Summary of Contents for Axess-tel px100
- Page 2 INTRODUCTION The Fixed Wireless phone operates through a wireless connection instead of a landline phone cable, enabling the subscriber to set up the phone anywhere wireless service is available. Axesstel CDMA 2000 Fixed Wireless Phone provides high quality and superior performance with many features such as excellent voice quality, World clock, Calculator, speaker phone, one-touch dialing and short message service.
-
Page 3: Table Of Contents
TABLES OF CONTENTS Advanced Features Safety Precautions……………………… Changing Greeting Message……….. Checking the Parts ……………………… System Reset ………………………... Setting up Your Phone ……….……….. Restricting Use of the Phone ………. Getting to Know Your Phone ……….… Locking / Unlocking the Phone …….. Display Icons ……………………………. -
Page 4: Safety Precautions
SAFETY PRECAUTIONS 1. Avoid placing the phone in a dusty location, or near a source of gas or fire. 2. Don't Shake, hit or drop the phone. 3. To clean the outside of the phone, use only a soft, dry cloth. The chemicals in alcohol, benzene or acetone can damage the surface of the phone. -
Page 5: Checking The Parts
CHECKING THE PARTS Once you have unpacked your phone, make sure that you have all the parts shown below. If any piece is missing or broken, please call your customer service. 1. Main Unit 4. User Manual 2. Handset 5. Antenna 3. -
Page 6: Setting Up Your Phone
SETTING UP YOUR PHONE Installing the phone This phone operates by receiving DC power from the AXESSTEL power adaptor that connects to an electrical outlet. The phone is equipped with a rechargeable battery as a back up in case of an AC power failure. Desktop installation Attach the handset Connect the antenna... - Page 7 SETTING UP YOUR PHONE Service Status Check Display in the Service Area When the power cord is connected properly, AXESSTEL all segments of the LCD window will turn on briefly. THU 10/09 5:24P The number of bars of signal strength indicator (antenna icon) indicates the strength of service signal of the area.
-
Page 8: Getting To Know Your Phone
GETTING TO KNOW YOUR PHONE 1. Antenna: Adjusting the position of antenna improves the sound quality of the call. 2. Menu/FM: Press to access the phone's menus. Press and hold the key for a few seconds to start FM Radio. (FM is optional. -
Page 9: Display Icons
DISPLAY ICONS Icons display on the screen to indicate what features you are using, e.g. signal strength, battery status and etc... AXESSTEL THU 10/09 5:24P Indicate the strength of the signal. More bars indicates stronger signal. Indicates the level of battery power. The more bars, the more power. -
Page 10: Function Keys
FUNCTION KEYS Press this key to retrieve messages. Press this key to display the phone's main menu. Press and Hold this key to turn on or off the FM radio. If there is an incoming call or if the user attempts to make an outgoing call while the FM radio is on, the FM radio turns off automatically Press this key to control the volume of keypad, earpiece... -
Page 11: Basic Operation
Basic Operation Making Calls Redial Receiving Calls Adjusting Volumes Choosing the Ring Tones Message Service FM Radio(Optional) -
Page 12: Making Calls
MAKING CALLS 1. Make sure your phone is turned on. PLEASE 2. Pick up the handset to hear a dial tone. DIAL When the phone fails to acquire service signal, you will hear "No Service" tone (intermittent tone). 3. Dial the number to call. The LCD window displays the number. -
Page 13: Receiving Calls
RECEIVING CALLS When there is an incoming call, the phone rings blinks "Incoming Call" message on the display. INCOMING CALL 1. Simply pick up the handset or press <SPEAKER> to answer 123-456-7890 the call. 2. To disconnect, replace the handset or press <SPEAKER>. NOTE: When the ringer volume is set to 'Silent', the phone does not ring. -
Page 14: Adjusting Volumes
ADJUSTING VOLUMES You can control the sound volumes including the key tone, Earpiece, speaker and the ringer Adjusting key tone volume Press <VOLUME KEY> repeatedly until it reaches proper volume. KEY VOLUME Adjusting external speaker volume Press <VOLUME KEY> repeatedly during hands free call to adjust external speaker volume. -
Page 15: Message Service
MESSAGE SERVICE Message service is a network dependent feature and is available only when your service provider supports it. Check with your service provider to ensure it is providing message service before using this function. Sending New Text Messages 1. Press <MESSAGE> . Press <1>(New Message). 1: NEW MESSAGE 2. - Page 16 Received Text Message 1. When text message arrives, e.g. 'MESSAGE! 10/12 4:04PM' displays shortly and appears in the icon line. MESSAGE! 2. Press <MESSAGE> ,<2>(Inbox). 10/12 4:04 P 3. Press <VOLUME KEY> (or <*>, <#>) to select message you want to see and press <OK>. 4.
- Page 17 Erasing All Messages 1. Press <MESSAGE> , <7>(Erase MSG). ERASE ALL? 2. Select 'YES' with <VOLUME KEY> (or <*>, <#>). 3. Press <OK>. ▶ Setting/Releasing Message Alert 1. Press <MESSAGE>, <8>(MSG Option), <1>(MSG Alert). 2. Select ON or OFF with <VOLUME KEY>(or <*>, <#>). MESSAGE ALERT 3.
-
Page 18: Fm Radio(Optional)
FM Radio (Optional, PX110F/PX120F/PX130F only) Using FM Radio 1. Press and hold <MENU/FM> to turn on the Radio. 2. Entering Radio Mode, Preset Channel and Frequency display Ch 0 107.1 MHz on the screen. 3. Press <*> or <#> lightly to move the preset channel. 4. -
Page 19: Phone Book
Phone book Internal phone Book Storing in phonebook Searching for Entries in Phonebook Erasing an Entry in Phonebook Erasing all Entries in Phonebook One-Touch Dialing Two-Touch Dialing... -
Page 20: Internal Phone Book
INTERNAL PHONE BOOK Your phone has an internal "Phone Book" in which you can store up to 150 frequently used names and numbers. STORING IN THE MEMORY PHONEBOOK NAME ? 1. Press <MENU>, <1>. 2. Enter the name by pressing the alphanumeric keypad and pressing <OK>... -
Page 21: Searching For Entries In Phonebook
SEARCHING FOR ENTRIES IN PHONEBOOK You can search information stored in the phone book in various way and make a call directly from the phonebook. Searching by Name 1. Press <MENU>, <1>(Phone book), <1> (Search), <1> (Name). NAME ? 2. Enter all or part of the name and press <OK>. Example) Enter A and press <OK>... - Page 22 Searching by Phone Number 1. Press <MENU> (Phone book), <1>(Search), <2>(Number). 2. Enter all or part of the number you remember and PHONE NUMBER ? press <OK>. 3. The phone displays the memory location and names which contain your entry. NOTE: “NO NAME MATCHES”...
-
Page 23: Erasing An Entry In Phonebook
ERASING AN ENTRY IN PHONEBOOK To Erase a Specific Number NAME ? 1. Press <MENU>, <1> (Phonebook) and <3> (Erase). 2. Press one of search options, <1> (Name), <2> (Number) or <3> (Location). 3. Enter name, address, or phone number according to ▶... -
Page 24: One-Touch Dialing
ONE-TOUCH DIALING Memory locations 01 ~ 09 are special one-touch dialing locations. You can dial the numbers stored in 01~09 by pressing just one key. 1. Pick up the handset or press <SPEAKER>. 2. Press and hold the number of the location (1~9) MEMORY 1 containing the number to be called for a moment. -
Page 25: Useful Features
Useful Features Call History Displaying Your phone Number Setting up Your LCD Mute Selecting Time Mode Setting Time Mode Checking and Clearing Call Times Setting Warning Alerts... - Page 26 CALL HISTORY Your phone stores the last 30 outgoing calls, incoming, and missed Calls combined (only when Caller ID function is activated). You can display and redial these numbers. Redialing Outgoing Calls 1. Press <MENU>, <3> (Call History), <3> (Outgoing) NOTE: If there’s no outgoing call history.
- Page 27 Erasing Call History 1. Press <MENU>, <8> (Security). 2. Enter lock code. ENTER LOCK CODE NOTE: Lock code is set as 0000 from the factory. _ _ _ _ To change lock code see page 34 3. Press <6> (Erase Logs). 4.
-
Page 28: Mute
MUTE This feature lets you mute the microphone, so that the other party cannot hear your voice or the sound of your surroundings. This function is only available during conversation. 1. Press <MENU>, <1>(Mute / Un-Mute) during conversation. The message ‘MUTE’ blinks to indicate the function is working. MUTE The other party can no longer hear you, but you can hear them. -
Page 29: Checking And Clearing Call Times
CHECKING AND CLEARING CALL TIMES Checking the Last call Time LAST CALL TIME 1. Press <MENU>, <4> (Time), <2>(Last Call). 3:25 2. Press <CLEAR> to exit the display. Checking Accumulated Incoming Call Time 1. Press <MENU>, <4> (Time), <3>(Total Time), INCOMING CALL <1>... -
Page 30: Setting Warning Alerts
SETTING WARNING ALERTS You can set your phone to sound warning beeps that indicate: - Each minute you are on a phone call - When you are out of the service area Setting/Releasing 1 Minute Alert 1. Press <MENU>, <5> (Sound), <4> (1 Min Alert). 2. -
Page 31: Advanced Features
Advanced Features Changing Greeting Message System Reset Restricting Use of the Phone Locking / Unlocking the Phone Changing the Lock Code World Clock Calculator... -
Page 32: System Reset
CHANGING GREETING MESSAGE This feature lets you change the greeting message that the phone displays during standby mode. 1: CALL TIMER ▼ 1. Press <MENU>, <7> (Configuration). 2: GREETING 2. Press <2>(Greeting). Current greeting displays. 3. Press <OK> to change greeting. 4. -
Page 33: Restricting Use Of The Phone
RESTRICTING USE OF THE PHONE You can restrict the use of the phone by unauthorized persons Restricting Outgoing Calls 1. Press <MENU>, <8> (Security). 1: OUTGOING ▼ 2. Enter lock code. 2: INTERNATIONAL NOTE: Lock code is set as 0000 from the factory. To change lock code, see page 34. -
Page 34: Changing The Lock Code
CHANGING THE LOCK CODE The lock code is preset to 0000 from the factory. You can Change the lock code to any 4 digit number. 1. Press <MENU>, <8> (Security). 2. Enter lock code. ENTER NEW CODE 3. Press <1> (Change Code). _ _ _ _ 4. -
Page 35: Optional Features
Optional Features Call Forwarding Call Waiting Three-way Calling... - Page 36 Call Forwarding Call Forwarding is a feature that lets you forward your incoming calls to another phone number, even if your phone is turned off or is in no service area. Contact your service provider to activate Call Forwarding. Call Waiting Call Waiting alerts you to a second incoming call while you are on the conversation.
-
Page 37: Miscellaneous
Miscellaneous Menu Table Specification... - Page 38 MENU OPTION TABLE Explanation SEARCH NAME Used when searching for a phone number in the phone book by NUMBER name/number/stored memory number LOCATION STORE Used when storing a phone number and 1. PHONEBOOK name in the phone book ERASE NAME Used when erasing a phone number in the phone book NUMBER...
- Page 39 LANGUAGE Select your language MY PHONE # Show your phone number CHANGE CODE Change Lock code EMERGENCY # Show your emergency # RESTRICT OUTGOING Restrict outgoing calls INTERNATIONAL Restrict international calls LONG DISTANCE Restrict long distance calls AUTO LOCK ON / OFF Lock the phone VERSION Show phone information...
