SERVICE MANUAL
Ver.1-2012I
Revision History
9-890-927-01
SVS151 Series
Design and specifications are subject to change
without notice.
PERSONAL COMPUTER

Advertisement

Table of Contents
loading

Related Manuals for Sony Vaio SVS151 SERIES

Summary of Contents for Sony Vaio SVS151 SERIES

  • Page 1 SVS151 Series SERVICE MANUAL Ver.1-2012I Revision History Design and specifications are subject to change without notice. PERSONAL COMPUTER 9-890-927-01...
  • Page 2 Service and Inspection Precautions Sony VAIO and CLIE are trademarks or regis Sony, VAIO and CLIE are trademarks or regis- Caution Markings for Lithium/Ion Battery Caution Markings for Lithium/Ion Battery - The teredtrademarks of Sony. Microsoft, Windows, following or similar texts shall be provided on 1.

  • Page 3: Table Of Contents

    M-1. Main Board (For Ext-Gfx model)…………………………. M-2. Main Board (For Int-Gfx model)………………………… Bottom B-1. Bottom………………………………………………..……… D-1. ODD………………………………………………………… D 1. ODD………………………………………………………… H-1. HDD…………………………………………………………… L-1. LCD …………………………………………………… Accessories Accessories A-1. Accessories…………………………..………………… 3-10 WWAN/LCD DIP Switch……………………………..…………………… 3-11 (to 3-11) [Sony Confidential] SVS151 Series (9-890-927-XX)
  • Page 4 G709T1UF G709T1UF Thermal Diode W83L771AWG (DDR) (H/W shutdown) (H/W shutdown) (H/W shutdown) (build up in dGPU) (SKIN) Page 62 Page 62 Page 62 Page 62 Page 62 Page 31 For CPU For GPU For Ambient [Sony Confidential] SVS151 Series (9-890-927-XX)
  • Page 5 Thermal Sensor Thermal Sensor Thermal sensor G709T1UF G709T1UF Thermal Diode W83L771AWG (H/W shutdown) (H/W shutdown) (DDR) Page 47 Page 47 (SKIN) Page 47 Page 47 For CPU For Ambient OUTPUTS +GFXCORE L sku optional [Sony Confidential] SVS151 Series (9-890-927-XX)
  • Page 6 APTER2. FRAME HARNESS DIA AGRAM 2-1.SVS151 Series (TOP) [Sony Confidential] SVS151 Series (9-890-927-XX)

  • Page 7: Svs151 Series (Top)

    2-2. SVS151 Series (BOTTOM) [Sony Confidential] SVS151 Series (9-890-927-XX)

  • Page 8: Screws S-1. Screws

    Main Board M-1.Main Board (For Ext-Gfx model)…….……………… M-2.Main Board (For Int-Gfx model)…. ….………….. Bottom Palmrest B-1.Bottom……………………………………………………. D-1.ODD…………………………………………………….… H-1.HDD……………………………………………………………. L-1.LCD ……………………………………………………… Accessories A-1.Accessories……………………..……………………… 3-10 WWAN/LCD DIP S it h WWAN/LCD DIP Switch ……….…….……………. 3-11 Main Board Bottom [Sony Confidential] SVS151 Series (9-890-927-XX)
  • Page 9 S-1. Screws [Sony Confidential] 3- - 2 SVS151 Series (9-890-927-XX)
  • Page 10 P-1. Palmrest [Sony Confidential] 3- - 3 SVS151 Series (9-890-927-XX)

  • Page 11: M-1. Main Board (For Ext-Gfx Model)

    M-1. Main Board (For Ext-Gfx model) [Sony Confidential] 3- - 4 SVS151 Series (9-890-927-XX)

  • Page 12: M-2. Main Board (For Int-Gfx Model)

    M-2. Main Board (For Int-Gfx model) [Sony Confidential] 3- - 5 SVS151 Series (9-890-927-XX)

  • Page 13: B-1. Bottom

    B-1. Bottom [Sony Confidential] 3- - 6 SVS151 Series (9-890-927-XX)

  • Page 14: D 1. Odd

    D-1. ODD [Sony Confidential] 3- - 7 SVS151 Series (9-890-927-XX)

  • Page 15: H-1. Hdd

    H-1. HDD [Sony Confidential] 3- - 8 SVS151 Series (9-890-927-XX)

  • Page 16: L-1. Lcd

    When replacing either, The Left and Right Hinge must use same vendor's parts. Vendor name is inscribed on red circled area. Jarlly 4-429-358-01 4-429-359-01 4-429-358-11 4-429-359-11 4-429-358-21 4-429-359-21 Left Hinge Right Hinge Left Hinge Left Hinge Right Hinge Right Hinge [Sony Confidential] SVS151 Series (9-890-927-XX)

  • Page 17: A-1. Accessories

    2005 2006 2006 2006 2006 Power Cord Power Cord AC Adapter AC Adapter (for Stick Type Adapter) (Stick Type) 2007 2011 2012 2014 Battery Pack Carrying Pouch Cable Clip Extended Battery 2015 2015 Battery Adapter [Sony Confidential] SVS151 Series (9-890-927-XX)

  • Page 18: Wwan/Lcd Dip Switch

    2. The second and third are used for LCD DIP Switch setting. 15.5/1920x1080/LED/ClearLikeAG/Flat/LGD (A-1892-968-A/A-1920-708-A) 3. The fourth one is used for Intel Anti-Theft setting. When replace Main Board, not to change the normal setting of the replaced one. With Anti-Theft Without Anti-Theft [Sony Confidential] SVS151 Series (9-890-927-XX)

  • Page 19: Note For Wwan Board Replacement

    WWAN : X X X X X X X X X X X X 2. Attach the barcode label which is included with the WWAN Board to o the position where you peeled off the label in the step 1. [Sony Confidential] SVS151 Series (9-890-927-XX)

  • Page 20: Note For Wimax Board Replacement

    2. Attach the barcode label which is included with the WIMAX Board t to the position where you peeled off the label in the step 1 to the position where you peeled off the label in the step 1. [Sony Confidential] SVS151 Series (9-890-927-XX)
  • Page 21 4-3 Holding Method of Main Board 1. When operating with both hands, gently hold the middle of Main board edge as show 2. When operating with one-hand, gently hold the middle of Main board edge and keep vertical. (Level) (Vertical) [Sony Confidential] SVS151 Series (9-890-927-XX)
  • Page 22 SVS151 Series This manual and the constituent data may not be replicated, copied nor reprinted in whole or in part without prior written authorization of Sony Corporation English 2012IF00-1 Sony Corporation 9-890-927-01 © 2012 Sony Corporation Published by Sony Corporation VAIO & Mobile Business Group...

  • Page 23: Revision History

    Revision History Suffix Ver. Date Contents QM No. Ver 1 Ver.1 2012 09 21 2012.09.21 First Edition First Edition <Remarks> <Remarks> [Sony Confidential] SVS151 Series (9-890-927-XX)
