwards. To ensure a faultless sealing in the section that passes through the hood, between the TURBHOGAR fireplace and the wrought ironwork, heat resistant putty may be used. WRONG RIGHT 90º... - Page 6 The draught must never be closed when the door is open. In order to control the flow of hot air, the TURBHOGAR fireplace • is fitted with a three-position switch: Position 0: Automatic mode –...
-
Page 7: Maintenance
(normally 20-30 minutes after the lighting); in the same way, the turbines switch off when the temperature of the TURBHOGAR fireplace drops. To get full benefit from the heating power of the TURBHOGAR fireplace • we recommend using Position II, as its greater air flow is specially desig- ned for the conveying of air to other rooms or for heating up an area more quickly. -
Page 8: Electrical Connection
Switch Diagram of the electrical connection Any repair work to or handling of the Turbhogar model particular the • electrical system must be carried out by authorised technical staff. For any information related to the assembly, use or maintenance of •... - Page 9 TURBHOGAR · MANUAL OF ASSEMBLY AND USE Technical data – ALFA Model Upper hot air outlets Smoke outlet Hot air outlets with adjustable grilles Draught control handle Door with vitro-ceramic glass Anchors for transportation Ashes box with adjustable grille Turbine switch key...
- Page 10 TURBHOGAR · MANUAL OF ASSEMBLY AND USE Technical data – BETA Model Upper hot air outlets Smoke outlet Hot air outlets with adjustable grilles Draught control handle Double door with vitro-ceramic glass Anchor for transportation Ashes box with adjustable grille...
- Page 11 TURBHOGAR · MANUAL OF ASSEMBLY AND USE Technical data – DELTA 2 – DELTA 3 Model Connection of the heat ducts 1.- Remove the upper cover of the Turbhogar 2.- Insert the metallic connector supplied, fireplace using a screwdriver to lever the edge which will serve as a joint for the flexible heat of the lid.
- Page 12 TURBHOGAR · MANUAL OF ASSEMBLY AND USE Technical data – NEO Model Connection of the heat ducts 1.- Remove the upper cover of the Turbhogar 2.- Insert the metallic connector supplied, which will serve as a joint for the flexible heat fireplace using a screwdriver to lever the edge of the cover.
- Page 13 TURBHOGAR · MANUAL OF ASSEMBLY AND USE Technical data – SIGMA Model Upper hot air outlets Smoke outlet Front hot air outlets Draught control handle Door with Anchors vitro-ceramic glass for transportation Removable ashes box Folding cover This model has an air inlet control grille, turbines and a Handles for transportation switch key behind the folding cover.
- Page 14 TURBHOGAR – Complementary sheet to the Manual of Installation and Use Complementary sheet to the Manual of Installation and Use Review 281108 TURBHOGAR Models Alfa, Beta, Delta, Epsilon, Lambda, Neo, Sigma UNE-EN 13229 Manufacturer: ROFER AXARQUÍA S.L. Family / Models...
- Page 15 TURBHOGAR – Complementary sheet to the Manual of Installation and Use Warning for installer and user (Add to the beginning of page 3) • The installation of the fireplace and of the smoke duct should be carried out in observance of all the local regulations, including those referring to national and European norms.
- Page 16 TURBHOGAR – Complementary sheet to the Manual of Installation and Use Smoke ducts (Add to the end of page 6) • The smoke duct and the hood of each device should be individual. Do not connect 2 or more heating devices to the same smoke duct.
-
Page 17: Spare Parts
TURBHOGAR – Complementary sheet to the Manual of Installation and Use Maintenance (Add to the end of page 8) • In order to prevent the soot accumulated in the chimney draught catching fire, we recommend a periodic check and cleaning of the draught installation using mechanical means carried out by qualified technical staff at least once a year. -
Page 18: Technical Data
TURBHOGAR – Complementary sheet to the Manual of Installation and Use Technical data (Add to the beginning of page 10) • The TURBHOGAR fireplace is an insertable device, which conforms with the obligatory UNE EN-13229 regulations: Normal heat output: 12 KW... - Page 19 TURBHOGAR – Complementary sheet to the Manual of Installation and Use Probable causes of failure or irregular functioning • The device you have purchased is a high performance fireplace of guaranteed quality. Nevertheless, certain extreme climate conditions such as strong winds, hail storms or risks of freezing temperatures, may cause the chimney draught to be inadequate.
- Page 20 TURBHOGAR – Complementary sheet to the Manual of Installation and Use table 2 Irregular function Probable cause Course of action Close the hot air outlets in the rooms that Reduction in the hot air are not being used. You have probably Excess of hot air outlets flow.
- Page 21 TURBHOGAR – Complementary sheet to the Manual of Installation and Use CE Declaration of compliance The manufacturer hereby Certifies that the fireplace models listed below meet all the requirements of the EU Directive governing construction products (89/106/EEC) comply with regulations UNE-EN 13229:2001 “Insertable devices, including open fireplaces:2003,which...
