SubliJetR Ricoh GX7000 Installation Manual

Ricoh GX7000 – Installation Guide:

Ricoh (OEM) Printer setup

1.) Open the printer box, remove the cables and other accessories, and place them aside. Next, remove
the printer from the box, and place it on a sturdy work surface with sufficient operational clearances
(the printer weighs approximately 43 lb). Finally, remove the orange adhesive tape and attach the
power cord and the USB cable. DO NOT POWER ON THE PRINTER AT THIs TIME.
2.) Remove the SubliJet-R ink cartridges from their packages. Open the right front cover on the printer, and
insert the cartridges in the order indicated—from left to right (as you face the printer): black (K), cyan (C),
magenta (M) and yellow (Y). Press each cartridge in until it engages securely, and close the cover once
all of the cartridges are in place. Never shake or agitate the cartridges.
3.) Remove the paper tray, pull the cover straight up, and adjust the guides for the paper size you will be
using. Load the paper, put the cover back on, and reinsert the tray into the printer. For larger paper sizes,
refer to the documentation provided with your Ricoh printer for extending the paper tray.
(4:20)
(1:2)
PAGE 1 Of 2 >>
