Summary of Contents for Show Technology LEDPAR182
-
Page 1: User Manual
LED PAR Quad-18 IP65 User Manual LEDPAR182 LED PAR Quad-18 IP65 www.showtech.com.au... -
Page 2: Table Of Contents
LED PAR Quad-18 IP65 Table of Contents 1. Safety instructions…………………………………………………………3 1.1 Overhead rigging …………………………………………………….4 1.2 Power Connection …………………………………………………..6 1.3 Cleaning and Maintenance ……………………………………..6 2. Menu Navigation ............7 3. DMX Allocation ...............9 4. Photometric Data ………...........11 5. Technical Specifications ………………………………………………..12... -
Page 3: Safety Instructions
LED PAR Quad-18 IP65 1. Safety Instructions FOR SAFE AND EFFICIENT OPERATION Be careful with heat and extreme temperature. Avoid exposing it to direct rays of sun near a heating appliance. Do not put it in a temperature below 41°F/5°C, or exceeding 95°F/35°C. Keep away from humidity, water and dust. -
Page 4: Overhead Rigging
LED PAR Quad-18 IP65 Take care with the power cable. Never pull the power cable to remove the plug from the receptacle, be sure to hold the plug. When not using the unit for an extended period of time be sure to disconnect the plug form the receptacle. -
Page 5: White
LED PAR Quad-18 IP65 DANGER OF FIRE! When installing the device, make sure there is no highly-flammable material (decoration articles, etc.) within a distance of min. 0.5m. Mount the projector with the mounting bracket to your trussing system using an appropriate clamp. -
Page 6: Power Connection
LED PAR Quad-18 IP65 1.2. Power Connection !! CAUTION!! Never leave this device running unattended!! Every person that is involved with this item has to be qualified!! Connect item with main plug. The voltage and frequency must exactly be the same as stated on the device. -
Page 7: Menu Navigation
LED PAR Quad-18 IP65 2.0 Menu Navigation Menu level Menu level 1 Remark Default: 10CH，d 1 5:GB 6:RB 7:RG 8:RGB 9:RW 10:GW 11:BW 12:RGW 13:RBW 14:GBW 15:RGBW Default: RGBW... -
Page 8: Dmx Allocation
LED PAR Quad-18 IP65 P1：15-color program (fading) low-high-low；（ Default：P1） P2：15-color program (fading) low-high P3：15-color program (fading) high-low P4：mixing color switching P5：running P1-P4 Default：S100 Range：000-255 Default：255 （Default：OFF） DIM around：0.8S DIM around：1.6S DIM around：2.4S To unlocking, please press” UP-DOWN-UP-DOWN- ENTER” step by step; If the password input is wrong, please press ”ENTER”... - Page 9 LED PAR Quad-18 IP65 ４-CH Function Value Percent/Setting 000-255 0~100% ２ Green 000-255 0~100% Blue 000-255 0~100% ４ White 000-255 0~100% 6-CH Function Value Percent/Setting Dimmer 000-255 0~100% 000-255 0~100% Green 000-255 0~100% Blue 000-255 0~100% White 000-255 0~100% 000-010 No Function Strobe 011-255...
- Page 10 LED PAR Quad-18 IP65 051-070 G 100% B 0~100% 071-090 G 100%~0 B 100% 091-110 R 0~100% G 0 B 100% 111-130 R 100% G 0 B 100%~0 131-150 R 100% G 0~100% B 0~100% 151-170 R 100%~0 G 100%~0 B 100% 171-200 R 100% G 100% B 100% W:100% 201-205...
-
Page 11: Photometric Data
LED PAR Quad-18 IP65 Auto Program 5 Auto 000-255 Only when CH.8 has Auto 01-05 activated speed Dimmer 000-051 Menu Setting dimmer mode Speed 052-101 dimmer mode off 102-150 dimmer mode 1 153-203 dimmer mode 2 204-255 dimmer mode 3 4.0 Photometric Data Color 7848... -
Page 12: Technical Specifications
LED PAR Quad-18 IP65 5.0 Technical Specifications Power supply: 100 -240 V AC, 50/60 Hz Power consumption: 180 W DMX control channels: 4 / 5 / 10 DMX512 connection: 5-pin XLR Number of LEDs: 18 Type of LEDs: 8 W Quad Chip Beam angle: approx.
