- Page 1 Victory II automated luminaire rel. 1.02 user manual...
-
Page 2: General Warnings
• The minimum distance between the projector and the surface to be illuminated must not be less than 1.5 m. • In case of serious functioning problems, switch off the equipment and contact the nearest SGM retailer or the manufacturer directly for inspection. -
Page 3: Table Of Contents
3 - gobo ch 4 - shutter/strobe ch 7 - gobo rotation ch 8 - palette ch 9 - prism and prism rotation ch 10 - reset Made in Italy by SGM Electronic Printed in September, 1998 • Rel. 1.02... -
Page 4: Main Characteristics
Main Characteristics The intelligent projectors of the Victory series spring from a design philosophy which all SGM products have for years had in common. These new scanners, because of their avant-garde performance, cer- tainly take top place among the best in world-wide production. The accurate study of the functions, the search for innovative materials, the continuous technical updating have led to the realization of a certainly unique product: Victorys are projectors suitable for a multitude of applications. -
Page 5: Iris
(the absolute fastest among the projectors in this range) and occurs in 0.08 sec. Diffused light beams Victory II is equipped with a frost filter to allow emission of diffused light beams to create coloured backgrounds and settings with fixed or variable colours. The frost filter may be combined with the whole range of colours available. -
Page 6: Technical Characteristics
Mirror: Ultra-high reflection, in special glass. Electronics: Entirely developed by engineers of the SGM Research & Development Laboratory. Has a power supply card (CS 0207) and a logic card (CS 0208). Settings: By means of dip-switches, to address the control channels of the projector and to set the selectable options: - PAN/TILT scanning inversion;... -
Page 7: Positioning And Focusing
Positioning and Focusing Positioning To position the projector, the channels must be set as follows: Channel 1 dimmer 100% open Channel 2 colour white Channel 3 gobos no figure Channel 4 shutter/strobe open Channel 5/6 pan/tilt centre position Channel 7 gobo rotation Channel 8 palette... -
Page 8: Victory Ii 250 Maintenance
Victory II 250 Maintenance Access to inside Victory has a particular way of access to the inside of the projector. Remaining fixed as installed, the projector can be opened exactly halfway in longitudinal direction, thus allowing easy access to the inner parts in order to carry out any necessary operation, be it cleaning, lamp change or service of any mechanical or electrical part. -
Page 9: Colour Replacement
The start address is set with the dip-switch located on the back of the projector. The address can be modified also when the projector is on. 64 128 256 Victory II PRO150 #1 (ch 01 ÷ 12) Victory II PRO150 #2 (ch 13 ÷ 25) Victory II PRO150 #3 (ch 26 ÷ 38) Victory II PRO150 #4 (ch 39 ÷... -
Page 10: Victory Connections
Victory Connections The projector is fitted with a DMX512 and RS-232/423 input/output. When making the start address settings, consider that 4 channels are used (channel 1 is not operatio- nal in this version). For connection in a DMX network always use balanced microphonic cables type RF 60/12 2x0.25mm or similar and select a good quality to prevent malfunctioning of the projector. -
Page 11: Options" Dip-Switch
“OPTIONS” Dip-switches PAN /TILT Normal - Reverse O P T IO N S The PAN and TILT dip-switches are used to invert vertical and hori- 1 2 3 4 zontal scanning from top to bottom, from left to right and vice versa. - Page 12 2 colour Value Color 0÷9 White On Victory II the 8 base colours are multi- plied by a colour-temperature conversion fil- 10÷19 White + Yellow ter, thus obtaining 16 colours. The top-qua- 20÷29 Yellow lity 38 ( dichroic filters are carefully selected 30÷39...
- Page 13 4 variable-speed rotating gobos adjustable in the two directions. Gobo change with or without blackout. The linearity and gobo rotation speed, thanks to an exclusive system created by SGM engineers, is unequalled, and selectable in direction and speed. Channel 3 interacts with channel 4. From channel 4 the operator may select gobo change with...
- Page 14 ch 4 shutter/strobe The shutter/strobe is adjustable from Value Shutter/Strobe Channel 4. 0÷9 Shutter closed 10÷19 Strobe - 1 fps Use of ìMusic Flashî is recommended (see table), which gives a remarkable visual 20÷29 Strobe - 1.39 fps impact. 30÷39 Strobe - 1.65 fps Channel 4 interacts with channel 2 and 40÷49...
- Page 15 Channel 8 controls activation of the palettes which activate the colour conversion and frost filter. The colour conversion filter allows doubling the number of colours projected by Victory II: from the 8 base colours 16 are thus obtained. The frost filter allows generating diffused light, ideal to create coloured backgrounds.
