Refer to the service manual in the GSPN(see rear cover) for the more information.
BASIC:
SMH6165STG
MODEL:
SMH8165STE
MODEL CODE: SMH8165STE/XAA
Version:
00,01
1. Precaution
2. Product Specification
3. Disassembly and Reassembly
4. Troubleshooting
5. Exploded Views and Part List
6. PCB Diagrams
7. Wiring Diagrams
8. Schematic Diagrams

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMH8165STE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung SMH8165STE

Summary of Contents for Samsung SMH8165STE

  • Page 1 BASIC: SMH6165STG MODEL: SMH8165STE MODEL CODE: SMH8165STE/XAA Version: 00,01 1. Precaution 2. Product Specification 3. Disassembly and Reassembly 4. Troubleshooting 5. Exploded Views and Part List 6. PCB Diagrams 7. Wiring Diagrams 8. Schematic Diagrams Refer to the service manual in the GSPN(see rear cover) for the more information.

  • Page 2: Table Of Contents

    • Contents 1. Precaution ................3 1-1 Safety precautions .

  • Page 3: Precaution

    1. Precaution...

  • Page 4: Safety Precautions

    1. Precaution Follow these special safety precautions . Although the microwave oven is completely safe during ordinary use, repair work can be extremely hazardous due to possible exposure to microwave radiation, as well as potentially lethal high voltages and currents . 1-1 Safety precautions ( All repairs should be done in accordance with the 13.

  • Page 5: Special High Voltage Precautions

    1. Precaution 1- Special High Voltage Precautions High Voltage Warning Do not attempt to measure any of H . V . Capacitor the high voltages --this includes the filament voltage of the magnetron . High voltage is present during any cook cycle . Before touching any components or wiring, always unplug the oven and discharge the high voltage capacitor (See Figure 1-1)

  • Page 6: Specifications

    2. Specifications -1 Features Product Features • Stirrer and Turntable Continually rotates food to ensure even cooking. • Instant Cook Instant On Controls - Allow quick, one touch cooking and reheating. Two speed, 300CFM venting system - Quickly removes smokr and •...

  • Page 7: Table Of Specifications

    2. Specifications 2-3 Table of Specifications Basic Model New Model Items SMH6165STG SMH8165STE (00,01) Cavity Size (cu .ft .) 1 .6 1 .6 Power Power Source 120 V / 60 Hz 120 V / 60 Hz Output Power (Watts) 1000 1000 Power Consumption (Watts/Amp)

  • Page 8: Disassembly And Reassembly

    3. Disassembly and Reassembly MAGNETRON, MOTOR ASSEMBLY, VENT BLOWER AND HIGH VOLTAGE TRANSFORMER Oven must be removed from wall. REMOVING OVEN FROM WALL ( PEOPLE REQUIRED) Oven is hooked on metal tabs at bottom of wall mounting plate and to cabinet by (3) top cabinet bolts . 3-1 Replacement of High Voltage Transformer Parts Explaination Photo...
  • Page 9 3. Disassembly and Reassembly 3-1 Replacement of High Voltage Transformer Parts Explaination Photo Explaination Discharge the High voltage capacitor . High voltage capacitor Disconnect all the leads . Base Remove Base Bottom bottom . HV Trans Take out the HV Trans .

  • Page 10: Replacement Of Magnetron

    3. Disassembly and Reassembly 3- Replacement of Magnetron Parts Explaination Photo Explaination Remove the magnetron including the shield case, permanent magnet, choke coils and capacitors (all of which are contained in one assembly) . Disconnect all lead wires from the magnetron .

  • Page 11: Replacement Of Door Assembly

    3. Disassembly and Reassembly 3-3 Replacement of Door Assembly Parts Disassembly Photo Explaination Insert flat screwdriver into the gap between Door Removal of “A” and Door “C” to remove Door “C” . Be careful Door Assembly when handling Door “C” because it is fragile .Then remove the door assembly .

  • Page 12: Replacement Of Door Assembly

    3. Disassembly and Reassembly 3-3 Replacement of Door Assembly Removal of Remove 2 screws, then handle is detached from Handle Door “A” . Following the procedure as shown in the figure, insert and bend a thin metal plate between Door Removal of “E”...

  • Page 13: Replacement Of Fuse

    3. Disassembly and Reassembly 3-4 Replacement of Fuse Parts Explaination Photo Explaination The fuse is located on the noise filter. Disconnect power and remove grille . Replace the fuse . When 20A fuse blows out by the operation of interlock monitor switch failure, replace Fuse the primary interlock switch, secondary Fuse...

  • Page 14: Replacement Of Stirrer Motor

    3. Disassembly and Reassembly 3-6 Replacement of stirrer motor Parts Explaination Photo Explaination Disconnect power and remove Grille screws(3) . Remove the bracket duct upper . Stirrer Motor Disconnect the stirrer motor wire . Remove stirrer motor screws(2) and pull the stirrer motor .

  • Page 15: Removal Of Stirrer

    3. Disassembly and Reassembly 3-7 Removal of stirrer Parts Explaination Photo Explaination The stirrer is motor driver and located on the upper side of the cavity . The oven uses a top feed wave guide . The stirrer is located in the wave guide and the motor is located on the wave guide .

  • Page 16: Replacement Of Control Circuit Board

    3. Disassembly and Reassembly 3-8 Replacement of Control Circuit Board Parts Explaination Photo Explaination Disconnect power and remove grille . Be sure to ground any static electric charge in your body and never touch the control circuit . Removal of Control Box Remove a screw securing the control box Assembly...

  • Page 17: Replacement Of Cooktop Lamp

    3. Disassembly and Reassembly 3-9 Replacement of Cooktop lamp When replacing the night light, make sure that you are wearing gloves to avoid injury from the heat of the bulb . Parts Explaination Photo Explaination Unplug the oven or turn off the power at the main power .

  • Page 18: Replacement Of Oven Light

    3. Disassembly and Reassembly 3-10 Replacement of Oven Light Parts Explaination Photo Explaination Remove the Grille Remove the bracket Duct upper by Oven Light remove 1 screw . Replace the bulb with a 40 watt appliance bulb .

  • Page 19: Troubleshooting

    4. Troubleshooting 4. Troubleshooting 4-1 Error Code Numbering Rule ERROR CODE NUMBERING RULE is applied to a microwave oven and an oven .(CMO, OTR, Grill, Convection, Commercial etc .) All sensors and devices have their own number . ex) Gas Sensor = 1, Temp . Sensor = 2, . . . Of each device, No .1 and No .2 refer to “Open Error”...

  • Page 20: Electrical Malfunction

    4. Troubleshooting 4-3 Electrical Malfunction 4-3-1 -SE- “- SE -” is displayed. Is the key not recognized at all? Is the key recognized intermittently? Is a specific key not recognized? The membrane is defective. S/W Error Replace the Control Panel. After Power >...
  • Page 21 4. Troubleshooting 4-3- E-11 Sensor Open Error (E-11) : Check if the sensor housing is inserted into the connector Connect the sensor. of the main PCB. Is the sensor disconnected? sensor Is the sensor wire Connect the : Check if the sensor wire is damaged, if the connected properly? wire properly.
  • Page 22 4. Troubleshooting 4-3-3 E-1 Sensor Short Error (E-12) : Check if both terminals of the sensor are slightly shorted. Remove the shorted part Is the sensor shorted? of the temperature sensor. sensor : Check if the sensor and related parts such as the connector or Is the sensor terminal part Remove any foreign soldering parts are slightly shorted.
  • Page 23 4. Troubleshooting 4-3-4 E-13, E-14 Sensor Max Time Error (E-13, E-14) Does it heat up without Insert food : Since heating without placing food into placing food into it? and heat it again. the oven may damage the product, take care. Does it heat with completely Place food with : Since heating completely dried food...

  • Page 24: Electrical Malfunction

    4. Troubleshooting PRECAUTION 1. CHECK GROUNDING BEFORE CHECKING FOR TROUBLE . . BE CAREFUL OF THE HIGH VOLTAGE CIRCUIT . 3. DISCHARGE THE HIGH VOLTAGE CAPACITOR . WHEN CHECKING THE CONTINUITY OF THE SWITCHES OR TRANSFORMER, DISCONNECT ONE LEAD WIRE FROM THESE PARTS AND THEN CHECK CONTINUITY WITHOUT THE POWER SOURCE ON .
  • Page 25 Oven does not accept key input Open or loose connection of membrane key pad to Ass’y PCB 4. Troubleshooting Shorted or open membrane panel Replace PCB main. Defective Ass’y PCB Timer starts countdown but no microwave oscillation . (No heat while oven lamp and fan motor turn on.) Off-alignment of latch switches Adjust door and latch switches.
  • Page 26 Consult electrician. Loose wiring of door sensing switch on when plugged in (Intermittent oscillation) Aging of magnetron Fan motor turns Consult electrician. Loose wiring of door sensing switch on when plugged in Aging of magnetron Fan motor turns Consult electrician. Loose wiring of door sensing switch on when plugged in 4.

  • Page 27: Exploded Views (00,01Version)

    5. Exploded Views and Parts List 5-1 Exploded Views (00Version) P012 P034 M134 P007 P002 P003 P032 P039 P004 M061 P015 M024 M036 M050 P016 U003 M001 T030 M030 H024 T036 P001 T037 T038 P141 M020 M087 P109 C081 M059 M015 M067 M023...
  • Page 28 5. Exploded Views and Parts List 5. Exploded Views and Parts List 5-1 Exploded Views (01Version) P012 P034 P036 P007 P025 P002 P224 P024 P032 P039 P004 M061 P015 M024 M036 M050 P016 U003 M001 T030 M030 H024 T036 P001 T037 T038 P141...

  • Page 29: Exploded Views And Parts List

    5. Exploded Views and Parts List 5- Version List (00,01Version) (S.N.A : SERVICE NOT AVAILABLE) Code No. Version Description Specification Q’ty Remark C001 DE94-01806C ASSY CONTROL PANEL SMH8165STG/XAA,STS,-, C082 DE94-01807V ASSY CONTROL BOX SMH8165ST,120V60HZ,STS, SNA - C089 DE39-40673A WIRE HARNESS-H 120V60HZ,OTR6 ALL MODEL,G D006 DE64-00337A...

  • Page 30: Main Parts List (00,01Version)

    5. Exploded Views and Parts List 5-3 Main Parts List (00Version) (S.N.A : SERVICE NOT AVAILABLE) Code No. Description Specification Q’ty Remark B001 3405-001034 SWITCH-MICRO 125/250VAC,16A,200GF,SPST-N B002 3405-001033 SWITCH-MICRO 125/250VAC 16A,200GF,SPSTNC B006 DE66-00168A LATCH-BODY MODULAR-2,PP,-,-,-,-,- B013 DE66-90106B LEVER-SWITCH LOWER PP,T1 .4,-,-,2 .0g,OTR B018 DE96-00414A ASSY BODY LATCH...
  • Page 31 5. Exploded Views and Parts List 5-3 Main Parts List (Continued) (S.N.A : SERVICE NOT AVAILABLE) Code No. Description Specification Q’ty Remark P012 DE92-90242E ASSY-HOOD DAMPER OTR 6/7,OUTSOURCING PAR PANEL OUTER P012 DE92-90242D ASSY-HOOD DAMPER JVM-1870,JVM250BL OTR4, P015 DE92-90509D ASSY-BKT DUCT UPPER MO1650WA/XAA,SS OTR, P016 DE61-50469A...
  • Page 32 5. Exploded Views and Parts List 5-3 Main Parts List (01Version) (S.N.A : SERVICE NOT AVAILABLE) Code No. Description Specification Q’ty Remark B001 3405-001034 SWITCH-MICRO 125/250VAC,16A,200GF,SPST-N B002 3405-001033 SWITCH-MICRO 125/250VAC 16A,200GF,SPSTNC B006 DE66-00168A LATCH-BODY MODULAR-2,PP,-,-,-,-,- B013 DE66-90106B LEVER-SWITCH LOWER PP,T1 .4,-,-,2 .0g,OTR B018 DE96-00414A ASSY BODY LATCH...
  • Page 33 5. Exploded Views and Parts List 5-3 Main Parts List (Continued) (S.N.A : SERVICE NOT AVAILABLE) Code No. Description Specification Q’ty Remark P015 DE92-90509D ASSY-BKT DUCT UPPER MO1650WA/XAA,SS OTR, P016 DE61-50469A BRACKET-DUCT UPPER -,SECC,T0 .4,W206,L272 P024 DE32-60011A SENSOR-GAS ST-MWO,-,-,-,-,-,- P025 DE61-90111A HOLDER-SENSOR -,POM(DURACON-M90-02),-,-,...

  • Page 34: Door Parts List (00,01Version)

    MODULAR-2,POM,-,-,-,-,BLK,- D020 DE94-01814A ASSY HANDLE SMH8165BG/XAA,-,BLK,ARCADIA D024 DE64-02053A SCREEN-DOOR(B) SMH8165,TEMPERED GLASS,T3 D037 DE94-01816A ASSY DOOR A SMH8165STG/XAA,-,STS,ARCADIA D049 DE94-01811D ASSY DOOR SMH8165STE/XAA,PP,STS,ARCADIA, D060 6107-001175 SPRING-ES HSWR,BLUING,PI0 .95,D8 .5,L48 .4 D073 DE63-00516A EARTH-DOOR SMH8165ST,STS430,0 .15,-,-,-,- Z779 DE64-01946A INLAY-DOOR SMH8165BG/XAA,STS430,0 .3 MM,-...
  • Page 35 SPRING-KEY BLUING,HSWR,PI1 .95,D8 .75,L43 D011 DE64-01308A DOOR-KEY MODULAR-2,POM,-,-,-,-,BLK,- D020 DE94-01814A ASSY HANDLE SMH8165BG/XAA,-,BLK,ARCADIA D024 DE64-02053A SCREEN-DOOR(B) SMH8165,TEMPERED GLASS,T3 D037 DE94-01816A ASSY DOOR A SMH8165STG/XAA,-,STS,ARCADIA D049 DE94-01811D ASSY DOOR SMH8165STE/XAA,PP,STS,ARCADIA, D073 DE63-00516A EARTH-DOOR SMH8165ST,STS430,0 .15,-,-,-,- Z779 DE64-01946A INLAY-DOOR SMH8165BG/XAA,STS430,0 .3 MM,-...

  • Page 36: Control Parts List (00,01Version)

    5. Exploded Views and Parts List 5-5 Control Parts List (00Version) C082 C001 C003 C001 P157 C005 C009 C089 C004 Z783 (S.N.A : SERVICE NOT AVAILABLE) Code No. Description Specification Q’ty SA/SNA Remark C001 DE94-01806C ASSY CONTROL PANEL SMH8165STG/XAA,STS,-, D006 C001 DE94-01820A ASSY CONTROL PANEL...
  • Page 37 5. Exploded Views and Parts List 5-5 Control Parts List (01Version) C082 C001 C003 C001 P157 C005 C009 C089 C004 Z783 (S.N.A : SERVICE NOT AVAILABLE) Code No. Description Specification Q’ty SA/SNA Remark C001 DE94-01806C ASSY CONTROL PANEL SMH8165STG/XAA,STS,-, D006 C001 DE94-01820A ASSY CONTROL PANEL...

  • Page 38: Standard Parts List (00,01Version)

    5. Exploded Views and Parts List 5-6 Standard Parts List (00Version) (S.N.A : SERVICE NOT AVAILABLE) Level Code No. Description Specification Q’ty Remark 6002-000643 SCREW-TAPPING TH,+,2S,M4,L10,ZPC(YEL),SW BASE PLATE,CAVITY FRONT 6002-001173 SCREW-TAPPING FH,+,2S,M4,L12,ZPC(BLK),MS GRILLE 6003-001568 SCREW-TAPTITE FH,TORX,-,B-TITE,M4,L14,NI B/D-LATCH 6006-001170 SCREW-ASSY TAPP WS,TH,+,M4,L10,ZPC(YEL) P-CORD,WIRE HARNESS-H DE60-10045A SCREW-TAP PH...
  • Page 39 5. Exploded Views and Parts List 5-6 Standard Parts List (01Version) (S.N.A : SERVICE NOT AVAILABLE) Level Code No. Description Specification Q’ty Remark 6002-000643 SCREW-TAPPING TH,+,2S,M4,L10,ZPC(YEL),SW BASE PLATE,CAVITY FRONT 6002-001173 SCREW-TAPPING FH,+,2S,M4,L12,ZPC(BLK),MS GRILLE 6003-001568 SCREW-TAPTITE FH,TORX,-,B-TITE,M4,L14,NI B/D-LATCH 6006-001170 SCREW-ASSY TAPP WS,TH,+,M4,L10,ZPC(YEL) P-CORD,WIRE HARNESS-H DE60-10045A SCREW-TAP PH...

  • Page 40: Pcb Diagrams

    6. PCB Diagrams 6. PCB Diagrams 6-1 PCB Diagrams (00Version) (This Document can not be used without Samsung’s authorization)

  • Page 41: Pcb Diagrams (00,01Version)

    6. PCB Diagrams 6- PCB Diagrams (00Version) (This Document can not be used without Samsung’s authorization)
  • Page 42 6. PCB Diagrams 6. PCB Diagrams 6-1 PCB Diagrams (01Version) (This Document can not be used without Samsung’s authorization)
  • Page 43 6. PCB Diagrams 6- PCB Diagrams (01Version) (This Document can not be used without Samsung’s authorization)

  • Page 44: Wiring Diagrams

    7. Wiring Diagrams 7. Wiring Diagrams 7-1 Wiring Diagrams (00Version) (This Document can not be used without Samsung’s authorization)
  • Page 45 7. Wiring Diagrams 7-1 Wiring Diagrams (00Version) (This Document can not be used without Samsung’s authorization)
  • Page 46 7. Wiring Diagrams 7. Wiring Diagrams 7-1 Wiring Diagrams (01Version) (This Document can not be used without Samsung’s authorization)
  • Page 47 7. Wiring Diagrams 7-1 Wiring Diagrams (01Version) (This Document can not be used without Samsung’s authorization)

  • Page 48: Schematic Diagrams

    8. Schematic Diagrams 8. Schematic Diagrams 8-1 Schematic Diagrams (00Version) (This Document can not be used without Samsung’s authorization) BZ501 CBE2220BA LOUVER VENT. BOOST IC101 TMP86CM72FG-CHUN DSP101 VFD25-0717...
  • Page 49 8. Schematic Diagrams 8. Schematic Diagrams 8-1 Schematic Diagrams (01Version) (This Document can not be used without Samsung’s authorization) BZ501 CBE2220BA LOUVER VENT. BOOST IC101 TMP86CM72FG-CHUN DSP101 VFD25-0714...
  • Page 50 .samsungportal .com cis .samsungportal .com Europe europe .samsungportal .com China china .samsungportal .com Asia asia .samsungportal .com Mideast & Africa mea .samsungportal .com © Samsung Electronics Co ., Ltd . March . 2009 Printed in Korea Code No . : DE68-04983A...
