Karel DSS80 Owner's Manual

Direct station select module

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Karel DSS80

Direct Station Select Module

Easy to Use

Owner's

Guide

Edition 3.1

Table of Contents

Summary of Contents for Karel DSS80

Page 1 Karel DSS80 Direct Station Select Module Easy to Use Owner’s Guide Edition 3.1...
Page 2: Table Of Contents
CONTENTS SECTION PAGE INTRODUCTION OVERVIEW I.1. DSS80 KEYS PROGRAMMING & USING DSS80 KEYS II.1. EXTENSION KEYS II.2. LINE KEYS II.3. COMMON POOL KEYS II.4. PRIVATE POOL KEYS II.5. FEATURE KEYS II.6. CLEARING A KEY II.7. AUTO SETTING...
Page 3: Introduction
DSS80 Direct Station Select Module facilities of KAREL MS48 / MS48-ISDN / MS128 / MS224 Telephone System. The guide is prepared assuming that the DSS80 user is familiar with MS48 / MS48-ISDN / MS128 / MS224 Easy To Use Owner's Guide.
Page 5: Overview
I. OVERVIEW DSS80 Module, which is indeed a keypad consisting of 80 keys and corresponding LEDs, is mainly designed to be used together with Karel LT48 & LT48-H Feature Phones and OP48 & OP48-H Consoles. Figure 1 illustrates the outlook of a DSS80 Module.
Page 6 These keys can be used to enter parameters during programming of DSS80. DSS80 Programming Keys: These keys have letters “S, T, C, M, P, E, A, R” as indicators. These keys can be used to enter and exit programming mode of DSS80.
Page 7: Programming & Using Dss80 Keys
Press “ E ” key until the third “beep”. DSS80 exits the programming mode automatically 30 seconds after the last use of a DSS80 key. However, it is recommended to use “ E ” key to exit Programming Mode so as to prevent any possible program errors.
Page 8: Ii.1. Extension Keys
CTIVATE Press “ S ” key until the third “beep”. Press key that you want to program. Dial 4-digit physical extension number using DSS80 Numeric Keys. IMPORTANT 4-digit physical extension number should be entered even: ∗ When Flexible Numbering is activated on the system, or ∗...
Page 9: Ii.2. Line Keys
II.2. LINE KEYS PROGRAMMING • CTIVATE Press “ T ” key until the third “beep”. Press key that you want to program. Dial 2-digit line number using DSS80 Numeric Keys. USING • CTIVATE LINE ACCESS Lift handset. Press line key.
Page 10: Ii.3. Common Pool Keys
COMMON POOL KEYS PROGRAMMING • CTIVATE Press “ C ” key until the third “beep”. Press key that you want to program. Dial 2-digit common pool register number (00,…,49) using DSS80 Numeric Keys. USING • CTIVATE Lift handset. Press common pool key.
Page 11: Ii.5. Feature Keys
Primary Function of the 9 key programmed can be at most 9 digits. 3. Instead of private pool numbers, any feature code can be assigned to DSS80 keys as well. To do that, instead of the external number, the feature code with a "...
Page 12 Press feature key. Press feature key. Dial your password from Dial your password from telephone. telephone. Dial “1” from telephone. Dial “0” from telephone. Receive internal dial tone. Receive internal dial tone. Karel DSS80 Easy To Use Owner’s Guide Edition 3.2...
Page 13 Hour (00..23) and minute Receive internal dial tone. (00..59). Receive internal dial tone. 5. Feature 05: (Do Not Disturb) • A CTIVATE ANCEL Lift handset. Press feature key. Receive internal dial tone. Karel DSS80 Easy To Use Owner’s Guide Edition 3.2...
Page 14 Press feature key Retrieve parked call by dialing the line number. Converse. 8. Feature 08: (Parallel Operators-Operator Only Feature) • A CTIVATE ANCEL Lift handset. Press feature key. Receive internal dial tone. Karel DSS80 Easy To Use Owner’s Guide Edition 3.2...
Page 15 12. Feature 12: (Background Music) • A CTIVATE ANCEL Lift handset. Press feature key. Hang up. 13. Feature 13: (External Call Pick Up) • A CTIVATE Lift handset. Press feature key. Converse. Karel DSS80 Easy To Use Owner’s Guide Edition 3.2...
Page 16 CTIVATE ( CTIVATE ( WHILE IDLE WHILE TALKING TO THE DOORPHONE You are conversing through the Lift handset. doorphone. Press feature key. Press feature key. Receive internal dial tone. Continue conversing. Karel DSS80 Easy To Use Owner’s Guide Edition 3.2...
Page 17: Ii.6. Clearing A Key
Receive internal dial tone. II.6. CLEARING A KEY • CTIVATE Press “ T ” key until the third “beep”. Press key that you want to clear. Dial “ 00 ” using DSS80 Numeric Keys. Karel DSS80 Easy To Use Owner’s Guide Edition 3.2...
Page 18: Ii.7. Auto Setting
II.7. AUTO SETTING Using Auto Setting facility, the Primary Functions of all DSS80 keys can be programmed at once by assigning one of the several options. These options are given in items below. • CTIVATE Press “ R ” key until the third “beep”.
Page 19 In all of the assembled programming options, the Secondary Functions of the keys are set to be empty. If any of the ports that are assigned to DSS80 keys does not exist in the current system capacity, then error tone is received if these ports are tried to be accessed by pressing the relevant key of the DSS80 module.
