Summary of Contents for oCOSMO CB301523
-
Page 2: Table Of Contents
For technical assistance, please call (855)-662-6766 or (855) 6oCOSMO and select option 3 or email our tech support group at ocosmoTS@oCOSMO.com. For all other inquiries, please call (855)-662-6766 or (855) 6oCOSMO and selectoption 4 or email our customer service group at ocosmoCS@oCOSMO.com. -
Page 3: Table Of Contents
Table of Contents TABLE OF CONTENTS 2 SAFETY INFORMATION 3 SAFETY INSTRUCTIONS 4 PACKAGE CONTENTS 6 OVERVIEWS 6 & B RONT & E OUND EMOTE XTRAS OUNTING THE OUND NSTALLING ATTERIES TO THE EMOTE ONTROL CONNECTION SUGGESTIONS 13 TV 13 F YOU HAVE DIGITAL AUDIO WITH YOUR TV 14 F YOU HAVE ANALOG AUDIO WITH YOUR... -
Page 4: Safety Information
SAFETY INFORMATION Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with the highest priority on safety. However, improper use can result in electric shock and / or fire. In order to prevent potential danger, please observe the following instructions when installing, operating and cleaning the product. -
Page 8: Sound Bar Remote & Extras
Sound Bar Remote & Extras This remote uses a lithium CR2025 battery. 1. POWER – Turns the Sound Bar on or off. 2. VOLUME (–) – Press this button to decrease the volume. 3. MOVIE – Press this button to switch to the MOVIE sound mode. 4. -
Page 9: Sound Bar
Some oCosmo HDTV remotes might also have buttons used to control the sound bar. If you S. source, S. mode, S. Vol (+/-) buttons, you can use them to control the Sound Bar. Power, POWER – This button turns the Sound Bar on or off. -
Page 10: Mounting The Sound Bar
Mounting the Sound Bar To mount the Sound Bar you need to have 400 mm of horizontal space on the wall. Measure the length of 400mm on the wall. With a pencil mark the two entry points where you are going to install the dry wall anchors and puncture the points with a nail so it is easier for the anchor to be screwed in. - Page 11 Align the mounting brackets on the back of the sound bar to the two screws protruding on the wall and fit into them, then finally slowly lower the sound bar so that it securely hangs onto the screws. - 10 - Sound Bar 2.1 User Manual...
-
Page 12: Installing Batteries To The Remote Control
Installing Batteries to the Remote Control Please insert one CR2025 lithium battery into the remote control. Make sure that you match the (+) and (-) symbols on the batteries with the (+) and (-) symbols inside the battery compartment. Afterwards, re-attach the battery cover. Please note: Only use CR2025 lithium batteries. -
Page 13: Connection Suggestions
Connection Suggestions If you have digital audio with your TV Grab the included 3 head RCA audio cable and use the black colored RCA plug. Find the SPDIF digital audio coax connection on the back of the TV and connect one end of the cable to it. -
Page 14: If You Have Analog Audio With Your Tv
If you have analog audio with your TV Grab the included 3 head RCA audio cable and use the red and white colored RCA plug. Find the analog audio out on the back of the TV and connect one end of the cable to it matching the colors red to red, and white to white. -
Page 15: If You Have An Audio Device With Your Tv
If you have an audio device with your TV Grab the included 3.5mm mini-jack cable. Find the headphone jack connection on the audio device and connect one end of the cable to it. Connect the other end of the cable to the back of the Sound Bar 2.1’s LINE IN connection. -
Page 16: Operation
Operation TO SWITCH ON / OFF THE UNIT Press the POWER button on the front panel or the RED button on the remote control to turn on the unit. If the unit is on you will see the display window show the source selected, volume level and sound mode. -
Page 17: How Do I Clean The Sound Bar
How do I clean the Sound Bar? IMPORTANT The power cable has to be removed from the socket before cleaning the Sound Bar. Do not use volatile solvent (alcohol, rosin, and toluene) to clean the Sound Bar. These types of chemicals might damage the housing . Cleaning the bezel and remote control Use a 100% cotton cloth or micro-fiber cloth for cleaning. -
Page 19: Call Us If You Need Help
For technical help, contact our Technical Support Group via email or phone. Please have your p/n number, serial number, and date of purchase available before you call. Tech Support E-mail : ocosmoTS@oCOSMO.com Customer Service Email : ocosmoCS@oCOSMO.com TEL : (855)-662-6766 or (855) 6oCOSMO Operation Hours : Mon - Fri at 8:30 AM –... -
Page 20: Specification
*The product’s specifications may change without notice or obligation. **This manual’s pictures and words are for references only and are subject to change without notice or obligation. oCOSMO Inc is not liable for the misuse or misinterpretation of this manual. - 19 -... -
Page 21: Limited Product Warranty
Continental US, Alaska, Hawaii and Puerto Rico. See below for the RC2602 Extended Service warranty. oCOSMO’s Responsibility R&2602 units purchased from an authorized R&2602 U.S. Reseller in the United States and that are used in the fifty (50) United States or Puerto Rico and Canada are warranted to... - Page 22 components, and/or software bundled with the Sound Bar are not covered by this warranty. Any damages caused directly or indirectly by Buyer’s or Reseller’s “Value Added Feature” are not covered by this warranty or R&RVPR, Inc. Any damages of any kind including, but not limited to, direct or indirect damages, lost profits, lost savings, or other special incidental, exemplary or consequential damages whether for breach of contract, tort, or otherwise, or whether arising out of the use of or inability to use the product, even if R&2602 , INC.
-
Page 23: Disclaimer, Trademarks, & Copyright Information
Disclaimer, Trademarks, & Copyright Information RC2602 is a trademark or registered trademark of RcRDPR Group. R&26 02 Inc. shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product. is D trademark of SRS LabV, Inc. -
Page 24: Fcc Compliance Statement
FCC Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: This device may not cause harmful interference This device must accept any interference received, including interference that my cause undesired operation.
