- Page 1 XI006AE 6-channel Audio and Video Capture Adapter User’s Guide Rev 1.0 2011/7/27...
-
Page 3: Table Of Contents
Content Preface ............................1 Minimum Hardware Configuration ....................1 Recommended Hardware Configuration ..................1 System Requirements ........................1 Hardware and Driver Installation ....................2 Connection of Input ........................2 SD Video Signal(CVBS) ....................... 2 Audio Signal .......................... 3 Video Capture Device Instruction ....................3 Display "Filter Properties Dialog Window"... -
Page 5: Preface
XI006AE is featured with small and exquisite bulk, superior performance. The XI006AE can simultaneously capture six Standard-Definition video signals, and six stereo analog audio signals. The user’s guide will provide with necessary instruction for proper use of XI006AE capture adapter. 2 Minimum Hardware Configuration ... -
Page 6: Hardware And Driver Installation
Microsoft Windows 7 Microsoft Windows Server 2008 R2 5 Hardware and Driver Installation Please refer to " XI006AE Installation Guide" to install the hardware and the driver. 6 Connection of Input 6.1 SD Video Signal(CVBS) Figure 1, SD video signal connection sketch map Copyright ©... -
Page 7: Audio Signal
Video 5 (XI006AE Adapter x) Video 6 (XI006AE Adapter x) The Video 1 to 6(XI006AE Adapter x) is corresponding to yellow video BNC interface with the same number in breakout cable. XI006AE not only offers basic options, such as image brightness, contrast, hue, saturation, Gamma and so on, but also provides additional options for setting function. -
Page 8: Display "Filter Properties Dialog Window" In Common Software
7.1 Display "Filter Properties Dialog Window" In Common Software Double click "AmCap.exe", choose SD video device "Video 1 (XI006AE Adapter1)" in "Devices" menu, then click "Video Capture Filter ..." in "Settings" menu, pop-up " Filter Properties dialog window". 7.2 “Device” Instruction... - Page 9 relevant version number when you solve problems. Firmware: if new features need to upgrade the firmware, we should first backup it and then upgrade the firmware. Notes: The different versions of the firmware and hardware cannot be mixed together, or else it will get error when upgrade. Additionally, do not power outage in the process of firmware upgrade, otherwise it will lead to upgrade firmware fail, then the capture card will not work.
-
Page 10: Capture Device "Advanced Settings" Instruction
7.3 Capture Device "Advanced Settings" Instruction Figure 4, "Advanced Settings" page Copyright © 2009-2010 All Rights Reserved. Nanjing Universal Networks Co. 6/16... -
Page 11: Capture
7.3.1 Capture Square Pixel Mode: image is not deformation, XY pixel and aspect ratio are both 4:3, PAL input is 768x576, NTSC input is 640x480, square pixel mode is default. Non Square Pixel Mode: image is a little deformation, PAL input is 720x576,NTSC input is 720x480. -
Page 12: Video Formats Setting
8.1 Display "Filter Output Pin" In Common Software AMCAP: Double click "AmCap.exe", choose HD video device "HD Video (XI006AE Adapter1)" in "Devices" menu, then click “Video Capture Pin ...”in "Settings" menu, pop-up " Filter Output Pin ". 8.2 “Out Format” Instruction Figure 5,””properties page... -
Page 13: Audio Capture Device Instruction
9 Audio Capture Device Instruction XI006AE is based on the Microsoft DirectShow interface. After installation in operating system, the relevant audio devices will be added on. Any software which is compatible with DirectSound, DirectShow can use the recording device for capturing sound. -
Page 14: Windows Vista, Windows 7, Windows 2008, Windows 2008 R2
3. In "Mixer", select "Audio 1 (XI006AE Adapter x)", click "OK" button. 4. Corresponding volume control project will be displayed, this time you can operate volume and "quiet" according to your requirement. ， Windows XP/2003“VolumeControl”-“Properties” dialogue Figure 6 9.2 Windows Vista, Windows 7, Windows 2008, Windows 2008 R2... -
Page 15: Compatible Software Instruction
1. In system notification icon area on right corner right-click " "button, select "Recording devices" in pop-up menu. 2. In pop-up list which displays recording device, select " Audio 1 XI006AE Adapter x ", click "Properties" button, system will pop up device properties dialog window. - Page 16 DirectShow interface, and audio capture software which is based DirectSound interface, such as: Windows Media Encoder Adobe Flash Media Live Encoder Real Producer Plus Video LAN for Windows Copyright © 2009-2010 All Rights Reserved. Nanjing Universal Networks Co.
