MISTRAL MAX
2
CAR ALARM WITH HOPPING CODE
EXAMPLE OF WIRING DIAGRAM
ACC
On
To ACC or ignition
Off
Start
To Start wire
86
87
30
To ignition input (11)
87
87a
87
To output start kill (9)
85
Note: Relay is delivered with alarm.
Fig.1 Wiring diagram for start kill relay
Input LIGHT
Lights Control Unit
CONTROL (6)
Vehicle Signal Light
Hazard Lights
Switch
Light output (23)
Relay contact bypassing the
Common input (24)
hazard light switch
Fig. 2 Parking Lights output connected to the Hazard light switch
Common input (24)
Common input (24)
connect to +12V
+12V
connect to ground
Fig.3 Signal lights connecting example
(for direct control both lights is necessary connect diodes)
Output to TRUNK
Start kill (-)
ACC
ON
Start
OFF
Siren +12V
ignition (+)
supply +12V
fuse 15A
ground
Security loop
+12V
15 black
BAT
5 oranž. / biely
input Trunk (-)
5 orange / white
input Door (-) 4 blue / white
input Door (+) 3 blue
Valet
PROG
switch
tlačidlo
CN4
CN3
Shock sensor
Additional sensor
WIRING DIAGRAM of ALARM
• INSTALLATION MANUAL 2/2
Example of wiring diagram for door locking system
+12V
NC1
orange
COM1
white
NO1
yellow
Alarm
NC2
orange/black
COM2
white/black
NO2
Up
yellow/black
Fig.4 Original built-in central power lock & only a switch existed
inside of front door. A motor and the control level were required.
Up
NC1
orange
COM1
white
NO1
yellow
Alarm
NC2
+12V
orange/black
COM2
white/black
NO2
yellow/black
+12V
Front Door Power Lock
Fig.5 Original built-in central power lock & electric power lock
switch were installed For example: CHRYSLER
12 greeen
output COM1
17 white
fuse 5A
output NO1
18 yellow
output NC1
19 orange
9 yellow / green
16 pink
output COM2
20 white/black
output NO2
21 yellow/black
output NC2
11 orange
22 orange/black
1 red
13 black
output LIGHT
fuse 10A
input – LIGHT COM
+12V
output AUX1 (-)
8 grey
output AUX2 (-) 10 grey / white
input LIGHT CONTROL (+) 6 black / white
output to PAGER (-) 7 green / yellow
CN2
CN1
2
MISTRAL MAX
X. PROGRAMMING CAR ALARM VIA PC
The car alarm MISTRAL MAX
2
is possible to program via PC, too. To connect car alarm with PC and
set parameters via PC, you need MISTRAL PROG programming cable and MISTRAL MAX
application, which must be installed before alarm connection. After installation of MISTRAL PROG cable
and MAXprog application software is everything ready for programming.
Postup inštalácie ovládacieho súbora pre programovací kábel
After unzipping archive file Cable_PL-2303_Drivers.zip, you must run the file PL2303_Prolific_
WDMDriverInstaller_v1.6.1.exe, from unzipped folder.
- The program starts and displays the information page. It is possible to click Next.
- Files needed for a programming cable begin to install.
- After files successfully installed, installation complete page shows.
MISTRAL MAX
programming process
2
- Plug in connector of programming cable to the alarm.
- Alarm must be powered through the red (+) and black (ground).
- Connect the USB connector into a free USB port.
- Run MAXprog.exe. Program version can be updated, by adding alarm options. Watch distributor
web site.
- Alarm login to the program will be automatically (green text of alarm firmware version will display in
the row).
For reading configuration from the car alarm you need click on to Read button firstly.
Obr.4 Zapojenie pre centrálne zamykanie so spínačom
Application function description
v oboch dverách. Je potrebný motor na riadenie.
Save as.. - click on if you want actually configuration data from the display to write into file on the PC.
Open - click on if you want load configuration data from file into application. Loaded values are
immediately showed on the display.
Print - actually configuration values from display is printed on the printer.
Language - it is possible to select application language.
Exit - application ended.
Read - click on if you want to receive configuration from car alarm into the PC. Received values are
immediately showed on the display.
Write - click on if you want to send actually configuration from the display to car alarm.
Default - click on if you want to set car alarm to factory settings.
Number of service code - it is possible to set code for emergency disarming. For writing this
emergency code into the car alarm, you need click on to Write button..
Switch
LOCK
UNLOCK
23 brown
24 brown / black
Connect in depending on light
polartity - positive or negative
+12V
PAGER
Alarm setup
2
