IPCorder KNR-1004/1008
Quick Installation Guide
Thank you for purchasing this KOUK
will quickly guide you through the setup process. For more information please refer to the User manual available
on the enclosed CD or download it from http://www.ipcorder.com.
Important safety instructions
The purchased device works under voltage. If wrongly handled the device could be damaged or cause injury to the
person handling the device.
• The manufacturer is not liable for potential damage caused by incorrect usage or placing the device in an unsuitable
environment.
• The device is not designed for outdoor use, operational temperature 5 - 40 °C.
• Do not use the device in an environment with strong vibrations.
• Unauthorized modification of this device can damage it or cause a fire.
• Prevent from contact with fluids; do not expose the device to high temperatures.
• Protect the device from falling.
• It is permitted to use accessories only intended for the device (hard disks, cables, etc.).
• In case of the malfunction of the device, contact your dealer.
• The manufacturer is not liable for damage to the product that is caused by unusual or unforeseeable circumstances
(force majeure).
This guide is intended for IPCorder KNR-1004/1008. Individual models differ by the maximum possible number
of simultaneously connected cameras or videoservers:
• KNR-1004: up to 4 cameras or videoservers
• KNR-1008: up to 8 cameras or videoservers
M product. Before you start using it, please read this installation guide which
1
Advertisement
Table of Contents
Related Manuals for Koukaam IPCorder KNR-1004
Summary of Contents for Koukaam IPCorder KNR-1004
-
Page 1: Quick Installation Guide
• The manufacturer is not liable for damage to the product that is caused by unusual or unforeseeable circumstances (force majeure). This guide is intended for IPCorder KNR-1004/1008. Individual models differ by the maximum possible number of simultaneously connected cameras or videoservers: •... - Page 2 1. Package contents In the package you will find your IPCorder, power adapter 12 V / 2 , Hex key tool, network cable, an installation CD, the installation guide and licence agreement. 2. How to install IPCorder in several minutes •...
- Page 3 • Connect the device to the computer network and plug it into a power outlet. • On start-up IPCorder will attempt to obtain the IP address automatically via DHCP. If unsuccessful it is set up to the default value of 192.168.1.78. If the IPCorder is in the same subnet as the PC used to access it, it should appear in the Network Places folder under Microsoft Windows.
- Page 4 • For easier physical localisation of IPCorder you can click on the button Locate – a red diode with an exclamation mark symbol will begin to blink on IPCorder. • Click twice on the required device. The interface of the IPCorder Service mode will be displayed in the default internet browser, this will be indicated by a lit red diode with an exclamation mark symbol.
- Page 5 The front panel of IPCorder KNR-1004/1008 contains 4 types of LED diode signals: • The Network Diode ( ) indicates the activity of the network adapter. • The Storage Diode ( ) blinks green if the hard disk is active.
- Page 6 utton function description Button ON/OFF ( • If pressed for less than 3 seconds it will switch off the acoustic signal in defined cases (see below). • If pressed for more than 5 seconds (accompanied by a short beep) it will switch the device on or off, a running application will end safely.
- Page 7 4. System Requirements The system requirements are partly dependent on the version of the installed firmware. The client computer should meet the following minimum requirements for the installed firmware: • Operating system: Microsoft Windows 2003, 2008, XP, Vista, 7 (32 and 64 bit version); Mac OS X 10.5 (only Intel x86), 10.6 and 10.7;...
- Page 8 If the problems continue, contact your vendor, or directly contact the manufacturer's technical support department of KOUK M a.s. company at the address support@koukaam.se. Before you do so, please check that your IPCorder is equipped with the latest version of firmware (your problem is probably resolved in the new version). We also recommend visiting F Q at http://www.ipcorder.com in the support section where the F Qs are fully answered.
