Summary of Contents for SVT SVT-4100
-
Page 1: User Manual
SVT-4100 ACCESS CONTROL KEYPAD (SVT19110) User Manual Please read this user manual prior to installing the system, and keep it well for future use. - Page 2 SVT-4100 ACCESS CONTROL KEYPAD - SPECIFICATIONS 100 mm 110 mm Description Mode indicator Matrix Keypads Case screw Technical Parameters Ambient temperature -20 Relative humidity Operating Voltage DC 14.5V Standby Current 90mA Operating Current 120mA...
- Page 3 INSTALLATION (without the rain guard) Install into the wall Screw hole 50mm Screws (fix with button case) INSTALLATION (with the rain guard) Screw anchors Wall hole Rain cover Screws Screws (fix with rain cover)
- Page 4 WIRING CONNECTION Black Power supply DC 14.5V White Unlock button Purple Lock Connect to main board module J1...
- Page 5 OPERATION 1. The original factory defaulted programming password is 1234. 2. In the programming mode, set 40 groups of 4-digit codes for door open. Set programming code 1. Switch off the power, press * and hold, switch on the power. After hearing a long sound, release *.
- Page 6 Add user passwords 1. Enter to the programming mode first. 2. Enter position 01- 30 (31-40 can not set unlocked time as they are normal open/closed). 3. Enter 4-digit password. If long "DI" sound is heard twice, it indicates password stored fails, and this password exists somewhere else.
- Page 8 The design and specifications of this user manual can be changed without any notification to the user. All copyright and interpretation rights are reserved to SVT Innovations Inc.
