- Page 1 CEAN RESENCE Technologies Underwater IP Camera System OPT-06SD/HD User’s Manual Version 2.1 ™ OceanCam Models: OPT-06SD, OPT-06SDE, OPT-06HD, OPT-06HDE, OPT-06FHD & OPT-06FHDE Ocean Presence Technologies ©2011-2013 All Rights Reserved.
- Page 2 OR IN CONNECTION WITH THIS MANUAL, THE SOFTWARE OR OTHER INFORMATION CONTAINED HEREIN OR THE USE THEREOF. Ocean Presence Technologies reserves the right to make any modification to this manual or the information contained herein at any time without notice.
-
Page 3: Table Of Contents
Position Presets & Tours..... 16 8.6.2 Camera Specifications.... 27 4.10 Image Transmission ......17 8.6.3 Camera Components ..... 28 Housing Specifications......28 Mounting the Camera......29 Underwater Cable Wiring ....29 Ocean Presence Technologies Copyright ©2011-2012 All Rights Reserved. Page 3... -
Page 4: Shipped Components
HE BOX AND PACKING MATERIALS Configuring the network SHOULD BE RETAINED IN THE EVENT THAT Deployment testing SHIPPING IS REQUIRED Step #4 is covered in detail in Section 6 of this manual. Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 4... -
Page 5: Connecting The Camera
The power light will stay on and the network light will blink for two minutes at which time the turret will realign to the home position. Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 5... -
Page 6: Deployment Testing
If moisture is seen on the top inside of the dome, either the O-ring was not properly sealed or additional moisture removal may be required. If a dry system cannot be obtained, please contact the manufacturer for assistance. Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 6... -
Page 7: System Description
The power light will stay on and the network light will blink for two minutes at which time the turret will realign to the home position. Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 7... -
Page 8: Housing
The camera can also be powered from 48 VDC batteries. DO NOT PLUG IN OR REMOVE THE HOUSING P E CONNECTOR WHILE UNDERWATER WHEN THE POWER IS ON! Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 8... -
Page 9: Moisture Purging System
Weights should not be used for permanent placement or in high surge. Standard lead dive weights can be used instead of the weight tray. Attach weights to the metal bars on either side of the housing. Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 9... -
Page 10: Camera Operations
Each camera will appear on a separate line. The IP Address of the camera will be assigned using DHCP. This indicates that the software has automatically detected the camera. Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 10... -
Page 11: Configuring The Camera
When light is reduced, Camera features include: image size, Motion-JPEG video retains a high quality image but reduces the bandwidth by Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 11... -
Page 12: Upright Mounting
ActiveX viewer. The ActiveX button displays the ActiveX viewer. Plug-in free is used for non- windows platforms. Tool is used to download system utilities. This operation is Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 12... -
Page 13: Area Zoom
1) area zoom or 2) vector dragging. To return to the home position, click on the center of the panorama panel. Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 13... -
Page 14: Panorama Control
Selecting the record button will start the capture of video from the camera. The square stop button will end the recording. The stored video can be found by opening the video file folder. Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 14... -
Page 15: Free Plug-In Viewer
Stream type, image size, frame rate and preset position. (Displayed only three different camera controls are when a camera preset position is selected from the drop-down menus below registered.) the viewing window. Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 15... -
Page 16: Operation Authority
Resume time on inactivity defines the restart or stop the tour after it has stopped by manual pan, tilt or zoom operation or by camera movement to the preset position Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 16... -
Page 17: Image Transmission
Configure Tour A to Tour E respectively. Each tour setting consists of 5 items: On/Off, Sequence, Speed, Stay time. Effective period. Select the tour to configure from the drop-down list. Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 17... -
Page 18: System Accessories
When wiring single connector power cables to 48 VDC batteries, JPEG O AUDIO IS OUTPUT IF be careful to maintain proper JPEG/F LASH IS USED FOR THE polarity. FREE VIEWER Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 18... -
Page 19: Wireless Network
Apple iPhone. For more details, see Smart Phone Viewer User’s Manual on the Software CD or at: http://www.sony.net/ipela/snc Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 19... -
Page 20: Pre-Deployment Testing
WARNING: D O NOT EXCEED THE DEPTH LIMITATION OF THE HOUSING AILURE TO HEED THIS WARNING MAY RESULT IN LEAKAGE AND POSSIBLY IMPLOSION AND SERIOUS INJURY Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 20... -
Page 21: Care & Maintenance
Allen key provided. O NOT PRESS DOWN ON THE TOP OF THE DOME WHEN REATTACHING THE DOME ASSEMBLY TO THE HOUSING Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 21... -
Page 22: O-Ring Greasing Technique
If the housing shows excessive accumulation of algae growth, it should be detached from the cables and brought to the surface for a more thorough cleaning. Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 22... -
Page 23: Appendix
ESETTING TO FACTORY SETTING IS NOT not be properly set to accept DHCP ADVISABLE UNLESS ALL OTHER automatic address assignments. Check the TROUBLESHOOTING PROCEDURES HAVE Windows Network Connections. FAILED TO RESOLVE THE PROBLEM Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 23... -
Page 24: Dsn Error/Server Not Found
If the camera is not any of the silicone grease into the o-ring shown active DHCP addresses, a camera groove. Use fingers to thoroughly reset as described under Section 6.1.3 Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 24... - Page 25 O-ring being flattened against the mating surfaces is observed. The areas of the O-ring that is not in contact with mating Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 25...
-
Page 26: Warranty
The Contact Ocean Presence Technologies at manufacturer is not liable for any accidents info@oceanpresence.com for more information. during which this housing was in use. -
Page 27: Camera Specifications
Power requirement AC 24 V, High-Power-over-Ethernet, IEEE802.3at compliant (Class 4) Power consumption 25 W max Dimensions ø 5 7/8 x 7 5/8 inches (ø 147.4 mm x 190.9 mm ) Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 27... -
Page 28: Camera Components
Underwater-mateable connectors allows housing to be removed for maintenance Moisture control Silica dry bags 11.85” (301 mm) x 10.25” (260 mm) x 13.86” (352 mm) Size (L x W x H) 24 lbs (9.5 kg) Weight Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 28... -
Page 29: Mounting The Camera
NDERWATER ABLE IRING The Power-over-Ethernet underwater cable has been specially designed for long life in harsh conditions. It employs both power and network connections as shown in the diagram below. Ocean Presence Technologies Copyright ©2011-2013 All Rights Reserved. Page 29...
