USER MANUAL
www.activeon.com

Advertisement

Table of Contents
loading

Summary of Contents for activeom CX

  • Page 1 USER MANUAL www.activeon.com...

  • Page 2: Table Of Contents

    8. User menu 8-1. Playback mode 8-2. User setting 9. Rechargeable Battery 10. Smart phone control 11. Connect ACTIVEON CX to smartphone(using ACTIVEON App) 12. Transferring data to computer 13. Firmware update 14. Features and speci cations 15. Inside the Package ※...

  • Page 3: Name Of Each Part

    ENGLISH www.activeon.com * Please read this manual carefully before the use! 1. Name of each part Mode / Navigation Internal MIC LED Indicator Power / Shutter (Top, Bottom, Front, Back) LCD Screen Speaker Li-ion battery slot microSD Card Slot (microSD Card not included) Mini USB port Tripod hole (Bottom) HD OUT...

  • Page 4: Operation & Button Description

    2. Operation & button description ACTIVEON CX is operated by two buttons. ( button , button ) ● )button features “Power, Shutter and Enter”. ● )button features “Mode change, Navigation and User menu”. ● The feature of buttons are de ned as below table.

  • Page 5: Start The Camera

    ) button to move select bar on OSD menu or change setting 3. Start the camera 1. Open the battery cover and insert ACTIVEON CX Li-ion battery. 2. Insert microSD Card on the microSD Card slot. (The camera will not record when microSD Card is not inserted.) 3.

  • Page 6: Lcd Screen Shot

    4. LCD screen shot Video screen Description Function ① ② ③ ④ Current mode Shows current mode (video or photo) ① Shows current shooting mode Shooting (Video - Auto stop / Looping / Timelapse) ② mode (Photo - Self timer / Timelapse / Burst) Recording time Shows recording time information ③...

  • Page 7: Graphical Icon Description

    5. Graphical icon description Mode Function Icons Description Video mode Current mode Photo mode Battery Shows battery capacity status Shows FOV setting status (Super wide / Wide / Medium / Narrow) Zoom Shows current zoom level (None / x2 / x3 / x4) Live Shows current recording e ect status (Sports / Aqua / Night) E ect...

  • Page 8: Video Recording

    Function Description Mode Icons Records video until set time. Auto stop (1min / 5min / 10min / 30min) Captures images in set intervals and creates a timelapse video le. Timelapse Video (1sec / 3sec / 5sec / 10sec /30sec / 60sec) Continuously records a video for a set time until you stop.

  • Page 9: Photo Shoot

    7. Photo shoot Press ( ) button to change to photo mode. ● Mode changes as ● Video mode Photo mode Photo burst Photo timelapse in turn. 1. Press ( ) button to shoot photo. 2. In 'Photo Timelapse' mode, Press ( ) button to stop photo shooting.

  • Page 10: Playback Mode

    8-1. Playback mode User can view recorded video or photo on the screen. ● Press ( ) button to select control panel on top menu. ● While the le is playing, you can call the play control panel by ( ) button.

  • Page 11: User Setting

    Function Operation Photo playback Press ( ) button to use control panel. Press ( ) button to select. 8-2. User setting Function Sub menu Description WiFi APP Turn on WiFi to connect with smartphone Turn o WiFi to disconnect with smartphone WiFi BACK Return to previous menu...
  • Page 12 Function Description Sub menu Shooting mode Manual / Self-Timer / Burst / Timelapse Self-Timer 5sec / 10sec / 15sec Burst 3 photos per 1 sec / 5 photos per 1 sec Photo Setting Timelapse 1sec / 3sec / 5sec / 10sec / 30sec / 60sec Resolution 5MP / 4MP / 3MP BACK...
  • Page 13 Function Description Sub menu Filter O / Black&White / Warm / Negative / Sepia / Red / Green / Blue Time Stamp On / O E ect O / Aqua / Sports / Night E ect Setting White Balance Auto / 3000K / 5500K / 6500K 100 / 200 / 400 / 1600 / Auto BACK Return to previous menu...

  • Page 14: Rechargeable Battery

    Function Description Sub menu Auto Power o Never / 1min / 2min / 3min Default Setting Yes / No Version Info Displays current camera software version General Setting Displays current WiFi SSID and Password WiFi Info BACK Return to previous menu 9.

  • Page 15: Smartphone Control

    * You can take a video and photo, and adjust camera setting on ‘ACTIVEON’ ‘ACTIVEON’ features will be upgraded through application update through your smartphone. 11. Connect ACTIVEON CX to smartphone(using ACTIVEON App) On your camera Turn on ‘WiFi APP’ function in ACTIVEON CX. ●...
  • Page 16 11. Connect ACTIVEON CX to smartphone(using ACTIVEON App) On your Smartphone On your smartphone or tablet, turn the WiFi on and select the network CX0-xxxxxx under WiFi setting. ● Default password is ‘1234567890’ . ● 'ACTIVEON' app on your smartphone or tablet.

  • Page 17: Transferring Data To Computer

    While the camera is connected to a battery charger or car charger for recharge, ● the camera can record while it is recharging. 1. Power on ACTIVEON CX. 2. Connect the camera to a computer via USB cable. 3. The camera LCD will display as 'USB Ready' .

  • Page 18: Firmware Update

    1. Format the memory card, and copy rmware le to the root directory of microSD Card. 2. Insert the microSD to ACTIVEON CX and turn on the power. 3. Firmware upgrade will automatically start as showing the updating status on the screen.

  • Page 19: Features And Speci Cations

    14. Features and specifications “ACTIVEON CX” 1080p 30fps Action camera ● Full HD(1920 x 1080) resolution, 30fps recording ● 196ft(60m) waterproof housing ● 4M pixel high precision digital image CMOS sensor ● 170° wide-angle eld of view (FOV) (* Video recording 160 ° FOV) ●...

  • Page 20: Inside The Package

    15. Inside the Package...

  • Page 22: Caution

    CAUTION It could be exploded if the battery is inappropriate type. Please insert proper type of battery according to instructions. The symbol means that according to local laws and regulations your product should be disposed of separatly from household waste. When this product reaches its end of life, take it to a collection point designated by local authorities.

  • Page 23: Rf Exposure Information (Sar)

    RF Exposure Information (SAR) NOTE : This appliance and its antenna must not be co-located of operation in conjuction with any other antenna or transmitter. A minimum separation distance of 20cm must be maintained between the antenna and the person for this appliance to satisfy the RF exposure requirements. This device meets the U.S.
  • Page 24 USA Warranty www.activeon.com...
  • Page 25 ACTIVEON LIMITED WARRANTY This limited warranty is provided by ACTIVEON to the original end user purchaser (“Purchaser”), when delivered in new condition in its original container. The Product is warranted to be free from manufacturing defects under normal use and service for a period of 12 months from the date of original purchase (“Warranty Period”). Where there is no evidence of the date of original purchase, ACTIVEON shall consider the date of manufacture as the date of original purchase.
  • Page 26 EU Warranty www.activeon.com...
  • Page 27 ACTIVEON LIMITED WARRANTY (EU) The following limited warranty is provided by ACTIVEON with respect to the ACTIVEON product (“Product”) purchased by the original end user purchaser (“Purchaser”), when delivered in new condition in its original container. Consumers have legal rights under applicable national legislation governing the sale of consumer goods. Such rights are not a ected by the warranties in this limited warranty. The Product is warranted to be free from manufacturing defects under normal use and service for a period of 24 months as from the date of original purchase (“Warranty Period”).
