  • Page 1 ViewPoint 2240 User Manual AVP-2240-804-001...
  • Page 2: Explanation Of Graphical Symbols

    A product and cart combination should be moved or other product (including amplifiers) that produce with care. Quick stops, excessive force, and heat. Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 3 This Class A digital apparatus complies with Canadian ICES-003. CE Declaration of Conformity (For EU Customers) We, Arrive Systems, Inc., declare under our sole responsibility that the Arrive component to which this declaration relates, is in conformity with General Emissions Standard EN50081-1 and with Generic Immunity Standard EN50082-1 1992.
  • Page 4 16. When using this unit for a long time, this unit may of disposal. become warm. Disconnect the cables, then leave this unit alone for cooling. 17. To prevent damage by lightning, keep the cables disconnected during a lightning storm. Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 5 IP addresses or phone numbers in illustrative content is unintentional and coincidental. ARRIVE disclaims ownership of the brand or use or association of the name “Visionergy” and/ or “Verity” as a real business or business entity and does not recommend the use of this name by others for a similar purpose of creating examples to avoid confusion.
  • Page 6: Table Of Contents

    6. Configuring the unit using Desktop Client....17 6.1 ViewPoint Recorder ..........17 6.2 Matterhorn Server .............19 6.3 Classroom Location ..........20 6.4 Viewpoint Web Manager ..........21 6.5 User Settings ..............22 6.6 Modules ..............25 6.7 About ................26 Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 7 7.7 Modules ...............34 7.8 About ................34 8. Recorder ................35 9. Content Manager ..............40 10. Player .................44 11. Manage and Replay the recorded session ( Matterhorn Server)...............45 12. Web Manager ..............45 13. References ...............53 Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 8: Introduction

    (called rich media). Arrive ViewPoint™ eliminates the need for a dedicated computer capture agent on the presenters’ side, reducing the physical layout of connectors, space and power consumption.
  • Page 9: Features And Specifications

    Video Input 2: HDMI Presentation Input USB 3.0 ports DVI-I port HDMI output port Network Port USB 2.0 ports RS232 Port ( for Camera Control) Audio Output Mirocphone Input Power Input Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 10: Hardware

    BreakOut Cable Mounting Kit 1(Wall), 1(Rack) Screws Installation requirements • Requires Arrive EM Server (EMS) software for scheduling and central management, 2.4 Operating requirements Power requirements Input - 100-240 V, 50-60 Hz 0.5a, Output - 19v 6A Power consumption 70-120w Operating temperature 5 to 30°C (23 - 86 °F)
  • Page 11: Product Information

    Integrates with Opencast Matterhorn server for publishing and archiving the recorded sessions. • Enables scheduled recording via Arrive InfoPoint interface with interoperability with 3rd party LMS in Matterhorn domain. • Enables scheduled recording via Opencast Matterhorn server v1.3 & v1.4 •...
  • Page 12: Setting Up The Unit

    3.2 Connecting the unit Arrive ViewPoint is an ideal 1RU solution for wall mount, under desk mount, table-top or rack mount. Fix the rack mount or wall mount provided with the unit as per requirement.Ensure all the safety guidelines for mounting the unit is followed.
  • Page 13 Note: If the connections to Video Input 1 and Video Input 2 are interchanged, the audio may not get recorded properly. The diagram below shows a sample connectivity schema for Arrive ViewPoint™. Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 14: Before You Begin

    Arrive ViewPoint™ easily registers to Matterhorn v1.3 and v1.4 servers. Arrive ViewPoint™ can be configured and managed through two different interfaces, namely the Desktop Client, and AVP Control Console. The Desktop Client is available to the user through the display unit/monitor connected to the appliance.
  • Page 15: Power-On Behavior

    At first power-on, the unit boots up and the End User License Agreement (EULA) screen is displayed: Figure 3: EULA Acceptance Click on Accept Agreement.The Desktop Client setup screen is displayed upon license acceptance, . Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 16 The subsequent power-on displays the Recording Screen on the Desktop Client as shown below. You can click on to navigate to the setup screen. Figure 5: Subsequent Power-ons- Recording Screen Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 17: Configuring The Unit Using Desktop Client

    (one time behavior). If a DHCP server is not existing in the network, the details need to be populated manually. The ViewPoint Recorder tab allows user to configure the following fields: Figure 6: Desktop Client- ViewPoint Recorder Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 18 Note: Any change made through this tab forces the unit to restart. The configuration can be altered anytime. If you click on Save when no changes are made, the application alerts that no changes are made to the existing configuration. Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 19: Matterhorn Server

    The above values are read from the configuration file. On unit restart, the unit is re- registered with Matterhorn. Note: Please refer to References section in the manual to know more about the Matterhorn server. Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 20: Classroom Location

    6.3 Classroom Location This is an optional tab and is configured only if integration with Arrive Edgeless Media Server (EMS) is available. The EMS must be available in the same network as the unit. When this integration exists, ViewPoint becomes a resource to the EMS.
  • Page 21: Viewpoint Web Manager

    Enter the Password( if existing) Note: By default, the Username and Password sections are blank. In case a Username and Password is provided, the same is used to login to Web Manager. Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 22: User Settings

    Select the audio input type. Available: Analog Audio ,Embedded Audio Audio Input Note: If Analog Audio is the selected type, ensure the breakout cable is connected to the relevant audio card. Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 23 Figure 11: Desktop Client -Repository- Local Select the protocol NFS or CIFS. This location will be mounted to the unit to save the recordings. Enter the location. If required, furnish the Username and Password. Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 24 So repository changes should be made thoughtfully. When the network repository is accessed, ensure that high speed network connection exists. The response will take a longer time when compared to local repository. Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 25: Modules

    Only if the integration is enabled from this interface will the corresponding tabs be available for set-up. When Classroom Location is enabled, the schedules are synchronised from the Arrive Edgeless Media Server. Further enabling schedule recording automates the recording process.
  • Page 26: About

    A new window appears showing new updates and its description. • Click on Install. The updates get installed. • The application restarts. Note: Updates can be installed only from the Desktop Client. Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 27 Figure 16: Desktop Client -About - Install Updates Figure 17: Desktop Client -About - Install Updates Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 28: Configuring The Unit Using The Avp Control Console

    On authentication, the AVP Control Console homepage is displayed. Figure 19: Home Page - AVP Control Console To navigate to setup page; Click on To access Content Manager; Click on . Refer to section 9 for more details. Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 29 The setup interface for both AVP Control Console and Desktop Client is almost identical except that the application updates cannot be installed on the unit from the About Tab; refer to Section 6.8 About. Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 30: Viewpoint Recorder

    For steps and more details, refer to Section 6. Configuring the Unit using Desktop Client. 7.1 ViewPoint Recorder Figure 22: AVP Control Console - ViewPoint Recorder 7.2 Matterhorn Server Figure 23: AVP Control Console- Matterhorn Server Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 31: Classroom Location

    7.3 Classroom Location Figure 24: AVP Control Console- Classroom Location 7.4 ViewPoint Web Manager Figure 25: AVP Control Console - ViewPoint WebManger Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 32: User Settings

    7.5 User Settings Figure 26: AVP Control Console- User Settings 7.6 Repository Figure 27: AVP Control Console- Repository- Local Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 33 Figure 28: AVP Control Console- Repository- NFS Figure 29: AVP Control Console- Repository- CIFS Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 34: Modules

    The About tab of the AVP Control Console provides current information about the application. No information about the application updates or interface to Install Updates is provided. Figure 31: AVP Control Console- About Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 35: Recorder

    When the unit is powered on, the recording page is displayed by default. Press the Record button to initiate the recording. Figure 32: Desktop Client- Recording Screen To stop the recording, press the Stop button Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 36 Camera Zoom (increase/ decrease) and Camera Presets (1 to 6). When integrated with Arrive Edgeless Media Server and automatic recording is enabled, the recording for the schedule fetched from the EM Server is automatic. The subject and the presenter name will be automatically populated from the server.
  • Page 37 Figure 34: Desktop Client- Automatic Recording The schedule can be cancelled even 2 minutes prior to commencement. Figure 35: Desktop Client- Schedule cancel Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 38 AVP Control Console When the unit is accessed from the AVP Control Console after authentication,the recording page is displayed by default. (Home page). Figure 37: AVP Control Console- Automatic Recording Page Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 39 The two text boxes (Subject, Presenter) are to be populated by the user prior to recording. No changes can be done after recording is initiated. The boxes can be left blank. Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 40: Content Manager

    Matterhorn server and the field for Course/ Series is filled. Size Size of the recording Duration Duration of the recording Status** Gives the publishing status of the recording Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 41 • The file publication to Matterhorn is initiated. The publication status notice is displayed on the screen. • Accessing Content Manager from AVP Control Console: Click on from the Recording Page. Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 42 Control Console. Download the Recording • Select the recording. • Click on Download Button. • The file is downloaded to the default browser folder. Once downloaded, it can be viewed locally. Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 43 Figure 42: AVP Control Console - Convert Again In case the file does not play properly, the file needs to be re-converted. From the Player homepage, click on “Convert Again” for a re-conversion. Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 44: Player

    Note: It is mentioned earlier that recordings can be downloaded from the Content Manager of AVP Control Console. The recording is downloaded to the browser download location. The recording can be opened and viewed from this location also. Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 45: Manage And Replay The Recorded Session ( Matterhorn Server)

    Web Manager of the ViewPoint is an optional module. It is a web interface that can be accessed http://IPaddress/vpwebmanager, The IP address is assigned and shared by the administrator of the network. The Web Manager monitors all the units in the network. Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 46 Please refer the Modules and ViewPoint Web Manager sections for more details. When accessed, user authentication is prompted. Default Login: admin Default Password: admin Figure 45: Login Page - Web Manager On authentication, the homepage is displayed. Figure 46: HomePage- Web Manager Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 47 The list of units from the network registered with the web manager are listed. HostName of the Unit; in case of integration with Arrive HostName Edgeless Media Server, then the Room Name is displayed Building Name of the building where the unit is placed...
  • Page 48 Time elapsed. The recording cannot be stopped before 10 seconds. The Stop button is inactive for that period. Note: The Action Tools and Remote Control options are disabled. Figure 49: Web Manager- Ongoing Recording Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 49 Click on Stop Recording button; to stop recoding. • Figure 50: Web Manager- Stop Recording Restart Application • Click on Restart Application button. Figure 51: Web Manager- Restart Application • To confirm, Click on OK. The application restarts. Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 50: Remote Control

    Figure 53: Web Manager- Remote Control- No AMT » If Active Management Technology( AMT) is configured in the unit BIOS, the following can be performed on the unit. Power On, Power Off and Restart. Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 51 60 seconds. During in period Video Preview button is disabled. This preview window can be closed manually before 60 seconds has elapsed. Note: To access video preview, Java has to be enabled. The required guidelines are available at http://www.java.com/en/download/help/ enable_browser.xml Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 52 Click on Recorder to connect to the AVP Control Console from the web manager. Figure 57: Web Manager- AVP Control Console You can configure and the handle the unit as required. Refer to 6. Configuring the Unit using AVP Control Console for more details. Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 53: References

    For more information on the Matterhorn server, refer http://opencast.org/matterhorn For successful integration with Arrive InfoPoint and avail the complete functionality of Classroom Location and automatic recording refer to: This document guides you through the first steps of deploying and configuring Arrive Edgeless Server Platform.
  • Page 54: Additional Resources

    ARRIVE Support and Services teams deliver an innovative advisory approach to help ARRIVE customers better utilize and derive more value from ARRIVE solutions. In addition to answering questions and resolving technical concerns, ARRIVE...
  • Page 55 Topics that are not covered under an Arrive CarePoint program, where an ARRIVE Customer Support team member will proactively provide the most appropriate alternative resource, include: Training-ARRIVE Academy is the best resource for training, offering classroom training, real-time Learning, custom training, self-study guides, and an annual customer conference.
  • Page 56 (formatting formulas, parameters, etc.). • The third-party software publisher. • Assistance connecting your ARRIVE data to third-party • Your own IT staff. reporting tools. • Training on use of third-party products. Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 57 (OS), database • ARRIVE Community. platforms, Internet Information Server (IIS), browsers, etc. • Your external vendor. Hardware Warranty Information Please visit Arrive CarePoint for updated information on warranty for computing equipment Copyright © 2014 Arrive Systems, Inc. All rights reserved.
  • Page 58 Arrive Systems, Inc. 6737 Katella Ave. Cypress, CA 90630, USA Toll Free: +1-844-427-7483 (USA / Canada) Fax: +1-510-281-7546 www.arrivesys.com Email: info@arrivesys.com Copyright © 2014 Arrive Systems, Inc. All rights reserved.
