OWNER'S MANUAL

9537

FOR MODEL

BKNHUSM

IF YOU ENCOUNTER ANY PROBLEMS WITH THE

ASSEMBLY OR FUNCTIONING OF THIS TOY,

DO NOT RETURN IT TO THE STORE

WHERE YOU PURCHASED IT

THEY ARE NOT EQUIPPED TO ASSIST YOU.

CALL THE APPROPRIATE NUMBER BELOW

TO REACH A CUSTOMER SERVICE

REPRESENTATIVE.

A M AV CUSTOMER TOLL FREE:

1 - 8 0 0 - 3 8 7 - 7 5 8 6

Y O U M U S T C H A R G E THE BAT T E RY

FOR 24 HOURS BEFORE F I R S T U S E

S E E PAGE 9 FOR I N S T R U C T I O N S .

Table of Contents

Need help?

Do you have a question about the 9537 and is the answer not in the manual?

Questions and answers

Summary of Contents for Power Rider 9537

Page 1 OWNER’S MANUAL 9537 FOR MODEL BKNHUSM IF YOU ENCOUNTER ANY PROBLEMS WITH THE ASSEMBLY OR FUNCTIONING OF THIS TOY, DO NOT RETURN IT TO THE STORE WHERE YOU PURCHASED IT THEY ARE NOT EQUIPPED TO ASSIST YOU. CALL THE APPROPRIATE NUMBER BELOW TO REACH A CUSTOMER SERVICE REPRESENTATIVE.
Page 2: Wiring Diagram
• Follow all the instructions carefully to ensure that your child operates and enjoys this vehicle as safely as possible. • Only use the AMAV Power Rider™ on level surfaces or inclines of less than 6 . Stay away from steep slopes or inclines, stairs, driveways or ramps.
Page 3: Parts List
Parts list This parts list applies to AMAV Power Rider™, model 9537, Night Heat. Parts indicated in UNDERLINE must be installed by the consumer. This is not an assembly diagram. For assembly instructions, see the following pages. Key Quan. DESCRIPTION CODE ....1 .
Page 4 “Snap-Fit” Assembly Figure 1 Figure 3 Figure 2 Dashboard Figure 4 Figure 1 When you take the car and all the parts out of the box, you will see the body of the car, as shown in Figure 1. Figures 2, 3 and 4 To attach the dashboard to the car, just line up the cen- ter hole with the steering column, and slide the dash- board down.
Page 5 Figure 6 Figure 5 Windshield Hood Figures 5 and 6 Figures 7, 8 and 9 Now you can attach the windshield and side mirrors to To attach the front hood, just line up the two tabs at the the car. As you can see in Figure 5, the windshield and base of the hood with the slots in the car body, just in mirrors slant towards the back of the car when installed.
Page 6: Adjustable Seat
B. Adjustable seat Figure 14 Your Power Rider™ seat can be adjusted for a grow- ing child. It fits into slots in the car body as shown in Figure 14. For smaller children the seat fits into slots “B” and “D”,and for taller children, into slots “A”...
Page 7: Steering Wheel
Locking pin Figure 15 Figure 16 Steering Wheel Figure 15 To attach the steering wheel, first make sure that the wheels are pointing straight. You can move them by hand if necessary. Now take the steering wheel, and hold it so that you are facing it.
Page 8 Figure 24 Roll Bar, Seat Belt Now slide the end of the long strap through the hole in the roll bar. There are two holes in the roll bar. a n d F l a g Slide the strap throught the roll bar on the same side as the long strap.
Page 9: Battery Charging
Use of a damaged vehicle could result in a fire causing serious injury. • Use only AMAV Power Rider™ replacement parts, available at a Power Rider™ Service Center. To locate the nearest Service Center, call the telephone number on page 1.
Page 10: Note To Parents
WARNING BATTERY DISPOSAL Your 6-volt sealed lead acid battery cannot be IF BATTERY LEAK DEVELOPS: - Avoid contact with leaking battery acid. disposed of in your household trash. Place it - Place battery in a plastic bag, and follow in a plastic bag. It must be collected and recy- disposal instructions.
Page 11 Stickers and Decals... Figures 31 to 37 You are now ready to decorate your car with the sticker and decal sheets. To apply the decals, just peel them off the sticker and decal sheets, and apply them to the car. Press down firmly, and wipe with a clean dry cloth to remove any bubbles.
Page 12 M ..Phone touch pad N ..Vent O ..Stereo P ..Heater Q ..Power Rider R ..Oil S ..Fuel T ..Speedometer U .
Page 13: Safe Operation Rules
WARNING BATTERY DISPOSAL Your 6-volt sealed lead acid battery cannot be disposed of in IF BATTERY LEAK DEVELOPS: your household trash. Place it in a plastic bag. It must be col- - Avoid cont act with leaking battery acid. lected and recycled or disposed of in a manner that respects - Place battery in a plastic bag, and follow the environment.
Page 14: Troubleshooting Guide
Check all wire connections. Make sure they are tight. Fuse is blown. Change fuse with 30 amp fuse, from an authorized Power Rider™ Service Center. For the center nearest you, call the customer ser- vice number on page 1. 6 volt battery is dead.
Page 15 Fuse is blown. Replace fuse with authorized replacement part. Too much weight in the vehicle. Your Power rider™ car is designed to carry only one child. Total weight is 55 lbs. (25 kg) Do not attempt to tow anything. Too much stress on the motor due Avoid inclines of more than 6°.
Page 16 The AMAV Power Rider™ must only be used under adult supervision. In order for this Limited Warranty to apply, such use must be normal use and does not cover the Power Rider™ nor batteries if damaged by unreasonable use, abuse, misuse, neglect, water damage, improper ser- vice, accident or other cause not arising from defects in materials or workmanship.
