Soloon S6051-L2 Series Operation Instruction

Operation Instruction
S6051-L2 Series LCD Thermostat
1、General
S6051-L1 Series thermostat, with multi
purpose
controller
thermostat's NTC temperature sensor and
motorized fan together, detecting the
room's temperature condition, at the same time comparing to user desire
temperature degree, able to select the appropriate flow rate of warm air
capacity automatically, so therefore
temperature. The manufacturer also has passed ISO 9001:2000,
approved for quality and performance control.
2、Technical Data
Power Consumption: <1.5W
Set-point Range: 10-30℃
Load Current:< 1A
Timing Error: <1%
Accuracy: ±1℃
Output Power:<200W
Dimension：86mm×86mm×13mm(length × Width × Thickness）
Power Supply：220VAC±10%，50/60HZ
3、Symbols
"Power, Turn-on/off ；
"
"Mode, Heating/Cooling Changeover (Optional) ；
"
" "Function, order: Electric heating function→ Time Adjustment →
Timing Turn-on →Timing Turn-off → Return to Original Mode ；
Soloon Electronics (Beijing) Co., Ltd &
Soloon Electronics (Singapore) Co., Ltd
(2009 Edition A)
updated and computerized
function, and by using
produce a comfy room's
" "Fan Speed: Auto, High, Medium and Low;
"∧"Temperature up/down or setting ；
"∨"Temperature down or setting;
4、Menu & Setting
Temperature setting
Programmable ：When it is running, temperature and Power on/off
can not be adjusted ， if it needs to be adjusted ,it must be
reprogrammed .
Manual Mode ：Can set it directly（LCD screen shows "
right corner） 。
Heating/Cooling Setting
Press" "choosing Heating/cooling Mode， press "∧" for confirm、
press "∨" for cancel
Sleeping Function Setting
Touch" " Function key to switch to Sleeping and when the
is flickering, please press"∧" for confirm and "∨"for cancel.
Manual setting
Manual / Programmable switchover, Touch Function "
to programmable (manual) ,When the "
touch"∧" for turn up and "∨"for turn down.
Clock
Touch" " Function key to switch to Clock and when the
is flickering, please press "∧"Set time up；"∨"Set time down
Confirm after 5 sec.
Timing on/of Setting
"on the top
" key switch
"is flickering, please
