Summary of Contents for goldall Lighting HYP006F

Page 1 LE D WAS H LIGHT( 4 in 1) USER MANUAL...
Page 2: Before You Begin
1.BEFORE YOU BEGIN What is included Ø 1 x Fixture Ø 1 x Power cable with plug Ø 1 x User Manua Unpacking Instructions Immediately upon receiving a fixture, carefully unpack the carton; check the contents to ensure that all parts are present, and have been received in good condition.
Page 3: Safety Instructions
Safety Instructions WARNING! Please read these instructions carefully, which includes important information about the installation, usage and maintenance of this product.. The following symbols are used to identify important safety information on the product and in this manual: DANGER! DANGER! WARNING! WARNING! WARNING!
Page 4: Specifications
2.INTRODUCTION Specifications l Voltage Rating: AC100V 240V 50-60Hz l Power Rating: 70W l LED Quantity: 14X4-in-1(RGBW) l LED: 350mA l Beam Angle: 20°/30° /40°(option) l Ingress Protection: IP65 /indoor(option) l Product Size: 255 x 205 x290mm l Package Size: 315x280x345 mm l N/W:4.0Kg Features l RGBW color mixing with or without DMX controller...
Page 5: Product Overview
Product Overview Safety Power in Power out DMX IN DMX OUT Control board Dimensions Hanging bracket/ floor stand Bracket adjustment knob...
Page 6: Installation Requirement
3.SETUP Installation Requirement l This product can be used in a variety of situations, can hang and put on the ground. l If hanging the fixture for over head use, then please follow the below steps. l Please choose the suitable location to put or hang the light when installing it. You must use the exclusive clamp hanger and screw when hanging it, and make sure the weight of the light is within limits of the hanger.
Page 7: Connection Of Dmx Signal Wire
Connection of DMX Signal Wire Please use the fixture controller wire specially when use the DMX512 Controller. Connect the (male) 3 pin connector side of the DMX cable to the output (female) 3 pin connector of the first fixture. Connect the end of the cable coming from the first fixture which will have a (male) 3 pin connector to the input connector of the next fixture consisting of a (female) 3 pin connector.
Page 8: Control Panel Functions
4.OPERATING INSTRUCTIONS Control Panel Functions BUTTON FUNCTION MODE Exits from the current menu or function Enables the currently displayed menu or sets the currently selected ENTER value in to the selected function Navigates upwards through the menu list and increases the numeric value when in a function Navigates downwards through the menu list and decreases the numeric DOWN...
Page 9 MAIN SUB- FUNCTION SELECTION INSTRUCTION FUNCTION Sets the operating mode for the fixture:to receive signal from a DMX controller (DMX) .receive signal or Download programs from Master fixture. (Slave) 11 channels D+RGBW+S… 3 channels Hue Saturation Value 3 channels 4 channels D+RGB 4channels RGBW...
Page 10 Operating instructions 1.Upload custom program or set to another machine Set all the fixtures which receive custom programs from the source fixture as 1 Press MODE button until is displayed. 2 Then press ENTER button, use UP/DOWN buttons until is displayed. Press MODE return to MENU 3 On the Master unit, Press MODE button until is displayed on source fixture.
Page 11: Dmx512 Controller Mode
When 'R000' display on the screen, press the UP/DOWN button to choose the value. Repeat this step to edit the value of 'G000', 'b000','W000', 'S000', 'T000' and 'F000'. Please pay attention for the 'S' is the rate of strobe. 'T' is the operating time of the present step, the value is between 0 to 255.
Page 12: Dmx512 Channel Values
DMX512 Channel Values 11 channels STAG Channel Value Description 1 Dimming 000~255 0-100% 2 RED 000~255 0-100%(Or STEP TIME when CUS.01-10 is activated) 3 Green 000~255 0-10 0%(Or FADE TIME when CUS.01-10 is activated) 4 Blue 000~255 0-100% 5 white 000~255 0-100% 6 Macro color...
Page 13 Channel Value Description 9 Auto Speed 000~255 0~100%(only when using ch.8) 10 Dimming speed 000~255 Dimming speed 11 ID 000~255 ID address selection ID ADDRESS SELECTION VALUE FUNCTION VALUE FUNCTION VALUE FUNCTION 000~009 All Ids ID23 ID46 010~019 ID24 ID47 020~029 ID25 ID48...
Page 14 MASTER DIMMER Channels 1 controls the intensity of the currently projected color When the slider is at the highest position (255), then the intensity of the output is at themaximum. RED, GREEN BLUE AND WHITE COLOR SELECTION Channels 2, 3,4 and 5 control the intensity ratio of each of the Red, Green, Blue&white LEDs.
Page 15 3 channels HSV Channel Value Description 000~255 000~255 Saturation 000~255 Value (Intensity) Note: In HSV mode, Hue stands for the visible light, such as red, yellow, and cyan, etc. Saturation refers to the dominance of hue in the color; when saturation is at 100%, then the color is at its purest.
Page 16: Id Address Instructions
5 channels Co2.d Channel Value Description 000~255 Dimming 000~255 000~255 Green 000~255 Blue 000~255 White 6 channels Co2.s Channel Value Description 000~255 Dimming 000~255 000~255 Green 000~255 Blue 000~255 White 000~255 Strobe ID Address Instructions 1.Setting ID address 1 Access control panel function by pressing MODE until is displayed.
Page 17 Select STAG channel on fixture's control panel (Please refer to DMX512 Channels Selection). The figure above shows a simple DMX layout which has used three units at each DMX address. The three units have different ID addresses. In the DMX address: 001, the user can control the first three lights simultaneously.
Page 18: Master/Slave Control Mode
Master/Slave Control Mode 1 Setting master machine ess control panel function by pressing MODE until is displayed. Press ENTER, select by pressing UP/DOWN buttons. Press ENTER, and then press MODE to exit. You can choose pre-set programs, the range is o1--10 .
Page 19 Symptom(s) Possible Solution(s) Breaker/Fuse keeps Check total load placed on the electrical circuit blowing Check for a short in the electrical wiring: internal and/or external Check for power on Mains -Note: In the event of autoswitching transformer failure, the unit Device has no power can be sent in for repair;...
Page 20: Blow-Out Diagram
Blow-out Diagram. Description Part Number Glass cover 6P00605 LED Lens assembly 4170705 LED Metal-core PCB assembly 2P00603 Electronic Transformer 5080102 LED Driver PCB (Master) 2P00604 Display PCB 2P00605 Display Clear plastic cover 803004 Display watertight seal 6P00613 house 6P00606 power socket 5050101 DMX socket 5040201...
