Bajaj Motorsport DB30Dooblebug Assembly Manual & User Manual

Hide thumbs
1
2
3
4
5
6
7

Advertisement

Quick Links

Download this manual
Set Up instructions DB30 Doodlebug
Removal from crate
. Remove carton top
2. Remove set up instuctions,
owners manual and parts.
E -

REV - B

Advertisement

loading
Need help?

Need help?

Do you have a question about the DB30Dooblebug and is the answer not in the manual?

Questions and answers

Summary of Contents for Bajaj Motorsport DB30Dooblebug

  • Page 1 Set Up instructions DB30 Doodlebug Removal from crate . Remove carton top 2. Remove set up instuctions, owners manual and parts. REV - B...
  • Page 2 Hardware and Parts Front fork assembly Hardware 10mm Front 2 Beveled Fork Lock Nut Washers 10mm X 165mm Front Fork Bolt 2 large Washers Front Fender and Hardware 8mm lock 8mm X 25mm 2 Rubber Grommets Nuts Bolts Front Fender Front Tire and Hardware Cable Ties 12mm Front Axle bolt...
  • Page 3 Steering Fork assembly Fork Assembly 1. Install fork assembly. Make sure throttle cable, brake cable, and on/off switch wire are routed correctly through front fork assembly. (See photo for correct wire and cable placement) Brake Cable 2. Attach fork assembly by inserting fork bolt down through 1- large washer, 2- Top fork bracket, 3- Beveled washer facing down, 4- Down tube, 5- Beveled washer facing up,...
  • Page 4 SECURING THROTTLE CABLE, BRAKE CABLE AND WIRING 1. Use 3 plastic cable ties provided to secure brake cable and engine ON/OFF switch wire to ON/OFF switch wire mini bike frame (See photo for correct placement of cable ties) Make sure there are no kinks and Brake cable that brake cable and wiring have free movement when handle bars are turned left and right .

  • Page 5: Front Fender Assembly

    Front Fender Assembly 8mm X 25mm bolt Rubber Grommets Fender Orientation. Larger part toward front over wheel. 1. Install front fender. Make sure large portion of fender is over wheel. Install with rubber grommet between frame and fender. Tighten with 8mm Nuts and 8mm X 25mm bolts provided.

  • Page 6: Front Wheel Assembly

    Front Wheel Assembly Axle Bolt 1. Starting with left side (left side is defined as left side of mini bike while sitting in riding position), slide axle through 1- fork, 2- small Small wheel spacer left side wheel spacer , 3- wheel. 4- large wheel spacer, 5- fork, 6-washer.
  • Page 7 Gas and Oil . Drain packing oil and fill with correct amount and type of oil as specified in owners manual Oil Fill Plug Oil Drain plug 2. Fill gas tank as specified in owners manual. WARNING! This Mini Bike may be shipped with packing oil in engine.
