Northern Tool 168650 Owner's Manual

10in. meat saw/grinder with 3/4 horsepower motor
Hide thumbs Also See for 168650:

Advertisement

Quick Links

See also: Instruction Manual
10in. MEAT SAW/GRINDER
With 3/4 Horsepower Motor
OWNER'S MANUAL
WARNING:
Read carefully and understand all INSTRUCTIONS before
operating. Failure to follow the safety rules and other basic
safety precautions may result in serious personal injury.
Item # 168650
0110

Advertisement

loading
Need help?

Need help?

Do you have a question about the 168650 and is the answer not in the manual?

Questions and answers

Related Manuals for Northern Tool 168650

Summary of Contents for Northern Tool 168650

  • Page 1 10in. MEAT SAW/GRINDER With 3/4 Horsepower Motor OWNER'S MANUAL WARNING: Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item # 168650 0110...

  • Page 2: Technical Specifications

    If you have any questions relative to a particular application, DO NOT use the machine until you have first contacted Northern Tool + Equipment to determine if it can or should be performed on the product.
  • Page 3 ELECTRICAL SAFETY WARNING! Always check to ensure the power supply corresponds to the voltage on the rating plate. • Do not abuse the cord. Do not yank tool or extension cords from the receptacle. Keep power and extension cords away from heat, oil, sharp edges or moving parts. Replace damaged cords immediately. Damaged cords may cause a fire and increase the risk of electric shock.
  • Page 4 • Never place your fingers in a position where they could contact the saw if the workpiece should unexpectedly shift or your hand should slip. • Never climb on or allow others to climb on the saw table; it could break or pull the entire unit down. •...

  • Page 5: Fence

    GETTING TO KNOW YOUR MEAT SAW/GRINDER 1. Cover 2. Blade Guard 3. Fence 4. Pusher 5. Pusher Locking Knob 6. Sliding Stainless Steel Table 7. Front Access Door 8. Front Motor Access Panel 9. Rubber Feet 10. Steel Stand 11. Meat Grinder Assembly Locking Handle 12.
  • Page 6 Once the base is assembled, attach the Drive Belt (Part # 55) to the motor wheel (A) and to the Spindle Wheel (B) in the compartment directly above. If the two wheels don’t line up properly, loosen the four bolts (C) holding the motor in place and slide the motor up or down, depending on need.
  • Page 7 REPLACING OR ADJUSTING THE SAW BLADE WARNING! Make sure the machine is unplugged from a power source before replacing or adjusting the saw blade. To prevent serious injury, wear heavy-duty work gloves when working with or around the saw blade. REMOVING THE TABLE Before attempting to remove or replace the blade, the stainless steel table must be removed.

  • Page 8: Bearing 2

    MOUNTING A NEW BLADE Use only authorized replacement blades. To mount a new blade, begin by placing the upper portion of the blade onto the upper drive wheel, teeth facing down and toward you. While doing this, insert the blade in the slot located on the upper guide body (N). (Figure 8) Mount the lower half of the blade on the bottom drive wheel, making sure the blade goes in the slot (O) on the lower guide body.

  • Page 9: Washer

    ASSEMBLING THE POWER SWITCH WARNING! Do not use sharp tools when assembling the power switch, as they may damage the insulation on the wires. If you are unfamiliar with electrical work, contact a professional electrician to perform the installation. The ON/OFF power switch (W) is located in the upper corner of the stand. Attach the switch to the side of the steel stand using two nuts, bolts and washers (X).

  • Page 10: Knob

    Mounting a New Blade The fence (CC) and pusher (DD) have predetermined spaces for attachment to the table. The fence attaches to the side, the pusher attaches to the end. Using socket screws, attach the fence and pusher to their respective areas. (Figure 16) OPERATION Before and after use, wash all parts with warm soapy water.

  • Page 11: Motor

    Meat Grinder Use WARNING! Before using the Meat Grinder, clean all the working parts with hot soapy water. Do not attempt to grind bones or frozen meat as they may damage the grinder. Do not use fingers, utensils or anything other than the Push Rod to press meat into the intake.
  • Page 12 Fence Washer Spring washer Screw M6x16 Bolt M8x12 Stand cover Fix bracket Screw M8x12 Fix bracket Knob Pullcy Knob Motor Working table Bracket Support plate Fence Beam Bearing Switch box Retaining ring Retaining ring Switch Bearing Guide bracket Screw M4x12 Saw blade Guide insert Screw M4x16...
  • Page 14 WARRANTY One-year Limited Warranty Northern Tool + Equipment Co., 2800 Southcross Drive West P.O. Box 1499 Burnsville, MN 55337-0499 Made in China...
