- Page 2 PWA12 Wall Plate / In Wall Audio Control Amplifier Receiver PWA15BT Wall Plate / In Wall Audio Control Amplifier Receiver with Bluetooth Single Gang Wall Plate Stereo Audio Power Amplifier Wall Plate Stereo Audio Power Amplifier Receiver is a quick and easy way to get your music playing to most local speakers.
- Page 3 Connection Red Power + Black Power Black Signal (ground) Gray Signal Left White Signal Right Speaker Out, Right + Speaker Out, Right Speaker Out, Left + Speaker Out, Left Amplified In Wall Volume Control This device is the size of a standard wall volume control plate, and contains a highly efficient stereo amplification.
- Page 4 BLACK/WHITE/GRAY pigtail leads on the rear of the unit (for hard wired speaker connection). Please Note: An audio source should not be connected to both. Use only one or the other. PWA12 PWA1215BT (with Bluetooth) x Microphone Paging and Speaker Control Made Easy...
